Bring modern convenience to your original Zaxxon arcade hardware with our collection of Zaxxon Free Play and High Score Save Kits. These plug-and-play upgrades add reliable high score saving, Free Play functionality, and an intuitive on-screen settings menu while preserving the classic isometric space-combat gameplay that made Zaxxon a standout classic.
Related Arcade Kits You May Also Like:
Asteroids |
Space Duel |
Gravitar |
Tempest |
Time Pilot
Braze Zaxxon Free Play and High Score Save Kit
Braze Zaxxon High Score Save Kit — Features & Install 📄 Installation Guide (PDF) Overview A simple-to-install high score save kit for Zaxxon that permanently remembers the top 6 scores and initials—no batteries required. Includes deluxe Free Play, power-on self-test, an on-screen settings menu, and a Flip Screen option for 180° rotation. Installs in minutes with no board modifications or special wiring typically required. Installation Summary Power down the cabinet and access the CPU board. Carefully remove the Z80 CPU from the Zaxxon CPU board. Insert the Z80 into the included daughter card. Plug the daughter card into the vacated Z80 socket on the CPU board. Power on and follow the install guide to verify operation. Key Features Installs in minutes: no board modifications or special wiring. Top 6 High Score Save: remembers scores and initials permanently (no batteries). True Free Play: no coins required; keep the coin door closed. Full attract mode: attract screens run normally even in Free Play. Power-on diagnostics: automatic self-test every time the game powers up. On-screen settings: change options and erase high scores without DIP switch hassle. Flip Screen: 180° cabinet rotation with no monitor or hardware adjustments. FAQ Where can I download the install guide? Zaxxon Install Guide (PDF) Do I need to solder anything? Typically no. Most installations require no soldering or special wiring. How do I reset the high scores? Use the on-screen settings menu to erase the table and restore defaults. Can I rotate the display? Yes. Use the built-in Flip Screen setting for a 180° rotation—no monitor adjustments needed. Which CPU does this kit use? The kit interfaces with the Z80 CPU—remove the Z80, place it in the daughter card, then insert the card into the Z80 socket.
Zaxxon Free Play and High Score Save Kit
Zaxxon Free Play and High Score Save Kit for Sega Arcade PCB Upgrade your original Zaxxon arcade PCB with reliable free play, high score saving, attract sound enhancements, and optional Wi-Fi leaderboard support while preserving authentic gameplay and original arcade hardware. Designed specifically for original Sega hardware, this plug and play upgrade improves long-term reliability without changing gameplay timing, controls, sound, or the classic arcade experience collectors expect. Original Arcade Hardware • No Emulation • No Gameplay Changes • Designed for Authentic Arcade PCBs View Install Guide Free Play Play without coins while retaining optional coin operation. High Score Saving Stores the Top 6 scores with initials. Flip Screen Support Rotate the display 180° directly from the menu system. Optional Wi-Fi Upload scores online to global arcade leaderboards. Upgrade Your Zaxxon Arcade Experience Restore and enhance your original Zaxxon arcade machine with a professionally designed Free Play and High Score Save Kit built specifically for authentic Sega arcade hardware. Original boards often lose high scores, rely on aging components, or suffer from unstable resets. This upgrade modernizes your PCB while preserving the original gameplay, controls, timing, and arcade feel that made Zaxxon one of the most recognizable isometric shooters ever released. Unlike multigame systems or reproduction boards, this kit keeps your original arcade PCB intact while improving long-term reliability for collectors, operators, and restoration projects. Important Installation Notes Socketed Z80 required: Install a 40-pin socket if your Z80 processor is not socketed No Service Switch required: This kit uses an on-screen menu system Read the Zaxxon Installation Guide before installation Included Features Easy Installation: No soldering, board modifications, or special wiring required Permanent Score Saving: Reliable serial EEPROM storage instead of batteries or NVRAM High Score Save: Stores the Top 6 scores with initials Attract Sounds: Adjustable at 25%, 50%, or 100% attract rotation No Service Switch Needed: Full on-screen menu system built directly into the kit Logo Options: Choose manufacturer or HighScoreSaves attract logos Freeplay Mode: No more coins or opening the coin door Coin-Up Support: Continue using quarters or tokens Attract Mode Protection: Reduces static screens to help minimize burn-in On-Screen DIP Settings: Menu-driven setup without cabinet pull-out ROM Saver: Optionally remove original program ROMs Cabinet Compatibility: Works in Upright and Cocktail cabinets Backup and Restore: Save and restore high scores anytime Separate Score Tables: Supports 2, 3, 4, or 5 lives settings Flip Screen: Rotate the screen 180° directly from the menu Installation Information Installation Difficulty: Easy Soldering Required: No, if CPU is socketed Processor Requirement: Requires a Z80 processor Socketed CPU Required: Install a 40-pin socket if needed Cabinet Compatibility: Upright and Cocktail supported Installation Guide: Download PDF Installation Guide Optional Wi-Fi Features and Online Leaderboards Learn About Wi-Fi Enabled Kits Upgrade to a Wi-Fi Enabled Kit to upload scores online and compete against players around the world, locally within your arcade, or across your own connected cabinet network. Standard kits save scores locally to the PCB, while Wi-Fi kits add automatic online score syncing through the HighScoreSaves global leaderboard platform. View Global Arcade High Scores Zaxxon Free Play and High Score Save Kit FAQ Is installation truly plug-and-play? Yes. Simply ensure your Z80 processor is socketed or install a 40-pin socket. How many scores are saved? The kit stores the Top 6 high scores with initials. Do I need a Service or Test Switch? No. This kit uses an on-screen menu and does not require a Test or Service switch. What’s the difference between Wi-Fi and Standard kits? Wi-Fi kits upload scores online while Standard kits save scores locally to the PCB. Can I back up and restore scores? Yes. Backup and Restore functions are built directly into the kit. Can I flip the screen? Yes. Rotate the display 180° directly from the on-screen menu system. Will this work in my cabinet? Yes. The kit supports Upright and Cocktail Zaxxon cabinets. Does Freeplay disable coin inputs? No. Freeplay works alongside standard coin operation. Where can I download the Installation Guide? Download the Zaxxon Installation Guide PDF Designed and supported by HighScoreSaves for arcade collectors, restorers, and original hardware enthusiasts. Resources 1. Zaxxon Installation Guide PDF 2. Setup Tips and Configuration Guide 3. HighScoreSaves YouTube Channel 4. HighScoreSaves Facebook Page 5. HighScoreSaves eBay Store
Details and Benefits
The Zaxxon Free Play and High Score Save Kit is engineered for original arcade hardware to improve score retention, streamline resets, and enhance gameplay convenience. This upgrade brings modern reliability while preserving the classic isometric space shooter experience that defines Zaxxon.
What This Kit Adds
- Free Play support — Enable coin-free play while still supporting traditional coin operation
- Reliable high score saving — Permanent high score storage using non-volatile memory
- On-screen settings menu — Adjust gameplay and kit options without opening the cabinet
- Monitor-friendly attract behavior — Helps reduce static attract screen burn-in
- Cabinet compatibility — Works with Upright arcade cabinets
Advanced Features
- High score backup and restore — Save and reload score data as needed
- Separate score tables — Independent tables based on configuration settings
- Optional Wi-Fi support — Upload and sync high scores online
Important Installation Notes
This kit requires a compatible socketed CPU. Always review the installation guide prior to beginning to ensure correct setup and reliable operation.
Optional Wi-Fi enabled versions allow scores to be uploaded online and synced to your personal player page in addition to local high score saving on the PCB.
