Cheyenne Arcade PCB Upgrade Compatibility for Original Exidy 440 Hardware
Confirm whether your Cheyenne arcade machine uses compatible original Exidy 440 hardware for the HighScoreSaves Exidy 440 Multigame upgrade. Cheyenne is included with this 10-game kit rather than being offered as a separate Cheyenne-only product.
Choosing the Correct Cheyenne Arcade PCB Upgrade
A Cheyenne cabinet, marquee, gun, or control hardware does not by itself confirm compatibility. Original shooting cabinets may have been converted, repaired, or fitted with replacement boards, so the actual arcade hardware should be identified before ordering.
Cheyenne is supported through the HighScoreSaves Exidy 440 Multigame Free Play and High Score Save Kit. There is no separate Cheyenne-only HighScoreSaves kit. The upgrade requires documented compatible original Exidy 440 arcade hardware and keeps that original platform in service.
Cheyenne & Exidy 440 PCB Compatibility
How the Cheyenne Exidy 440 Installation Works
The Exidy 440 installation works with both the original CPU PCB and sound PCB. The boards are separated during installation so the required processors, ROMs, and daughter cards can be installed in their documented locations.
On the CPU board, designated EPROMs are removed and the 6809E processor is transferred to the kit. The main daughter card is then installed into the documented board sockets. On the sound board, the 6809 processor and designated EPROMs are removed before the sound daughter-card assemblies are installed.
Before restoring cabinet power, verify processor orientation, Pin 1 alignment, daughter-card seating, socket condition, ribbon-cable connections, DIP-switch positions, and all other installation steps shown in the current Exidy 440 guide.
Cheyenne Pre-Order Compatibility Checklist
Keeping the Original Exidy 440 Cheyenne Hardware
The HighScoreSaves Exidy 440 Multigame Kit keeps the compatible original Exidy arcade platform in service while adding Cheyenne and the other supported Exidy 440 titles, Free Play, permanent score saving, flexible game selection, diagnostics, and optional online capability.
For the complete 10-game list, exact high-score modes, menu options, Gun Select Mode, Stealth Mode, Standard and Wi-Fi versions, included components, current price, and ordering choices, use the individual Exidy 440 Multigame product page.
Cheyenne Exidy 440 PCB Compatibility FAQ
Is there a separate Cheyenne-only HighScoreSaves kit?
No. Cheyenne is supported through the HighScoreSaves Exidy 440 Multigame Free Play and High Score Save Kit.
Does installation require an original Exidy 440 PCB?
Yes. Cheyenne support requires documented compatible original Exidy 440 arcade hardware. The multigame kit works with that original platform rather than replacing it.
Which processors are used during Exidy 440 installation?
The installation guide requires a 6809E processor for the CPU-board portion of the kit and a 6809 processor for the sound-board portion.
Are original Cheyenne ROMs removed during installation?
Yes. Designated original EPROMs are removed from the Exidy 440 CPU and sound boards as directed by the installation guide. Save those original components and record where they were installed.
Does the multigame kit replace the original Cheyenne hardware?
No. The documented compatible original Exidy 440 hardware remains the underlying arcade platform. The daughter-card system adds multigame and score-saving functions to that original hardware.
