Super Pac-Man Free Play and High Score Save Kit for Original Super Pac-Man Hardware
Upgrade a documented compatible original Super Pac-Man arcade PCB with Free Play, permanent Top 5 score saving, menu-driven settings, serial EEPROM storage, attract-sound options, ROM Saver support, and optional Wi-Fi leaderboard support.
This HighScoreSaves kit is designed for original Super Pac-Man arcade hardware. It is not an emulation platform, reproduction board, or generic multicade replacement. The kit preserves the original Super Pac-Man door-based maze gameplay while adding modern score-saving and operator features.
Super Pac-Man High Score Save Kit Features
A focused upgrade for original Super Pac-Man PCBs that adds Free Play, Top 5 score saving, attract-sound control, menu-driven settings, and optional online leaderboard support.
- Designed for documented compatible original Super Pac-Man arcade PCBs
- Permanent Top 5 high score saving
- Separate score tables for two, three, four, and five lives
- Free Play with traditional Coin-Up operation available
- Serial EEPROM score storage with no batteries required
- Attract sounds and full attract-sound option
- Menu-driven DIP settings and on-screen difficulty settings
- ROM Saver support for optional program ROM removal
- Score backup and restore support
- Works in upright or cocktail cabinet configurations
- Optional 2.4 GHz Wi-Fi leaderboard support
Access the HighScoreSaves Settings Menu
To access the settings menu, hold Player 1 Start while turning the cabinet on. Release the button when the on-screen prompt tells you to continue.
Verify Super Pac-Man PCB Compatibility Before Ordering
- This kit is designed only for documented compatible original Super Pac-Man arcade PCBs.
- A 6809E processor is required for installation.
- The original 6809E is removed, installed on the HighScoreSaves daughter card, and the kit is installed where the 6809E was located.
- No soldering is required when the 6809E location already has a compatible socket.
- Optional program ROM removal is supported. A riser socket may be needed if the ROMs are not removed.
- Review the installation guide before setup and verify processor orientation, socket condition, board compatibility, and all installation steps before restoring cabinet power.
Read more below
Super Pac-Man Kit Details and Benefits
The Super Pac-Man Free Play and High Score Save Kit upgrades documented compatible original Super Pac-Man arcade hardware with Free Play, permanent Top 5 high score saving, menu-driven settings, serial EEPROM score storage, attract-sound options, ROM Saver support, and optional Wi-Fi leaderboard support.
This is a focused original-hardware upgrade for Super Pac-Man. It keeps the original PCB platform, cabinet controls, gameplay timing, and door-based maze mechanics while adding score-saving reliability and operator-friendly setup options.
Main Super Pac-Man Kit Features
- Original Super Pac-Man PCB support: Designed for documented compatible original Super Pac-Man arcade hardware.
- Permanent score saving: Saves the Top 5 supported high scores.
- Separate score tables: Maintains different supported score tables for two-, three-, four-, and five-life settings.
- Free Play: Start games without inserting coins.
- Coin-Up operation: Continue using traditional coin operation when Free Play is disabled.
- Serial EEPROM score storage: Saves supported scores and settings without batteries.
- Attract sounds: Enable standard attract sounds or full attract sounds, including dot-munching sound during gameplay attract.
- Attract mode: Helps reduce static-screen burn by keeping the game presentation active.
- Menu-driven DIP settings: Change supported DIP settings through the on-screen menu without opening the cabinet.
- On-screen difficulty: Set supported difficulty values from R0 Normal through RF Auto Hard.
- ROM Saver support: Optionally remove original program ROMs to reduce power and heat.
- Backup and restore: Back up saved scores and restore them later.
- Cabinet support: Works in documented upright or cocktail cabinet configurations.
- Optional Wi-Fi: Add online score submission while retaining local score saving.
Accessing the Settings Menu
To access the supported HighScoreSaves settings menu, hold Player 1 Start while turning the cabinet on. Release the button when the on-screen prompt tells you to continue.
Free Play, Coin-Up, and Top 5 Score Saving
Free Play allows Super Pac-Man to start without inserting coins. Traditional Coin-Up operation can still be used when Free Play is disabled, making the kit useful for home arcades, routed games, and collector cabinets.
The kit saves the Top 5 supported scores and maintains separate score tables for two-, three-, four-, and five-life settings. This lets the cabinet owner preserve score data while changing supported lives settings.
Score and settings data is saved through serial EEPROM storage instead of batteries or NVRAM. Backup and restore support is included for managing saved score data.
Attract Sounds, ROM Saver, and Cabinet Setup
Attract-sound options allow the cabinet owner to enable standard attract sounds or full attract sounds. The full attract-sound option includes the dot-munching sound during the gameplay attract screen.
ROM Saver support allows optional removal of original program ROMs. If the ROMs are not removed, a riser socket may be needed because of daughterboard clearance.
The kit supports documented upright and cocktail cabinet configurations and keeps the original Super Pac-Man gameplay experience centered on the original arcade PCB.
Installation and PCB Requirements
- Designed only for documented compatible original Super Pac-Man arcade PCBs.
- A 6809E processor is required for installation.
- The kit includes a 6809 daughter card.
- The original 6809E is removed from the PCB, installed on the daughter card, and the daughter card is installed where the 6809E was located.
- Ensure the processor is socketed. If it is not socketed, a compatible 40-pin socket must be installed before using the kit.
- Optional program ROMs can be removed as part of the ROM Saver setup.
- A riser socket may be needed if the original ROMs are not removed.
- Verify the notch and Pin 1 orientation on the 6809E before restoring power.
- Review the installation guide, double-check all work, and power off immediately if the game does not start after installation.
Standard and Optional Wi-Fi Versions
Standard kits save supported scores and settings locally. An internet connection is not required for gameplay, Free Play, Coin-Up operation, menu access, or local score saving.
Optional 2.4 GHz Wi-Fi kits include the same local features and add supported online score submission through the HighScoreSaves leaderboard platform.
Wi-Fi can be disabled without affecting local gameplay, Free Play, Coin-Up operation, score saving, or settings-menu operation.
Super Pac-Man Kit FAQ
Which PCB is required?
This kit is designed only for documented compatible original Super Pac-Man arcade PCBs.
What CPU is required?
A 6809E processor is required. The processor must be installed on the HighScoreSaves daughter card during installation.
Does installation require soldering?
Not when the 6809E location already has a compatible socket. If the processor is not socketed, a compatible 40-pin socket must be installed first.
How many scores are saved?
The kit saves the Top 5 supported high scores.
Does it support Free Play and Coin-Up?
Yes. Free Play is supported, and traditional Coin-Up operation can still be used.
How do I access the settings menu?
Hold Player 1 Start while turning the cabinet on. Release the button when the on-screen prompt tells you to continue.
Does it support attract sounds?
Yes. Standard attract sounds and full attract sounds are supported, including the dot-munching sound during gameplay attract.
Is Wi-Fi required?
No. Standard kits save supported scores locally. Wi-Fi is optional for online leaderboard support.
