Jail Break Free Play and High Score Save Kit for Original Konami Hardware
Upgrade a compatible original Konami Jail Break arcade PCB with Free Play, Top 5 high score saving, initials, serial EEPROM storage, attract sounds, menu-driven DIP settings, ROM Saver support, separate score tables, backup and restore, and optional Wi-Fi leaderboard support.
The HighScoreSaves Jail Break Kit works with original Konami arcade hardware rather than replacing the game board with an emulation platform, reproduction PCB, or multicade system.
The kit requires a 6809E processor installed in a compatible 40-pin socket. No soldering is required when the 6809E location is already socketed.
HighScoreSaves Jail Break Kit
Designed for players, collectors, and operators who want Free Play, permanent score saving, initials, attract sound support, menu-driven settings, and optional online leaderboard support while keeping original Jail Break arcade hardware in service.
- Free Play with traditional Coin-Up operation retained
- Permanent Top 5 high score saving using serial EEPROM storage
- Player initials saved with scores
- Full attract audio support
- Attract mode protection to help reduce CRT monitor burn-in
- Menu-driven DIP and operator settings
- ROM Saver support for optional original ROM removal
- Separate score tables for 2, 3, 4, or 5 lives settings
- Backup and restore support for saved high scores
- Upright and cocktail cabinet support
- Optional Wi-Fi leaderboard support
View Jail Break Free Play and High Score Save Kit
View Jail Break Installation Guide
Before ordering: confirm that your machine contains a documented compatible original Konami Jail Break arcade PCB and a socketed 6809E processor location. If the 6809E processor is soldered directly to the PCB, a qualified arcade technician must install a compatible 40-pin socket before the kit can be used.
Jail Break Kit Details and Benefits
The HighScoreSaves Jail Break Free Play and High Score Save Kit adds Free Play, Top 5 high score saving, initials, serial EEPROM storage, attract sounds, menu-driven DIP settings, ROM Saver support, separate score tables, backup and restore, upright/cocktail support, and optional Wi-Fi leaderboard support to documented compatible original Konami arcade hardware.
This daughterboard works with the original Konami Jail Break arcade PCB rather than replacing the game board with an emulation platform, reproduction PCB, or multicade system.
Main Jail Break Kit Features
- Top 5 score saving: Stores the Top 5 supported high scores permanently.
- Initial entry: Players can enter and permanently store initials with scores.
- Battery-free storage: Uses reliable serial EEPROM storage instead of battery-backed NVRAM.
- Free Play: Start Jail Break without inserting coins.
- Traditional Coin-Up operation: Continue accepting quarters or tokens when Free Play is disabled.
- Attract sounds: Full attract audio support is included.
- Attract mode protection: Helps reduce CRT monitor burn-in during idle operation.
- Menu-driven DIP settings: Adjust supported DIP options directly on screen.
- ROM Saver: Original ROMs may be removed when installed as directed.
- Separate score tables: Maintains independent score tables for 2, 3, 4, or 5 lives settings.
- Backup and restore: Save and reload supported high scores when needed.
- Upright and cocktail support: Supports documented upright and cocktail cabinet configurations.
- Optional Wi-Fi: Add online leaderboard score submission while keeping local score saving.
Access the HighScoreSaves Jail Break Settings Menu
To access the settings menu, hold Player 1 Start while turning the cabinet on. Release the button when the on-screen prompt tells you to continue.
Free Play, Initials, and Permanent High Scores
Free Play allows Jail Break to start without inserting coins while retaining traditional Coin-Up operation as an available setting.
Supported score data is stored using serial EEPROM, so battery-backed NVRAM is not required for saved scores. The kit stores the Top 5 supported high scores and allows player initials to be saved with those scores.
Separate score tables are supported for 2, 3, 4, and 5 lives settings, helping keep score results organized across different gameplay configurations.
Konami Hardware, Attract Sounds, and ROM Saver
Jail Break uses original Konami arcade hardware, and this kit is designed to keep the original run-and-gun gameplay, controls, timing, sound, and cabinet behavior intact.
Full attract audio support is included, and attract mode protection helps reduce CRT monitor burn-in during idle operation.
ROM Saver support allows designated original ROMs to be removed when the kit is installed as directed in the Jail Break installation guide.
Installation and PCB Requirements
- Designed for documented compatible original Konami Jail Break arcade PCBs.
- Access to the original arcade PCB is required during installation.
- This kit requires a 6809E processor.
- The 6809E processor must be installed in a compatible 40-pin socket.
- No soldering is required when the 6809E location is already socketed.
- If the 6809E processor is soldered directly to the PCB, a qualified arcade technician must install a compatible 40-pin socket.
- Remove only the designated original ROMs identified in the Jail Break installation guide when using ROM Saver features.
- Verify Pin 1 orientation, processor alignment, socket condition, board seating, and all processor pins before restoring cabinet power.
- Review the Jail Break installation guide before installation.
Standard and Optional Wi-Fi Versions
The Standard Kit saves supported scores locally to the PCB and does not require an internet connection for gameplay, Free Play, settings-menu operation, ROM Saver operation, initials, or local score saving.
The optional Wi-Fi Enabled Kit includes the same local features and adds online score syncing through the HighScoreSaves global leaderboard platform.
Wi-Fi can be disabled without affecting Jail Break gameplay, Free Play, local score saving, score tables, initials, ROM Saver operation, or menu-driven settings.
Jail Break Kit FAQ
Which arcade PCB does the HighScoreSaves Jail Break kit support?
The HighScoreSaves Jail Break kit is designed for documented compatible original Konami Jail Break arcade PCBs.
Which processor is required for the Jail Break kit?
The Jail Break kit requires a 6809E processor installed in a compatible socketed 40-pin processor location.
How many high scores does the Jail Break kit save?
The Jail Break kit stores the Top 5 supported high scores using serial EEPROM storage.
Does the Jail Break kit save player initials?
Yes. Players can enter and permanently save initials alongside their Jail Break scores.
Does the HighScoreSaves Jail Break kit support Free Play and Coin-Up operation?
Yes. The kit supports Free Play while retaining traditional Coin-Up operation when Free Play is disabled.
How is the HighScoreSaves Jail Break settings menu opened?
Hold Player 1 Start while turning the cabinet on. Release the button when the on-screen prompt tells you to continue.
What is ROM Saver on the Jail Break kit?
ROM Saver allows designated original ROMs to be removed when the kit is installed as directed in the Jail Break installation guide.
Does the Jail Break kit support upright and cocktail cabinets?
Yes. The Jail Break kit supports documented upright and cocktail cabinet configurations.
Is Wi-Fi required for the HighScoreSaves Jail Break kit?
No. Standard kits save supported scores locally. Wi-Fi is optional for online leaderboard support.
