Hyper Sports Rearranged Multigame Free Play and High Score Save Kit
Upgrade a compatible original Hyper Sports arcade PCB with the Hyper Sports Multigame Free Play and High Score Save Kit, adding Track and Field, Hyper Sports, and Hyper Sports Rearranged with Free Play, permanent score saving, serial EEPROM storage, practice levels, menu-driven settings, ROM Saver support, and optional Wi-Fi leaderboard support.
This multigame upgrade is designed specifically for original Konami Hyper Sports hardware. It does not install on Track and Field PCBs.
Installation requires socket work and PCB setup. Review the installation guide before ordering, including the required Z80 sound CPU socket, PROM sockets, and jumper configuration.
Hyper Sports Rearranged Multigame Features
Choose this kit when you want Track and Field, Hyper Sports, and Hyper Sports Rearranged running on compatible original Hyper Sports arcade hardware with modern score-saving and operator features.
- Includes Track and Field, Hyper Sports, and Hyper Sports Rearranged
- Designed only for original Hyper Sports arcade PCBs
- Not compatible with Track and Field PCBs
- Uses 6809E arcade CPU hardware
- Supports original 1–4 player control configurations
- Free Play with traditional Coin-Up operation retained
- Top 10 scores for Track and Field
- Top 13 scores for Hyper Sports
- Top 23 scores for Hyper Sports Rearranged
- Separate score tables for each game
- Reliable serial EEPROM storage with no batteries or NVRAM required
- Attract sounds and attract jingles
- Menu-driven DIP and gameplay settings
- ROM Saver support for optional original ROM removal
- High Scores button and All Global High Scores button support
- Practice levels for starting directly at events
- Boot directly into Hyper Sports, Track and Field, or Hyper Sports Rearranged
- Stealth Mode to automatically boot into the last played game
- Menu Lock to help prevent unauthorized menu changes
- Upright and cocktail cabinet support
- Optional Wi-Fi leaderboard support
View Hyper Sports Rearranged Multigame Kit
View Hyper Sports Rearranged Installation Guide
Before ordering: confirm that your machine contains a documented compatible original Hyper Sports arcade PCB. This kit does not install on Track and Field PCBs. Soldering and socket installation are required.
Installation requirements: the upper PCB requires a Z80 sound CPU socket at AB18 and a PROM socket at C3. The lower PCB requires PROM sockets at A9 and J12. Jumpers must be set to 128, not 64, at D10/D11 and F18/F19.
Hyper Sports Rearranged Multigame Kit Details and Benefits
The Hyper Sports Multigame Free Play and High Score Save Kit adds Track and Field, Hyper Sports, and Hyper Sports Rearranged to compatible original Hyper Sports arcade hardware. It also adds Free Play, permanent score saving, serial EEPROM storage, attract sounds, attract jingles, practice levels, menu-driven settings, ROM Saver support, Stealth Mode, Menu Lock, 1–4 player support, and optional Wi-Fi leaderboard support.
This kit is designed only for original Hyper Sports arcade PCBs. It does not install on Track and Field PCBs.
Games Included
Track and Field
Konami’s Olympic-style arcade game with rapid button gameplay, world records, and classic multiplayer competition.
Hyper Sports
The official Track and Field sequel with swimming, skeet shooting, vaulting, and additional Olympic-style arcade events.
Hyper Sports Rearranged
Rearranged gameplay with mixed event orders, new gameplay sequences, and additional variations.
Main Hyper Sports Rearranged Features
- Three games included: Track and Field, Hyper Sports, and Hyper Sports Rearranged.
- Permanent score saving: Uses serial EEPROM instead of NVRAM or batteries.
- Game-specific score tables: Saves Top 10 for Track and Field, Top 13 for Hyper Sports, and Top 23 for Hyper Sports Rearranged.
- Separate score tables: Each game has its own independent score tables.
- Free Play and Coin-Up: Play without coins while still supporting traditional coin operation.
- Attract sounds: Adjustable at 25%, 50%, or 100% rotation intervals.
- Attract jingles: Adds rotating audio features during attract mode.
- Attract mode protection: Helps reduce screen burn-in during idle periods.
- Original controls: Supports original 1–4 player arcade control layouts.
- On-screen DIP settings: Menu-driven configuration system.
- ROM Saver: Original ROMs can be removed when installed as directed.
- Backup and restore: Save and export high scores when needed.
- Reset button: Restart gameplay without powering down the cabinet.
- High Scores button: Quickly view saved score tables.
- All Global High Scores button: Useful for Wi-Fi enabled kits.
- Game selection: Boot directly into Hyper Sports, Track and Field, or Hyper Sports Rearranged.
- Stealth Mode: Automatically boot into the last played game.
- Practice levels: Start directly at any event.
- Bonus Man options: Additional Track and Field gameplay configuration.
- Menu Lock: Helps prevent unauthorized menu changes.
- 6809E processor support: Uses original 6809E arcade CPU hardware.
Game Selection, Practice Levels, and Menu Lock
The kit can boot directly into Hyper Sports, Track and Field, or Hyper Sports Rearranged. Stealth Mode automatically boots into the last played game for a more streamlined cabinet experience.
Practice levels allow players to start directly at individual events, making it easier to train specific parts of the game without affecting normal score play.
Menu Lock helps prevent unauthorized menu changes in public, routed, or shared arcade environments.
Installation and PCB Requirements
- Designed only for original Hyper Sports arcade PCBs.
- This kit does not install on Track and Field PCBs.
- Soldering and socket installation are required.
- The kit uses original 6809E arcade CPU hardware.
- The upper PCB requires a Z80 sound CPU socket at AB18.
- The upper PCB requires a PROM socket at C3.
- The lower PCB requires PROM sockets at A9 and J12.
- Jumpers must be set to 128, not 64, at D10/D11 and F18/F19.
- Verify socket work, jumper settings, Pin 1 orientation, processor alignment, board seating, and all pins before restoring cabinet power.
- Review the Hyper Sports Rearranged installation guide before installation.
Standard and Optional Wi-Fi Versions
The Standard Kit saves supported scores locally to the PCB and does not require an internet connection for gameplay, Free Play, local score saving, game selection, practice levels, Menu Lock, or menu-driven settings.
The optional Wi-Fi Enabled Kit includes the same local features and adds online score syncing through the HighScoreSaves global leaderboard platform.
Wi-Fi can be disabled without affecting local gameplay, Free Play, score saving, ROM Saver operation, game selection, practice features, or supported cabinet operation.
Hyper Sports Rearranged Kit FAQ
Which games are included with the Hyper Sports Rearranged kit?
The kit includes Track and Field, Hyper Sports, and Hyper Sports Rearranged.
Which arcade PCB does the Hyper Sports Rearranged kit require?
The kit installs only on original Hyper Sports arcade PCBs.
Can the Hyper Sports Rearranged kit install on a Track and Field PCB?
No. This kit does not install on Track and Field PCBs.
Is soldering required for the Hyper Sports Rearranged kit?
Yes. Socket installation and PCB work are required.
How many scores does the Hyper Sports Rearranged kit save?
It saves Top 10 scores for Track and Field, Top 13 scores for Hyper Sports, and Top 23 scores for Hyper Sports Rearranged.
Does the Hyper Sports Rearranged kit support Free Play and Coin-Up?
Yes. Free Play and traditional Coin-Up operation are both supported.
Does the Hyper Sports Rearranged kit support 4-player cabinets?
Yes. It supports original 1–4 player Hyper Sports control configurations.
Can players practice individual events?
Yes. Practice levels allow players to start directly at individual events.
Is Wi-Fi required for the Hyper Sports Rearranged kit?
No. Standard kits save supported scores locally. Wi-Fi is optional for online leaderboard support.
