Space Duel Free Play and High Score Save Kits
Download Space Duel Install Guide (PDF)
Upgrade Your Space Duel Arcade Experience
Bring modern convenience to your original Space Duel arcade hardware with our collection of Space Duel Free Play and High Score Save Kits. These plug-and-play upgrades add reliable high score saving, Free Play functionality, and an on-screen settings menu while preserving the classic vector shooter gameplay that makes Space Duel a timeless favorite.
Related Arcade Kits You May Also Like:
Asteroids |
Gravitar |
Gorf |
Space Invaders |
Galaga
6100 Monitor Low Voltage Section Regulator Upgrade
6100 Deflection Board LV Section Replacement Module The 6100 Deflection Board LV Section Replacement Module is designed to replace the unreliable low-voltage (LV) section found on the Atari 6100 vector monitor deflection board. This upgrade eliminates several common failure points that can cause instability, monitor shutdown, or inconsistent operation. Over time, the original low-voltage circuitry on the 6100 deflection board can become unreliable due to aging components, heat stress, and repeated power cycling. This replacement module modernizes that section of the circuit and provides improved reliability while maintaining proper monitor operation. Once installed, the module restores stable low-voltage regulation for the deflection board, helping ensure your vector monitor operates correctly in classic arcade machines such as Tempest, Star Wars, Major Havoc, Quantum, and other Atari vector cabinets that use the 6100 monitor. Key Features Replaces the original low-voltage section of the Atari 6100 deflection board Eliminates common LV circuit failure points Improves long-term reliability of the vector monitor Helps stabilize monitor operation and voltage regulation Designed for arcade restoration and repair work Compatibility Designed for use with the Atari 6100 vector monitor commonly found in classic arcade machines such as Tempest, Star Wars, Major Havoc, Quantum, and other Atari vector titles. Installation Notes Soldering and de-soldering are required for installation. The module installs directly onto the 6100 deflection board as shown in the gallery images. Installation should be performed by someone experienced with arcade PCB repair. This upgrade is an excellent solution for arcade collectors and technicians restoring original Atari vector monitors who want improved reliability without replacing the entire deflection board.
AVG - Atari Analog Vector Generator
Atari AVG Custom Chip Replacement The Atari AVG Custom Chip Replacement is designed as a direct substitute for the original Atari AVG chip (Part Number: 137179-001). This custom component functions as the Gate Array / Address Controller used in Atari vector arcade hardware, handling critical addressing and control tasks required for proper system operation. Because the original Atari AVG chip is long discontinued and increasingly difficult to source, this replacement solution provides a reliable option for repairing and restoring classic Atari arcade boards. It is engineered to replicate the functionality of the original DIP package chip while allowing collectors and technicians to keep their vector-based arcade systems running. This chip is commonly used in Atari vector arcade machines where the AVG (Analog Vector Generator) system manages the generation and control of vector graphics displayed on the monitor. Proper operation of this chip is essential for stable gameplay and correct vector drawing. Key Features Replacement for Atari AVG custom chip Compatible with original part number 137179-001 Implements the Gate Array / Address Controller function Designed for repair and restoration of Atari vector arcade boards Helps maintain long-term operation of classic Atari vector systems
Space Duel Free Play and High Score Save Kit
Space Duel Free Play and High Score Save Kit for Atari Arcade PCB Upgrade your original Space Duel arcade PCB with reliable free play, high score saving, attract sounds, and optional Wi-Fi leaderboard functionality while preserving authentic gameplay and original arcade hardware. Designed specifically for original Atari vector hardware, this plug and play upgrade improves long-term reliability without changing gameplay timing, controls, sound, or the classic arcade experience collectors expect. Original Arcade Hardware • No Emulation • No Gameplay Changes • Designed for Authentic Arcade PCBs View Install Guide Free Play Play without coins while retaining optional coin operation. High Score Saving Saves the Top 10 scores permanently with initials support. Attract Sounds Adjustable attract-mode sounds at 25%, 50%, or 100%. Optional Wi-Fi Upload scores online to global arcade leaderboards. Upgrade Your Space Duel Arcade Experience Restore and enhance your original Space Duel arcade machine with a professionally designed Free Play and High Score Save Kit built specifically for authentic Atari vector arcade hardware. Original boards often lose high scores, rely on aging components, or suffer from unstable resets. This upgrade modernizes your PCB while preserving the original gameplay, controls, timing, and vector arcade feel that made Space Duel one of Atari’s most recognizable color vector shooters. Unlike multigame systems or reproduction boards, this kit keeps your original arcade PCB intact while improving long-term reliability for collectors, operators, and restoration projects. Available Kit Options Build your kit exactly how you want it. Choose between a Wi-Fi Enabled Kit or a Standard Save Kit. Optional processor and socket upgrades are also available to simplify installation on original hardware. Important Installation Notes Socketed 6502 required: Install a 40-pin socket if your processor is soldered directly to the PCB Review the Space Duel Installation Guide before installing Included Features Easy Installation: No soldering, board modifications, or special wiring required Permanent Score Saving: Uses serial EEPROM instead of batteries or NVRAM High Score Save: Saves the Top 10 scores with initials Attract Sounds: Adjustable at 25%, 50%, or 100% of attract rotation Freeplay Mode: No more coins or opening the coin door Coin-Up Support: Continue using quarters or tokens if desired Attract Mode Protection: Helps reduce vector monitor burn-in by minimizing static screens Copyright Selection: Choose original manufacturer or HighScoreSaves branding On-Screen DIP Settings: Menu-driven configuration with no cabinet access needed ROM Saver: Remove original program ROMs while the program runs directly from the kit Cabinet Compatibility: Works in Upright and Cocktail cabinets Backup and Restore: Save and restore high scores anytime Reset Button: Restart the game without powering off when enabled through the menu Separate Score Tables: Independent high-score tables for 2, 3, 4, and 5 lives Fast Boot: Skip lengthy initialization sequences Stealth Mode: Boots directly into gameplay mode Installation Information Installation Difficulty: Easy Soldering Required: No, if CPU is socketed Processor Requirement: Requires a 6502 processor Socketed CPU Required: Install a 40-pin socket if needed Cabinet Compatibility: Upright and Cocktail supported Installation Guide: Download PDF Installation Guide Optional Wi-Fi Features and Online Leaderboards Learn About Wi-Fi Enabled Kits Upgrade to a Wi-Fi Enabled Kit to upload scores online and compete against players around the world, locally within your arcade, or across your own connected cabinet network. Standard kits save scores locally to the PCB, while Wi-Fi kits add automatic online score syncing through the HighScoreSaves global leaderboard platform. View Global Arcade High Scores Space Duel Free Play and High Score Save Kit FAQ Do I need to solder anything? No. This kit is fully plug-and-play with no board modifications required. Does it save high scores permanently? Yes. Scores are stored in EEPROM and remain saved when powered off. How many high scores are saved? The Top 10 scores with initials are saved permanently. Does it support attract sounds? Yes. Enable attract sounds at 25%, 50%, or 100% rotation frequency. Can I use Freeplay mode? Yes. Freeplay mode is fully supported. Does Coin-Up still work? Yes. Coin-Up continues working normally if desired. Does it support Upright and Cocktail cabinets? Yes. Compatible with both cabinet styles. What is Stealth Mode? Stealth Mode boots directly into gameplay while skipping menu screens. What CPU is required? A socketed 6502 processor is required. Where can I download the installation guide? Space Duel Installation Guide PDF Designed and supported by HighScoreSaves for arcade collectors, restorers, and original hardware enthusiasts. Resources 1. Space Duel Installation Guide PDF 2. Setup Tips and Configuration Guide 3. HighScoreSaves YouTube Channel 4. HighScoreSaves Facebook Page 5. HighScoreSaves eBay Store
Details and Benefits
The Space Duel Free Play and High Score Save Kit is designed for original arcade hardware to address common issues like lost high scores, unreliable resets, and limited configuration options. This upgrade brings modern reliability without changing the classic dual-stick vector shooter experience that Space Duel is known for.
What This Kit Adds
- Free Play support — Enable coin-free operation while still supporting traditional coin play
- Reliable high score saving — Permanent score storage using non-volatile memory
- On-screen settings menu — Adjust gameplay and kit options without opening the cabinet
- Monitor-friendly attract behavior — Helps reduce static attract screen burn-in
- Cabinet compatibility — Works with Upright arcade cabinets
Advanced Features
- High score backup and restore — Save and reload score data as needed
- Separate score tables — Independent tables based on configuration settings
- Optional Wi-Fi support — Upload and sync high scores online
Important Installation Notes
This kit requires a compatible socketed CPU. Always review the installation guide prior to installation to ensure correct setup and reliable operation.
Optional Wi-Fi enabled versions allow scores to be uploaded online and synced to your personal player page in addition to local high score saving on the PCB.
