Super Multipede Multigame Kit for Original Atari Millipede Hardware
Upgrade a documented compatible original Atari Millipede arcade PCB with the Super Multipede Multigame Free Play and High Score Save Kit, adding Centipede, Millipede, Super Breakout, and Warlords with Free Play, permanent score saving, menu-driven settings, serial EEPROM storage, ROM Saver support, and optional Wi-Fi leaderboard support.
This is an original-hardware arcade PCB upgrade, not an emulation platform, reproduction board, or generic multicade replacement. The kit installs on compatible Millipede hardware and expands the cabinet into a four-game Atari multigame setup while preserving the original arcade PCB platform.
Super Multipede Four-Game Atari Multigame Upgrade
A focused multigame upgrade for original Millipede PCBs that adds supported Atari classics, high score saving, Free Play, attract-sound options, and operator settings without replacing the original arcade board platform.
- Designed for documented compatible original Atari Millipede arcade PCBs
- Includes Centipede, Millipede, Super Breakout, and Warlords
- Centipede and Millipede save the Top 8 scores
- Super Breakout and Warlords save the Top 5 scores
- Separate score tables for supported game and configuration settings
- Free Play with traditional Coin-Up operation available
- Warlords operates in Free Play mode only
- Serial EEPROM score storage with no batteries required
- Attract sounds adjustable at 25%, 50%, or 100% per game
- Menu-driven DIP settings and game-selection menu
- ROM Saver support for removing original program ROMs from 1H through 1M
- Optional 2.4 GHz Wi-Fi leaderboard support
Game Selection and Settings Menu Access
During attract mode, hold Player 1 Start for approximately four seconds, then release it, to open the game-select menu.
To access supported HighScoreSaves settings, hold Player 1 Start while turning the cabinet on. Release the button when the on-screen prompt tells you to continue.
Verify Millipede PCB Compatibility Before Ordering
- This Super Multipede kit installs on a documented compatible original Atari Millipede PCB only.
- A 6502 processor is required for installation.
- The original 6502 is removed, installed on the HighScoreSaves daughter card, and the kit is installed where the 6502 was located.
- No soldering is required when the 6502 location already has a compatible 40-pin socket.
- The kit includes a 6502 main daughter card, graphics daughter card, and ribbon cable.
- The graphics character set daughter card installs at the documented 5P and 5R locations.
- Review the installation guide before setup and verify processor orientation, socket condition, ribbon cable placement, graphics daughter card placement, and all installation steps before restoring cabinet power.
Read more below
Super Multipede Kit Details and Benefits
The Super Multipede Multigame Free Play and High Score Save Kit upgrades documented compatible original Atari Millipede arcade hardware with Centipede, Millipede, Super Breakout, and Warlords. It adds Free Play, permanent score saving, menu-driven settings, serial EEPROM storage, ROM Saver support, attract-sound options, backup and restore, and optional Wi-Fi leaderboard support.
This is an original-hardware Millipede PCB upgrade. It is built for collectors, restorers, and operators who want to expand a Millipede cabinet while keeping the original arcade PCB platform instead of replacing it with an emulator, reproduction board, or generic multicade system.
Main Super Multipede Multigame Features
- Four games included: Play Centipede, Millipede, Super Breakout, and Warlords.
- Millipede PCB support: Installs on a documented compatible original Atari Millipede arcade PCB only.
- Permanent score saving: Centipede and Millipede save the Top 8 scores; Super Breakout and Warlords save the Top 5 scores.
- Separate score tables: Maintains separate supported score tables for Centipede, Millipede, and Super Breakout.
- Serial EEPROM storage: Saves supported scores and settings without batteries or NVRAM.
- Free Play: Start supported games without inserting coins.
- Coin-Up operation: Continue using traditional coin operation when enabled.
- Warlords note: Warlords operates in Free Play mode only and supports one-player play due to hardware limitations.
- Attract sounds: Set supported attract sounds at 25%, 50%, or 100% per game.
- Menu-driven DIP settings: Adjust supported settings without opening the cabinet.
- Backup and restore: Save and restore supported high-score data when needed.
- Reset button support: Restart supported gameplay without powering off when enabled in the menu.
- Stealth Mode: Choose whether the kit boots to the last played game or a fixed startup game.
- ROM Saver support: Remove original program ROMs from 1H through 1M so the program runs from the kit.
- Cabinet support: Works in upright or cocktail configurations, with Centipede and Millipede screen flipping supported in cocktail mode.
- Optional Wi-Fi: Add supported online score submission while retaining local score saving.
Game Selection and Settings Menu Access
During attract mode, hold Player 1 Start for approximately four seconds, then release it, to open the game-select menu.
To access supported HighScoreSaves settings, hold Player 1 Start while turning the cabinet on. Release the button when the on-screen prompt tells you to continue.
Included Games and Score Saving
Super Multipede includes Centipede, Millipede, Super Breakout, and Warlords. Centipede and Millipede save the Top 8 scores, while Super Breakout and Warlords save the Top 5 scores.
Supported scores and settings are stored through serial EEPROM instead of batteries or NVRAM. This gives the cabinet reliable local score retention while keeping the original Atari Millipede PCB as the core hardware platform.
Separate supported score tables are available for Centipede, Millipede, and Super Breakout. Warlords is included as a Free Play only mode and is limited to one-player support because of the hardware setup.
Free Play, Coin-Up, Attract Sounds, and Cabinet Support
Free Play allows supported games to start without inserting coins. Traditional Coin-Up operation can still be used when enabled, except for Warlords, which operates in Free Play mode only.
Attract-sound settings can be adjusted per game at 25%, 50%, or 100%. The kit also supports attract mode behavior that helps reduce static screen burn by avoiding completely static idle screens.
The kit supports upright and cocktail cabinet configurations. In cocktail mode, Centipede and Millipede can flip the screen correctly, while Super Breakout and Warlords use the Player 1 side controls.
Installation and PCB Requirements
- This Super Multipede multigame kit installs on a documented compatible original Atari Millipede PCB only.
- A 6502 processor is required for installation.
- The kit includes a 6502 main daughter card, graphics daughter card, and ribbon cable.
- The original 6502 is removed from the PCB, installed on the main daughter card, and the daughter card is installed where the 6502 was located.
- If the 6502 is not already socketed, a compatible 40-pin socket must be installed before using the kit.
- The graphics character set daughter card installs at the documented 5P and 5R locations.
- The included ribbon cable connects the main daughter card to the graphics daughter card.
- A riser socket may be needed for clearance near the Millipede PCB test points.
- ROM Saver support allows the original program ROMs from 1H through 1M to be removed after the kit is installed.
- Review the installation guide before setup and verify processor orientation, socket condition, ribbon cable placement, graphics daughter card placement, board clearance, and all installation steps before restoring cabinet power.
Standard and Optional Wi-Fi Versions
Standard kits save supported scores, settings, and configuration data locally to the PCB. An internet connection is not required for gameplay, Free Play, Coin-Up operation, game selection, or local score saving.
Optional 2.4 GHz Wi-Fi kits include the same local features and add supported online score submission through the HighScoreSaves leaderboard platform.
Wi-Fi can be disabled without affecting local gameplay, Free Play, Coin-Up operation, score saving, game selection, or settings-menu operation.
Super Multipede Multigame Kit FAQ
Which PCB is required?
This kit installs on a documented compatible original Atari Millipede PCB only.
Which games are included?
The kit includes Centipede, Millipede, Super Breakout, and Warlords.
How many scores are saved?
Centipede and Millipede save the Top 8 scores. Super Breakout and Warlords save the Top 5 scores.
Does it support Free Play and Coin-Up?
Yes. Free Play and Coin-Up are supported for the applicable games. Warlords operates in Free Play mode only.
Does Warlords support four players?
No. Warlords is limited to one-player support on this kit because of hardware limitations.
How do I select a game?
During attract mode, hold Player 1 Start for approximately four seconds, then release it, to open the game-select menu.
How is the settings menu opened?
Hold Player 1 Start while turning the cabinet on. Release the button when the on-screen prompt tells you to continue.
What CPU is required?
A socketed 6502 processor is required. If the processor is not socketed, a compatible 40-pin socket must be installed first.
Is Wi-Fi required?
No. Standard kits save supported scores locally. Wi-Fi is optional for online leaderboard support.
