Upgrade Your Asteroids Arcade Experience
Bring modern convenience to your original Asteroids arcade hardware with our collection of Asteroids Free Play and High Score Save Kits. These plug-and-play upgrades add reliable high score saving, Free Play functionality, and an on-screen settings menu—no cabinet disassembly or DIP switch changes required.
Related Arcade Kits You May Also Like:
Battlezone |
Space Duel |
Gravitar |
Tempest |
Warlords
Asteroids Free Play and High Score Save Kit
Asteroids Free Play and High Score Save Kit for Atari Arcade PCB Upgrade your original Atari Asteroids arcade PCB with reliable free play, high score saving, attract mode protection, and optional Wi-Fi leaderboard support while preserving authentic gameplay and original vector arcade hardware. Designed specifically for original Atari hardware, this plug and play upgrade improves long-term reliability without changing gameplay, timing, sound, or the classic vector arcade experience collectors expect. Original Arcade Hardware • No Emulation • No Gameplay Changes • Designed for Authentic Arcade PCBs View Install Guide Free Play Play without coins while retaining optional coin operation. High Score Saving Stores the Top 10 scores using reliable serial EEPROM. Optional Wi-Fi Upload scores online to global arcade leaderboards. Original Hardware Designed for authentic Atari vector arcade PCB gameplay. Upgrade Your Asteroids Arcade Experience Restore and enhance your original Asteroids arcade machine with a professionally designed Free Play and High Score Save Kit built specifically for authentic Atari vector arcade hardware. Original boards often lose high scores, rely on aging components, or suffer from unstable resets. This upgrade modernizes your PCB while preserving the original gameplay, vector graphics, sound effects, and arcade feel that made Asteroids one of Atari’s most iconic classics. Unlike multigame systems or replacement hardware, this kit keeps your original arcade PCB intact while improving long-term reliability for collectors, operators, and restoration projects. Included Features Easy Installation: Plug-and-play with no soldering required High Score Save: Stores the Top 10 scores Permanent Score Preservation: Reliable serial EEPROM storage Free Play Mode: Works with or without coin operation Coin Up Support: Retains authentic coin functionality Attract Mode Protection: Helps prevent vector monitor burn-in Customizable Screen Copyright: Manufacturer or HighScoreSaves branding Menu-Driven DIP Settings: Configure settings without opening the cabinet ROM Saver: Optionally remove original ROMs to reduce power usage Cabinet Compatibility: Works in Upright and Cocktail cabinets Selectable Wiring: Supports Asteroids OR Asteroids Deluxe Backup and Restore Scores: Perfect for tournaments and score events Reset Button: Restart the game without powering off the cabinet Separate Score Tables: Different score tables based on lives selected Installation Information Installation Difficulty: Easy Soldering Required: Only if your 6502 CPU is not socketed Socketed 6502 Required: Install a 40-pin socket if soldered directly to the PCB Cabinet Compatibility: Upright and Cocktail cabinets supported ROM Compatibility: Requires Version 2 Vector ROM Installation Guide: Download PDF Installation Guide Optional Wi-Fi Features and Online Leaderboards Learn About Wi-Fi Enabled Kits Upgrade to a Wi-Fi Enabled Kit to upload scores online and compete against players around the world, locally within your arcade, or across your own connected cabinet network. Standard kits save scores locally to the PCB, while Wi-Fi kits add automatic online score syncing through the HighScoreSaves global leaderboard platform. View Global Arcade High Scores Asteroids Free Play and High Score Save Kit FAQ Does this kit require soldering? Only if your 6502 CPU is not socketed. What’s the difference between Wi-Fi and Standard kits? Wi-Fi kits upload scores online while Standard kits save scores locally only. How many scores are saved? The kit stores the Top 10 high scores. Does Free Play disable coin operation? No. Free Play and Coin Up functionality work together. Is my cabinet compatible? Yes. This kit supports Upright and Cocktail cabinets. What is ROM Saver? ROM Saver allows you to remove original ROMs to help reduce PCB power usage. Where can I download the installation guide? Download the Asteroids Installation Guide PDF Designed and supported by HighScoreSaves for arcade collectors, restorers, and original hardware enthusiasts. Resources 1. Asteroids Installation Guide PDF 2. Setup Tips and Configuration Guide 3. HighScoreSaves YouTube Channel 4. HighScoreSaves Facebook Page 5. HighScoreSaves eBay Store
Braze Asteroids Free Play High Score Save Kit
Braze Asteroids Free Play and High Score Save Kit — Features & Install 📄 Installation Guide (PDF) Key Features Installs in minutes — no special wiring or soldering required. Top 10 high scores and initials are saved permanently (no batteries ever). Extended scoring: maximum score increased from 99,990 to 9,999,990. Fix for the Atari REV2 bug that erased the last initial on the 10th score. Compatibility & Included Parts This kit targets the REV2 version of Asteroids. For proper compatibility, a REV2 vector EPROM is required. Refer to the install guide’s “Revisions” section to confirm whether your board is REV1 or REV2. Installation Overview Power down and open your cabinet to access the PCB. Carefully remove the 6502 CPU from the Asteroids board. Insert the 6502 CPU into the included daughter card. Plug the daughter card into the vacated 6502 CPU socket on the board. Power on and follow the install guide to verify operation. How to Clear High Scores Put the game into Self Test using the cabinet’s self-test switch. While in Self Test, press and hold all four buttons: Left, Right, Fire, and Thrust. The screen will display “ERASED” confirming the clear. (Same procedure as Asteroids Deluxe.) FAQ Where can I download the install guide? Download Install Guide (PDF) Do I need to solder anything? No. The kit installs without soldering or special wiring. How long does installation take? Typically just a few minutes with basic PCB handling. Will my scores survive power-off? Yes. The top 10 scores and initials are stored permanently with no batteries required. What is “extended scoring”? The kit raises the maximum score from 99,990 to 9,999,990 to prevent rollover at 100K. Which board revisions are supported? The kit is based on REV2. A REV2 vector EPROM is required and included. Use the install guide to check your current revision. Does it fix the missing last initial? Yes. It fixes the REV2 bug that erased the final initial on the 10th entry.
Details and Benefits
Looking for more technical details before purchasing? The information below outlines the full capabilities and installation requirements of the Asteroids Free Play and High Score Save Kit.
The Asteroids Free Play and High Score Save Kit is designed for original arcade hardware and addresses common issues found on aging boards, such as lost high scores, reset reliability, and limited configuration options. This upgrade delivers modern stability and convenience while preserving the original gameplay and presentation of this classic title.
What This Kit Adds
- Free Play with flexibility — Enable coin-free operation while still supporting traditional coin play
- Reliable score retention — High scores are stored permanently using non-volatile memory
- On-screen control menu — Adjust game options without opening the cabinet
- Monitor-friendly attract behavior — Helps reduce burn-in on CRT displays
- Cabinet compatibility — Supports Upright arcade cabinets
Advanced Features
- Backup and restore — Save and reload high score data as needed
- Separate score tables — Independent high score tables based on configuration settings
- Practice modes — Additional training features depending on game setup
Important Installation Notes
A socketed 6502 processor or compatible architecture is required. If your board is not already socketed, install the appropriate socket before using this kit. Always review the installation guide prior to installation to ensure correct setup and reliable operation.
Optional Wi-Fi enabled versions allow scores to be uploaded online and synced to your personal player page in addition to local high score saving on the PCB.
