Rush'n Attack Arcade PCB Upgrades for Original Konami Z80 Hardware
Research the HighScoreSaves Rush'n Attack upgrade for compatible original Konami arcade hardware. The kit installs at the documented Z80 processor location while keeping the original Konami PCB, controls, graphics hardware, sound hardware, and dedicated arcade platform in service.
HighScoreSaves documents this daughter-card installation for compatible Rush'n Attack and Green Beret PCBs. The shared hardware support explains why the same kit and installation guide cover both names, while this category remains focused specifically on Rush'n Attack hardware and upgrade compatibility.
This is an original-PCB upgrade rather than a replacement JAMMA board, reproduction PCB, generic multicade, or software-emulation platform.
Rush'n Attack | Green Beret Free Play and High Score Save Kit Installation Guide
Before ordering, verify that your cabinet contains a documented compatible original Konami Rush'n Attack PCB and confirm the Z80 processor and socket configuration shown in the installation guide. The existing game board should be fully working before the upgrade is installed.
Rush'n Attack Z80 and PCB Compatibility
The HighScoreSaves daughter card installs at the documented Z80B-CPU location. A compatible Z80 processor must be installed on the daughter card; the existing compatible processor may be reused, or a replacement may be selected when ordering.
- Designed for documented compatible original Konami Rush'n Attack hardware
- Installation documentation also supports compatible Green Beret PCB hardware
- Uses a Z80 processor mounted on the HighScoreSaves daughter card
- Requires a compatible socketed 40-pin Z80 processor location
- Original program ROM removal is optional when using the documented ROM Saver configuration
HighScoreSaves designs and supports Rush'n Attack upgrades for documented compatible original Konami arcade PCBs using Z80 processor hardware.
Understanding the Rush'n Attack Original PCB Upgrade
The Rush'n Attack kit adds supported upgrade functionality while continuing to use compatible original Konami arcade hardware. The HighScoreSaves daughter card interfaces through the original Z80 processor location rather than replacing the complete game PCB.
For an original-hardware installation, identifying the actual PCB and processor configuration is more useful than relying only on cabinet artwork or the game name shown externally. Converted or repaired cabinets may contain hardware that differs from what was originally installed.
Rush'n Attack and Green Beret PCB Compatibility
HighScoreSaves uses one installation guide and daughter-card design for documented compatible Rush'n Attack and Green Beret arcade PCBs. Both supported configurations use the Z80 installation method documented for this kit.
The shared compatibility does not require combining the Rush'n Attack and Green Beret category pages. Each category can answer searches for its own game name while directing compatible hardware owners to the same HighScoreSaves product.
Z80 Processor and Daughter-Card Installation
The installation guide identifies the original processor position as the Z80B-CPU location. The Z80 is removed from the PCB socket and installed on the HighScoreSaves daughter card, and the completed daughter card is then installed into the original processor socket.
Correct processor orientation and daughter-card seating are important. Before restoring cabinet power, verify Pin 1 orientation, inspect the CPU socket and processor pins, and make sure nothing on the original PCB is contacting the underside of the new daughter card.
What If the Z80 Is Not Socketed?
The daughter card requires a compatible socketed Z80 processor location. If the processor is soldered directly to the PCB, a compatible 40-pin socket must be installed before the kit can be fitted.
Rush'n Attack ROM Saver Configuration
The installation guide includes an optional ROM Saver configuration. The designated original program ROMs may be removed after the daughter card is installed as directed. ROM removal is optional rather than a requirement for the basic installation.
If original program ROMs are removed, store them safely and record their original PCB locations so the board can be returned to its previous configuration later if desired.
Original Konami PCB vs. Replacement Hardware
The HighScoreSaves upgrade keeps the documented compatible original Konami PCB as the underlying game platform. It does not replace the machine with a generic multicade, replacement JAMMA board, reproduction PCB, or software-emulation system.
Why Keep the Original Rush'n Attack PCB?
- Retains compatible original Konami arcade hardware in the cabinet
- Keeps the original Rush'n Attack PCB as the operating game platform
- Continues using the original Z80-based processor architecture
- Adds supported functionality through a removable daughter-card upgrade
- Avoids replacing the game board with a generic multicade or emulation platform
What to Check Before Ordering the Rush'n Attack Kit
Vintage arcade cabinets may have been repaired, converted, or fitted with replacement components during decades of service. Inspect the actual PCB before ordering.
- Confirm that the cabinet contains documented compatible original Konami Rush'n Attack hardware
- Verify that the existing game board is fully working before installation
- Locate the documented Z80B-CPU position
- Confirm that a compatible Z80 processor is present or select a replacement when ordering
- Confirm that the Z80 processor location has a suitable 40-pin socket
- Inspect the processor pins, CPU socket, nearby test points, traces, and components for previous damage or repairs
- Review the Rush'n Attack | Green Beret Installation Guide before ordering or beginning installation.
After confirming compatible original Rush'n Attack hardware, visit the Rush'n Attack | Green Beret Free Play and High Score Save Kit product page for current pricing, Top 10 score saving, Free Play, score-table options, God Mode, graphics selection, Standard and Wi-Fi versions, configuration choices, and ordering.
