Galaga High Score Save Kit Compatibility

Confirm whether your original Galaga arcade PCB is compatible with the HighScoreSaves Galaga Free Play and High Score Save Kit. The current installation documentation shows supported Midway, Namco, and a documented Galag bootleg PCB layout, with different installation details depending on which board is installed in your cabinet.

Before You Order
Hardware: Compare your PCB with the documented Midway, Namco, or Galag bootleg layouts shown in the current Galaga installation guide
Processor: A compatible Z80 is required and must be installed in a suitable 40-pin socket for transfer to the HighScoreSaves daughterboard
Installation: Installation location differs by PCB; the guide identifies Midway at 3HJ, Namco at 3F, and a bootleg-specific 2732 EPROM installation at J4 rather than K4
Galaga Free Play and High Score Save Kit

Galaga Free Play and High Score Save Kit

From $75.00
Details

Choosing the Correct Galaga Arcade PCB Upgrade

The HighScoreSaves Galaga high score save kit is designed for documented compatible original Galaga arcade hardware. The current installation guide illustrates three different PCB layouts, and the physical installation details are not identical between them.

Before ordering, identify the exact board in the cabinet, locate the Z80 processor, confirm that the required locations are properly socketed, and compare your board directly with the current installation guide.

Documented Galaga PCB Compatibility

Midway Galaga PCB The current installation guide illustrates the Midway Galaga CPU board as one of the supported layouts. The documented secondary installation location is identified at 3HJ.
Namco Galaga PCB The current guide separately illustrates the Namco CPU board. Its documented corresponding installation location is identified at 3F.
Documented Galag Bootleg PCB A specific Galag bootleg PCB is also illustrated in the current guide. This layout has additional installation instructions and should not be treated as proof that every Galaga clone or reproduction PCB is compatible.

Galaga Z80 Processor Requirements

The Galaga kit requires a compatible Z80 processor. The current installation guide documents transferring the existing Z80 from the original PCB to the HighScoreSaves Z80 daughter card.

Pin 1 orientation must be maintained when the processor is moved to the daughterboard. The completed daughterboard is then installed into the documented Z80 socket on the original Galaga PCB.

If the required Z80 is soldered directly to the arcade PCB instead of installed in a compatible 40-pin socket, proper processor removal and socket installation are required before fitting the kit.

PCB-Specific Installation Differences

Midway — 3HJ The current guide identifies the documented Midway installation location at 3HJ. Use the current PCB photograph to confirm orientation before installing any daughterboard or supplied component.
Namco — 3F The corresponding documented Namco location is 3F. Do not assume the Midway and Namco board layouts place components in the same physical locations.
Galag Bootleg — 2732 at J4 The current guide instructs the installer to place the additional supplied 2732 EPROM at J4, not K4, on the documented Galag bootleg PCB. The appropriate bootleg option must also be selected in the kit menu.
Check Daughterboard Clearance The guide specifically instructs installers to make sure no original PCB component or test point contacts the underside of the installed daughterboard.

Galaga Pre-Order Compatibility Checklist

1. Identify the Galaga PCB Compare the board directly with the documented Midway, Namco, or Galag bootleg layouts in the current installation guide.
2. Confirm the Original PCB Works Verify that the game board is fully operational before installing the HighScoreSaves hardware. Existing board faults should be repaired first.
3. Locate and Inspect the Z80 Confirm the correct Z80 location, processor orientation, socket condition, and whether the processor can be safely removed.
4. Identify the Secondary Installation Location Follow the correct hardware path for Midway 3HJ, Namco 3F, or the documented bootleg installation rather than assuming all Galaga boards are laid out alike.
5. Review the Complete Installation Guide Check Pin 1 orientation, daughterboard clearance, the supplied 2732 EPROM instructions, and all PCB-specific locations before restoring cabinet power.

After Confirming Galaga PCB Compatibility

Once the PCB type, Z80 processor, socket condition, secondary installation location, and any bootleg-specific requirements have been confirmed, use the individual product page for the complete feature list, Standard and Wi-Fi versions, CPU and socket options, included components, current pricing, and ordering information.

This category is intended primarily to determine whether your original Galaga hardware is suitable for the HighScoreSaves Galaga Free Play and High Score Save Kit before ordering.

Galaga PCB Compatibility FAQ

How many Galaga PCB layouts are shown in the current guide?

Three: a Midway CPU board, a Namco CPU board, and a documented Galag bootleg PCB.

Does that mean every Galaga clone is compatible?

No. Compatibility should be confirmed against the documented PCB layouts shown in the current guide. Do not assume every clone or reproduction board uses a supported layout.

Which processor is required?

A compatible Z80 processor is required and is installed on the HighScoreSaves Z80 daughter card.

What are the Midway and Namco installation locations?

The current guide identifies Midway at 3HJ and Namco at 3F.

What is different about the documented Galag bootleg PCB?

The guide documents installation of an additional supplied 2732 EPROM at J4, not K4, and requires the appropriate bootleg menu setting.

Does installation require soldering?

No soldering is normally required when the documented installation locations are properly socketed. A soldered required processor must be professionally removed and socketed before installation.
