Tapper | Timber Multigame Free Play and High Score Save Kit for Original Bally Midway Hardware
Upgrade documented compatible original Bally Midway Tapper or Timber arcade PCBs with the Tapper | Timber | Root Beer Tapper Multigame Free Play and High Score Save Kit, adding Tapper, Timber, Root Beer Tapper, and Simpsons Tapper with Free Play, permanent score saving, menu-driven settings, serial EEPROM storage, ROM Saver support, cabinet-aware control mapping, and optional Wi-Fi leaderboard support.
This is an original-hardware arcade PCB upgrade, not an emulation platform, reproduction board, or generic multicade replacement. The kit preserves the original Tapper and Timber cabinet experience while adding four supported game options, score-saving reliability, and operator-friendly configuration features.
Tapper | Timber Four-Game Multigame Upgrade
A focused Bally Midway multigame upgrade for original Tapper or Timber hardware that adds supported game selection, Free Play, score saving, attract-sound control, selectable boot game, and cabinet-aware controls.
- Designed for documented compatible original Bally Midway Tapper or Timber arcade PCBs
- Includes Tapper, Timber, Root Beer Tapper, and Simpsons Tapper
- Saves Top 10 scores with optional Top 3 support
- Separate high score tables for each game and menu setup
- Free Play with traditional Coin-Up operation available
- Serial EEPROM score storage with no batteries required
- Attract sounds adjustable at 25%, 50%, or 100%
- Menu-driven settings and menu lock support
- Selectable boot game for Tapper, Timber, Root Beer Tapper, or Simpsons Tapper
- ROM Saver support for optional original program ROM removal
- Supports upright, cocktail, and cabaret cabinet configurations
- Optional 2.4 GHz Wi-Fi leaderboard support
Cabinet-Aware Control Mapping
Control behavior changes automatically depending on whether the kit is installed in a Tapper or Timber cabinet, helping each supported game play correctly with the available control panel.
When installed in a Tapper cabinet, Timber is supported as a one-player game using Tap plus joystick direction for chopping. When installed in a Timber cabinet, Tapper uses the Player 1 joystick and the chop controls act as tap inputs.
Verify Tapper or Timber PCB Compatibility Before Ordering
- This kit is designed for documented compatible original Tapper or Timber arcade PCBs.
- A socketed Z80 processor is required for installation.
- No soldering is required when the Z80 location already has a compatible 40-pin socket.
- Cabinet behavior depends on whether the kit is installed in a Tapper or Timber cabinet.
- Timber supports two-player simultaneous play when installed in a Timber cabinet.
- Review the installation guide before setup and verify processor orientation, socket condition, cabinet control layout, ROM Saver options, and all installation steps before restoring cabinet power.
Read more below
Tapper | Timber Multigame Kit Details and Benefits
The Tapper | Timber | Root Beer Tapper Multigame Free Play and High Score Save Kit upgrades documented compatible original Tapper or Timber arcade hardware with four supported games, Free Play, permanent score saving, menu-driven settings, serial EEPROM storage, attract-sound options, ROM Saver support, Backup and Restore, selectable boot game, menu lock, and optional Wi-Fi leaderboard support.
This is an original-hardware upgrade for Bally Midway Tapper and Timber cabinet owners who want multigame support without replacing the original arcade PCB with an emulator, reproduction board, or generic multicade system.
Main Tapper | Timber Multigame Features
- Four games included: Play Tapper, Timber, Root Beer Tapper, and Simpsons Tapper.
- Original hardware support: Designed for documented compatible original Tapper or Timber arcade PCBs.
- Permanent score saving: Saves Top 10 scores with optional Top 3 support.
- Separate score tables: Keeps individual tables for each supported game and menu setup.
- Serial EEPROM storage: Saves supported scores and settings without batteries or failure-prone NVRAM.
- Free Play: Start supported games without inserting coins.
- Coin-Up operation: Continue using traditional coins or tokens when desired.
- Attract sounds: Set supported attract sounds at 25%, 50%, or 100%.
- Menu-driven settings: Adjust supported options directly from the on-screen menu.
- Selectable boot game: Choose Tapper, Timber, Root Beer Tapper, Simpsons Tapper, or the last played game.
- High scores button: Quickly view saved score tables for the selected game.
- All global high scores button: Useful for Wi-Fi enabled leaderboard support.
- Menu lock: Help protect settings from guests or accidental changes.
- Stealth Mode: Boot directly into the last played or selected game.
- ROM Saver support: Original program ROMs may be removed and stored safely.
- Cabinet compatibility: Supports upright, cocktail, and cabaret cabinet configurations.
- Optional Wi-Fi: Add supported online score submission while retaining local score saving.
Tapper and Timber Cabinet Control Mapping
The kit maps controls so each game plays correctly with the installed control panel. This is especially important because Tapper and Timber cabinets use different physical controls.
In a Tapper cabinet, Timber is supported as a one-player game. Tap plus joystick left chops left, and Tap plus joystick right chops right.
In a Timber cabinet, Tapper uses the Player 1 joystick, and the left/right chop controls act as tap inputs. Timber supports two-player simultaneous play when installed in a Timber cabinet.
Included Games and Score Saving
The Tapper | Timber Multigame kit includes Tapper, Timber, Root Beer Tapper, and Simpsons Tapper. Each supported game can use its own saved score table and menu setup.
The kit saves Top 10 scores by default and supports optional Top 3 score-saving behavior. Supported scores and settings are stored locally using serial EEPROM instead of batteries or NVRAM.
Backup and Restore support allows saved score data to be preserved before service work, events, parties, transport, or testing.
Free Play, Coin-Up, Attract Sounds, and Boot Options
Free Play allows the supported games to start without inserting coins. Traditional Coin-Up operation can still be used when desired, preserving flexibility for home arcades, collectors, routed games, and events.
Attract sounds can be configured at 25%, 50%, or 100%. Attract mode protection helps reduce static screen burn during idle periods while still preserving the classic game presentation.
Selectable boot-game support lets the cabinet owner choose Tapper, Timber, Root Beer Tapper, Simpsons Tapper, or the last played game at startup. Menu lock and Stealth Mode help control what players and guests can access.
Installation and PCB Requirements
- Designed for documented compatible original Tapper or Timber arcade PCBs.
- A socketed Z80 processor is required for installation.
- No soldering is required when the required Z80 location already has a compatible 40-pin socket.
- If the processor is soldered directly to the PCB, a compatible 40-pin socket must be installed before using the kit.
- Cabinet behavior depends on whether the kit is installed in a Tapper or Timber cabinet.
- Timber is one-player only when played through a Tapper cabinet control layout.
- Timber supports two-player simultaneous play when installed in a Timber cabinet.
- ROM Saver support allows documented original program ROM removal after the kit is installed.
- Review the installation guide before setup and verify processor orientation, socket condition, cabinet control layout, ROM Saver steps, and all installation work before restoring cabinet power.
Standard and Optional Wi-Fi Versions
Standard kits save supported scores and settings locally. An internet connection is not required for gameplay, Free Play, Coin-Up operation, game selection, or local score saving.
Optional 2.4 GHz Wi-Fi kits include the same local features and add supported online score submission through the HighScoreSaves leaderboard platform.
Wi-Fi can be disabled without affecting local gameplay, Free Play, Coin-Up operation, score saving, game selection, or menu operation.
Tapper | Timber Multigame Kit FAQ
Which games are included?
The kit includes Tapper, Timber, Root Beer Tapper, and Simpsons Tapper.
Which PCB is required?
This kit is designed for documented compatible original Tapper or Timber arcade PCBs.
How many scores are saved?
The kit saves Top 10 scores by default and supports optional Top 3 score-saving behavior.
How does control mapping work?
The kit automatically adjusts control behavior depending on whether it is installed in a Tapper or Timber cabinet.
Does Timber support two-player simultaneous play?
Yes, when the kit is installed in a Timber cabinet. Timber is one-player only when played through a Tapper cabinet control layout.
Does it support Free Play and Coin-Up?
Yes. Free Play and traditional Coin-Up operation are both supported.
What processor is required?
A socketed Z80 processor is required.
Can I choose which game boots first?
Yes. The kit supports selectable boot-game behavior for Tapper, Timber, Root Beer Tapper, Simpsons Tapper, or the last played game.
Is Wi-Fi required?
No. Standard kits save supported scores locally. Wi-Fi is optional for online leaderboard support.
