Bump 'n Jump Arcade PCB Upgrade Overview for Original Data East Hardware
Review the available HighScoreSaves upgrade option for compatible original Data East Bump 'n Jump arcade PCBs, including permanent high score saving, installation requirements, hardware compatibility, serial EEPROM storage, ROM Saver support, upright/cocktail cabinet support, Coin-Up operation, and optional Wi-Fi leaderboard support.
This category is intended for collectors, operators, and restoration projects using original Bump 'n Jump arcade hardware. The upgrade keeps the original Data East PCB in service rather than replacing the cabinet with an emulation platform, reproduction board, or generic multicade system.
Bump 'n Jump installation requires the original encrypted 6502 processor C10707-1 installed in a compatible 40-pin socket. No soldering is required when the encrypted 6502 processor location is already socketed.
Bump 'n Jump Hardware Compatibility and High Score Save Features
The Bump 'n Jump kit is designed for original Data East arcade hardware and adds modern score-saving reliability, long-term serial EEPROM storage, ROM Saver support, and optional leaderboard support while preserving the original Bump 'n Jump gameplay, timing, controls, sound, and classic Coin-Up arcade behavior.
- Designed for compatible original Data East Bump 'n Jump arcade PCBs
- Coin-Up operation only; Free Play is not available on this kit
- Stores up to 150 scores
- Displays the Top 5 scores on screen
- Reliable serial EEPROM storage with no batteries or failure-prone NVRAM required
- Requires the original encrypted 6502 processor C10707-1
- Requires a compatible 40-pin CPU socket
- ROM Saver support for optional original program ROM removal
- Upright and cocktail cabinet support
- Optional Wi-Fi leaderboard support
View Bump 'n Jump High Score Save Kit
View/Download Bump 'n Jump Install Guide (PDF)
Before ordering: confirm that your machine contains a documented compatible original Data East Bump 'n Jump arcade PCB, the required original encrypted 6502 processor C10707-1, and a compatible 40-pin CPU socket. If the encrypted 6502 processor is soldered directly to the PCB, a qualified arcade technician must install a compatible 40-pin socket before the kit can be used.
Important: this Bump 'n Jump kit is a High Score Save Kit for Coin-Up operation. It does not add Free Play mode.
Bump 'n Jump High Score Save Kit Details and Benefits
The HighScoreSaves Bump 'n Jump High Score Save Kit adds permanent high score saving, up to 150 stored scores, Top 5 on-screen score display, battery-free serial EEPROM storage, ROM Saver support, upright/cocktail cabinet support, Coin-Up operation, and optional Wi-Fi leaderboard support to documented compatible original Data East Bump 'n Jump arcade hardware.
This upgrade is designed for original Data East Bump 'n Jump arcade PCBs. It keeps the original board in service rather than replacing the cabinet with an emulation system, reproduction PCB, or generic multicade platform.
Important: Coin-Up Only
This Bump 'n Jump kit is a High Score Save Kit only. It supports coins and tokens like the original arcade hardware. Free Play mode is not available on this kit.
Main Bump 'n Jump Kit Features
- High score saving: Stores up to 150 scores.
- Top 5 on-screen display: Displays the Top 5 scores directly on screen.
- Battery-free storage: Uses reliable serial EEPROM storage instead of batteries or failure-prone NVRAM.
- Coin-Up operation: Supports coins and tokens like the original Data East arcade PCB.
- No Free Play: Free Play mode is not available on this Bump 'n Jump kit.
- Encrypted CPU requirement: Requires the original encrypted 6502 processor C10707-1.
- Socketed CPU requirement: Requires the encrypted 6502 processor to be installed in a compatible 40-pin socket.
- ROM Saver: Original program ROMs may optionally be removed when installed as directed.
- Upright and cocktail support: Supports documented upright and cocktail cabinet configurations.
- Optional Wi-Fi: Add qualifying online leaderboard score submission while keeping local score saving.
High Score Saving and Top 5 Display
The Bump 'n Jump kit stores up to 150 scores while displaying the Top 5 directly on screen. This gives the original arcade PCB modern score retention without replacing the board or changing the original gameplay.
Supported score data is stored using serial EEPROM, so batteries or failure-prone NVRAM are not required for saved scores.
The kit is useful for restored cabinets, collections, routes, events, and tournament setups where score retention matters but the original Data East cabinet experience needs to remain intact.
Data East Hardware, Coin-Up Operation, and ROM Saver
Bump 'n Jump uses original Data East arcade hardware, and this kit is intended for documented compatible original Bump 'n Jump arcade PCBs.
Coin-Up operation remains like the original arcade board. This kit does not add Free Play, so the cabinet should be operated with coins, tokens, or the cabinet's existing credit method.
ROM Saver support allows designated original program ROMs to be removed when the kit is installed as directed in the Bump 'n Jump installation guide.
Cabinet Support and Local Saving
Upright and cocktail cabinet configurations are supported when used with documented compatible original Data East Bump 'n Jump arcade hardware.
Standard kits save supported scores locally to the installed arcade PCB. Wi-Fi is optional and is not required for normal Bump 'n Jump gameplay, Coin-Up operation, Top 5 display, local score saving, or ROM Saver operation.
Installation and PCB Requirements
- Designed for documented compatible original Data East Bump 'n Jump arcade PCBs.
- Access to the original arcade PCB is required during installation.
- This kit requires the original encrypted 6502 processor C10707-1.
- The encrypted 6502 processor must be installed in a compatible 40-pin socket.
- If the encrypted 6502 processor is soldered directly to the PCB, a qualified arcade technician must remove the processor and install a compatible 40-pin socket before the kit can be used.
- Free Play is not available on this kit.
- Remove only the designated original program ROMs identified in the Bump 'n Jump installation guide when using ROM Saver features.
- Verify Pin 1 orientation, processor alignment, socket condition, board seating, ROM removal locations, and all processor pins before restoring cabinet power.
- Review the Bump 'n Jump installation guide before installation.
Standard and Optional Wi-Fi Versions
The Standard Kit saves supported scores locally to the PCB and does not require an internet connection for gameplay, Coin-Up operation, Top 5 score display, ROM Saver operation, or local score saving.
The optional Wi-Fi Enabled Kit includes the same local score-saving features and can submit qualifying scores to the HighScoreSaves online leaderboard.
Wi-Fi can be disabled without affecting Bump 'n Jump gameplay, Coin-Up operation, local score saving, Top 5 display, or ROM Saver operation.
Bump 'n Jump High Score Save Kit FAQ
Does the HighScoreSaves Bump 'n Jump kit support Free Play?
No. This kit is Coin-Up only. Free Play mode is not available on this kit.
How many scores does the Bump 'n Jump kit save?
The kit stores up to 150 scores while displaying the Top 5 directly on screen.
Which arcade PCB does the Bump 'n Jump kit support?
The kit is designed for documented compatible original Data East Bump 'n Jump arcade PCBs.
Which processor is required for the Bump 'n Jump kit?
The kit requires the original encrypted 6502 processor C10707-1.
Does the encrypted 6502 need to be socketed?
Yes. The encrypted 6502 processor must be installed in a compatible 40-pin socket. If it is soldered directly to the PCB, a qualified arcade technician must install a socket first.
What is ROM Saver on the Bump 'n Jump kit?
ROM Saver allows designated original program ROMs to be removed while the game program runs directly from the kit when installed as directed.
Does the Bump 'n Jump kit support upright and cocktail cabinets?
Yes. Upright and cocktail cabinet configurations are supported when used with documented compatible original Data East Bump 'n Jump hardware.
Is Wi-Fi required for the HighScoreSaves Bump 'n Jump kit?
No. Standard kits save supported scores locally. Wi-Fi is optional for online leaderboard support.
