Mario Bros Free Play and High Score Save Kits
Download Mario Bros Install Guide (PDF)
Upgrade Your Mario Bros Arcade Experience
Bring modern convenience to your original Mario Bros arcade hardware with our collection of Mario Bros Free Play and High Score Save Kits. These plug-and-play upgrades add reliable high score saving, Free Play functionality, and an on-screen settings menu while preserving the classic 2D platform arcade gameplay.
Related Arcade Kits You May Also Like:
Pac-Man |
Ms. Pac-Man |
Dig Dug |
Frogger |
Galaxian
Braze Mario Bros Free Play and High Score Save Kit
Braze Mario Bros. High Score Save Kit — Features & Install 📄 Installation Guide (PDF) Overview A simple-to-install high score save kit for Mario Bros. that permanently remembers the top 5 scores and initials and also saves your current Free Play setting. No batteries required. Installs in minutes—no special wiring or soldering is typically needed. Installation Summary Power down the cabinet and access the CPU board. Carefully remove the Z80 CPU from the Mario Bros. CPU board. Insert the Z80 into the included daughter card. Plug the daughter card into the vacated Z80 socket on the CPU board. Power on and follow the install guide to verify operation. Key Features Installs in minutes: no board modifications or special wiring. Top 5 High Score Save: remembers scores and initials permanently (no batteries). Free Play saved: preserves your Free Play setting; toggle via standard Mario Bros. test mode. Easy reset: clear the table in test mode by resetting the bookkeeping distributions. FAQ Where can I download the install guide? Mario Bros. Install Guide (PDF) Do I need to solder anything? Typically no. Most installations require no soldering or special wiring. How do I reset the high scores? Enter Mario Bros. test mode and clear the “bookkeeping distributions” to restore the default table. Is Free Play saved? Yes. The kit saves your current Free Play setting; enable or disable it in the standard test mode. Which CPU does this kit use? The kit interfaces with the Z80 CPU—remove the Z80, place it in the daughter card, then insert the card into the Z80 socket.
Mario Bros Free Play and High Score Save Kit
Mario Bros Free Play and High Score Save Kit for Nintendo Arcade PCBs Upgrade your original Mario Bros arcade PCB with reliable free play, high score saving, attract sounds, and optional Wi-Fi leaderboard functionality while preserving authentic gameplay and original arcade hardware. Designed specifically for original Nintendo hardware, this plug and play upgrade improves long-term reliability without changing gameplay timing, controls, sound, or the classic platform gameplay collectors expect. Original Arcade Hardware • No Emulation • No Gameplay Changes • Designed for Authentic Arcade PCBs View Install Guide Free Play Play without coins while still supporting traditional coin operation. Top 5 High Scores Permanently stores the Top 5 scores with initials. Attract Sounds Toggle attract sounds ON or OFF during attract mode. Optional Wi-Fi Upload scores online to global arcade leaderboards. Upgrade Your Mario Bros Arcade Experience Restore and enhance your original Mario Bros arcade machine with a professionally designed Free Play and High Score Save Kit built specifically for authentic Nintendo arcade hardware. Original boards often lose scores, rely on aging components, or suffer from unstable resets. This upgrade modernizes your PCB while preserving the original gameplay, controls, timing, and classic cooperative platform gameplay that made Mario Bros one of Nintendo’s most iconic arcade releases. Unlike emulation or reproduction hardware, this kit keeps your original arcade PCB intact while improving long-term reliability for collectors, operators, and restoration projects. Customize Your Mario Bros Free Play and High Score Save Kit Build your kit exactly how you want it. Choose a Wi-Fi Enabled Kit or a Standard Save Kit. You can also add a processor and/or a 40-pin socket—optional but recommended for easier installation. Important Installation Notes Socketed CPU Required: Your Z80 processor must be socketed for the kit to work Read the Mario Bros Installation Guide before setup Main Features Easy Install: No soldering, board modifications, or special wiring required Save Your Scores Forever: Uses reliable serial EEPROM instead of failure-prone NVRAM or batteries High Score Save: Saves the Top 5 scores with initials Attract Sounds: Toggle attract sounds ON or OFF during attract mode Free Play: Play with no coins required Coin Up: Still supports traditional coin operation Attract Mode: Minimizes static screens to reduce CRT burn-in Menu-Driven DIP Settings: Adjust DIP switches through the on-screen menu ROM Saver: Optionally remove original program ROMs to save power Cabinet Compatibility: Works in Upright and Cocktail cabinets Additional Features Backup and Restore: Save and reload scores for tournaments or parties Separate Score Tables: Independent score tables for 2, 3, or 4 lives settings Reset Button: Restart the game without powering off the cabinet Self-Test: Accessible through the menu or by setting all DIP switches OFF Installation Information Installation Difficulty: Easy Soldering Required: No, if CPU is socketed Processor Requirement: Requires a Z80 processor Socketed CPU Required: Install a 40-pin socket if needed Cabinet Compatibility: Upright and Cocktail supported Installation Guide: Download PDF Installation Guide Optional Wi-Fi Features and Online Leaderboards Learn About Wi-Fi Enabled Kits Upgrade to a Wi-Fi Enabled Kit to upload scores online and compete against players around the world, locally within your arcade, or across your own connected cabinet network. Standard kits save scores locally to the PCB, while Wi-Fi kits add automatic online score syncing through the HighScoreSaves global leaderboard platform. View Global Arcade High Scores Mario Bros Free Play and High Score Save Kit FAQ Does this kit permanently save high scores? Yes. Scores are saved using reliable serial EEPROM memory and remain stored even when powered off. Does the kit support Free Play and Coin Up? Yes. Run the cabinet in Free Play mode or keep traditional Coin Up enabled. Is soldering required? No soldering is required if your Z80 processor is socketed. Can I adjust DIP settings from the menu? Yes. Coinage, lives, and gameplay settings can be adjusted through the on-screen menu system. Does the kit support Backup and Restore? Yes. Save and restore high scores anytime, making it perfect for tournaments and parties. Does this require a socketed CPU? Yes. A socketed Z80 processor is required for installation. Where can I download the installation guide? Download the Mario Bros Installation Guide PDF Designed and supported by HighScoreSaves for arcade collectors, restorers, and original hardware enthusiasts. Resources 1. Mario Bros Free Play and High Score Save Kit — Installation Guide PDF 2. Setup Tips and Configuration Guide 3. HighScoreSaves YouTube Channel — Installation Tips 4. HighScoreSaves Facebook Page 5. HighScoreSaves eBay Store
Details and Benefits
The Mario Bros Free Play and High Score Save Kit is designed for original arcade hardware to solve common issues such as lost high scores, unreliable resets, and limited configuration options. This upgrade brings modern reliability and convenience while preserving the classic Mario Bros 2D arcade experience.
What This Kit Adds
- Free Play support — Enable coin-free operation while still supporting traditional coin play
- Reliable high score saving — Permanent high score storage using non-volatile memory
- On-screen control menu — Adjust game options without opening the cabinet
- Monitor-friendly attract behavior — Helps reduce static attract screen burn-in
- Cabinet compatibility — Supports Upright arcade cabinets
Advanced Features
- High score backup and restore — Save and reload score data as needed
- Separate score tables — Independent table based on configuration settings
- Optional Wi-Fi support — Upload and sync high scores online
Important Installation Notes
This kit requires a compatible socketed CPU. Always review the installation guide prior to installation to ensure correct setup and reliable operation.
Optional Wi-Fi enabled versions allow scores to be uploaded online and synced to your personal player page in addition to local high score saving on the PCB.
