Lost Tomb Arcade PCB Upgrade Overview for Original Stern Hardware
Review the available HighScoreSaves upgrade option for compatible original Stern Lost Tomb arcade PCBs, including Free Play, Top 10 high score saving, installation requirements, hardware compatibility, ROM Saver support, attract sounds, menu-driven settings, Disable Continues, Disable Advertising, and optional Wi-Fi leaderboard support.
This category is intended for collectors, operators, and restoration projects using original Lost Tomb arcade hardware. The upgrade keeps the original Stern PCB in service rather than replacing the cabinet with an emulation platform, reproduction board, or multicade system.
Lost Tomb installation requires a socketed Z80 processor. No soldering is required when the Z80 location is already socketed.
Lost Tomb Hardware Compatibility and Upgrade Features
The Lost Tomb kit is designed for original Stern arcade hardware and adds modern reliability, score saving, menu settings, and optional leaderboard support while preserving the original maze-action gameplay, timing, sound, and cabinet behavior.
- Designed for compatible original Stern Lost Tomb arcade PCBs
- Free Play with traditional Coin-Up operation retained
- Permanent Top 10 high score saving
- Reliable serial EEPROM storage with no batteries or failure-prone NVRAM required
- Attract sounds during every attract cycle
- Original manufacturer or HighScoreSaves logo selection
- Attract mode protection to help minimize CRT monitor burn-in
- Menu-driven DIP and operator settings
- ROM Saver support for optional original program ROM removal
- Separate score tables for 3 or 5 lives settings
- Backup and restore support for saved high scores
- Stealth Mode support
- Disable Continues option for Free Play and tournament-style setups
- Disable Advertising option for removing in-game advertisement screens
- Upright and cocktail cabinet support
- Optional Wi-Fi leaderboard support
View Lost Tomb Free Play and High Score Save Kit
View Lost Tomb Installation Guide
Before ordering: confirm that your machine contains a documented compatible original Stern Lost Tomb arcade PCB and a socketed Z80 processor location. If the Z80 processor is soldered directly to the PCB, a qualified arcade technician must install a compatible 40-pin socket before the kit can be used.
Lost Tomb PCB Upgrade Details and Benefits
The HighScoreSaves Lost Tomb Free Play and High Score Save Kit adds Free Play, Top 10 high score saving, serial EEPROM storage, attract sounds, menu-driven DIP settings, ROM Saver support, separate lives-based score tables, backup and restore, Stealth Mode, Disable Continues, Disable Advertising, upright/cocktail support, and optional Wi-Fi leaderboard support to documented compatible original Stern arcade hardware.
This upgrade is designed for original Stern Lost Tomb arcade PCBs. It keeps the original board in service rather than replacing the cabinet with an emulation system, reproduction PCB, or multicade platform.
Main Lost Tomb Kit Features
- Top 10 score saving: Stores the Top 10 supported high scores permanently.
- Battery-free storage: Uses reliable serial EEPROM storage instead of failure-prone NVRAM or batteries.
- Free Play: Start Lost Tomb without inserting coins or quarters.
- Traditional Coin-Up operation: Coin operation remains supported when desired.
- Attract sounds: Enable sound during every attract cycle.
- Copyright options: Select original manufacturer or HighScoreSaves logos.
- Attract mode protection: Helps minimize CRT burn-in during idle operation.
- Menu-driven DIP settings: Adjust supported options from the on-screen DIP switch menu.
- ROM Saver: Original program ROMs may be removed when installed as directed.
- Separate score tables: Independent score tables based on 3 or 5 lives settings.
- Backup and restore: Save and reload high scores when needed.
- Stealth Mode: Hidden settings-menu access for a more original-looking startup.
- Disable Continues: Useful for Free Play setups, tournaments, or operator-controlled play.
- Disable Advertising: Removes in-game advertisement screens.
- Upright and cocktail support: Supports documented upright and cocktail cabinet configurations.
- Optional Wi-Fi: Add online leaderboard score submission while keeping local score saving.
Access the HighScoreSaves Lost Tomb Settings Menu
To access the settings menu, hold Player 1 Start while turning the cabinet on. Release the button when the on-screen prompt tells you to continue.
Free Play, Attract Sounds, and Permanent High Scores
Free Play allows Lost Tomb to start without inserting coins while retaining traditional Coin-Up operation as an available setting.
Supported score data is stored using serial EEPROM, so batteries or NVRAM are not required for saved scores. The kit stores the Top 10 supported high scores permanently.
Attract sounds can be enabled during every attract cycle, and attract mode screen cycling helps reduce the chance of CRT monitor burn-in during idle operation.
Stern Hardware, ROM Saver, and Score Tables
Lost Tomb uses original Stern arcade hardware, and this kit is designed to preserve the original maze-action gameplay, controls, timing, sound, and cabinet behavior.
ROM Saver support allows designated original program ROMs to be removed when the kit is installed as directed in the Lost Tomb installation guide. This can help reduce heat and power usage from aging original ROM hardware.
Separate score tables are supported for 3 and 5 lives settings, helping keep saved scores organized across different gameplay configurations.
Disable Continues, Disable Advertising, and Stealth Mode
Disable Continues can be useful for Free Play operation, events, tournaments, or arcade setups where continues should not be available.
Disable Advertising removes in-game advertisement screens for a cleaner cabinet presentation.
Stealth Mode provides hidden settings-menu access, helping the cabinet retain a more original-looking startup appearance.
Installation and PCB Requirements
- Designed for documented compatible original Stern Lost Tomb arcade PCBs.
- Access to the original arcade PCB is required during installation.
- This kit requires a Z80 processor.
- The Z80 processor must be installed in a compatible 40-pin socket.
- No soldering is required when the Z80 location is already socketed.
- If the Z80 processor is soldered directly to the PCB, a qualified arcade technician must install a compatible 40-pin socket before the kit can be used.
- Remove only the designated original program ROMs identified in the Lost Tomb installation guide when using ROM Saver features.
- Verify Pin 1 orientation, processor alignment, socket condition, board seating, and all processor pins before restoring cabinet power.
- Review the Lost Tomb installation guide before installation.
Standard and Optional Wi-Fi Versions
The Standard Kit saves supported scores locally to the PCB and does not require an internet connection for gameplay, Free Play, settings, ROM Saver operation, Disable Continues, Disable Advertising, score tables, or local score saving.
The optional Wi-Fi Enabled Kit includes the same local features and adds online score syncing through the HighScoreSaves global leaderboard platform.
Wi-Fi can be disabled without affecting Lost Tomb gameplay, Free Play, local score saving, ROM Saver operation, cabinet settings, or menu-driven options.
Lost Tomb Kit FAQ
Which arcade PCB does the HighScoreSaves Lost Tomb kit support?
The kit is designed for documented compatible original Stern Lost Tomb arcade PCBs.
Which processor is required for the Lost Tomb kit?
The Lost Tomb kit requires a Z80 processor installed in a compatible socketed 40-pin processor location.
How many high scores does the Lost Tomb kit save?
The kit stores the Top 10 supported high scores using serial EEPROM storage.
Does the Lost Tomb kit support Free Play and Coin-Up operation?
Yes. Free Play and traditional Coin-Up operation are both supported.
How is the HighScoreSaves Lost Tomb settings menu opened?
Hold Player 1 Start while turning the cabinet on. Release the button when the on-screen prompt tells you to continue.
What does Disable Continues do on the Lost Tomb kit?
Disable Continues prevents continue play, which can be useful for Free Play setups, tournaments, or operator-controlled gameplay rules.
What does Disable Advertising do on the Lost Tomb kit?
Disable Advertising removes in-game advertisement screens for a cleaner cabinet presentation.
Does the Lost Tomb kit support upright and cocktail cabinets?
Yes. The Lost Tomb kit supports documented upright and cocktail cabinet configurations.
Is Wi-Fi required for the HighScoreSaves Lost Tomb kit?
No. Standard kits save supported scores locally. Wi-Fi is optional for online leaderboard support.
