Taito Multigame Kit Compatibility
HighScoreSaves offers two original-hardware Taito multigame high score save kit paths. Choose the Jungle Hunt | Elevator Action | Taito Multigame Kit for compatible original SJ Taito hardware, or the Frontline Vertical Taito Multigame Kit for supported Frontline-style vertical Taito hardware.
| Comparison | Jungle Hunt | Elevator Action | Frontline Vertical Taito |
|---|---|---|
| Hardware Path | Compatible original SJ Taito Jungle Hunt and Elevator Action PCBs | Supported Frontline, Wild Western, Jungle Hunt, and Elevator Action PCBs where compatible |
| Included Games | Elevator Action, Jungle King, Jungle Hunt, Pirate Pete, Time Tunnel, Space Seeker, Seafighter Poseidon | Frontline, Wild Western, Alpine Ski, Bio Attack, Water Ski, Highway Race, Space Cruiser |
| Score Saving | Top 5 with initials for each supported game | Top 10 with initials |
| CPU Type | Z80 | Z80 |
Choosing the Correct Taito Multigame Kit
The correct HighScoreSaves Taito multigame upgrade depends on the actual Taito PCB stack, control configuration, and hardware family. These kits use original arcade hardware and should be selected from the board configuration rather than from cabinet artwork alone.
The Jungle Hunt | Elevator Action kit is the SJ Taito path. The Frontline Vertical Taito kit is the Frontline-style vertical path and may also support documented Jungle Hunt or Elevator Action hardware when the PCB and control requirements match.
Taito Multigame Compatibility Comparison
| Requirement | Jungle Hunt | Elevator Action | Frontline Vertical Taito |
|---|---|---|
| Primary Hardware | Original SJ Taito Jungle Hunt / Elevator Action hardware | Supported Frontline-style vertical Taito hardware |
| Supported PCB Examples | Jungle Hunt, Elevator Action | Frontline, Wild Western, Jungle Hunt, Elevator Action where documented compatible |
| Main CPU | Z80 daughter-card installation | Z80 daughter-card installation |
| Sound CPU | Z80 sound daughter card | Z80 sound daughter card |
| ROM Removal | Documented program and sound ROM removal required | Documented program and sound ROM removal required |
| Score Saving | Top 5 with initials for each supported game | Top 10 with initials |
Jungle Hunt | Elevator Action Hardware Path
Choose this kit when the cabinet uses documented compatible original SJ Taito Jungle Hunt or Elevator Action hardware and the goal is the seven-game SJ Taito multigame configuration.
Frontline Vertical Taito Hardware Path
Choose the Frontline Vertical Taito kit when the cabinet and controls match the supported vertical Taito hardware path. Documented compatible hardware may include Frontline, Wild Western, Jungle Hunt, and Elevator Action PCBs, with rotary-control requirements where applicable.
Z80 Main and Sound CPU Requirements
Socket and Soldering Requirements
No soldering is required when the documented Z80 processor locations already use compatible sockets. If a required processor is soldered directly to the PCB, a compatible 40-pin socket must be installed before fitting the daughter card.
Program and Sound ROM Removal
The documented Taito multigame installation process requires removal of specified original program and sound ROMs before the daughter cards are installed. Remove only the ROMs identified by the installation guide for the selected kit.
PCB Stack, Ribbon Cable, and Orientation Checks
These Taito installations involve more than a single CPU daughterboard. The PCB stack, daughter cards, ribbon cable, processor orientation, and removed ROM locations all need to be checked before power is restored.
Verify Pin 1 orientation, processor seating, socket condition, required ROM removal, daughter-card clearance, ribbon-cable placement, PCB-stack alignment, and every documented installation step.
Settings Menu Access
Hold Player 1 Start while turning the cabinet on. Release the button when the on-screen prompt tells you to continue.
Taito Multigame Pre-Order Checklist
After Confirming Compatibility
Once the correct Taito PCB family, Z80 locations, sockets, ROM-removal requirements, controls, and installation path have been confirmed, use the appropriate product page for complete information about Free Play, score saving, attract sounds, menu settings, Backup and Restore, advanced features, Standard and optional Wi-Fi versions, pricing, availability, and ordering.
Taito Multigame Compatibility FAQ
Which Taito multigame kit should I choose?
Choose the Jungle Hunt | Elevator Action kit for compatible original SJ Taito hardware. Choose the Frontline Vertical Taito kit for supported Frontline-style vertical Taito hardware.
Can Jungle Hunt or Elevator Action hardware use either kit?
The source documents Jungle Hunt and Elevator Action as the primary SJ Taito path and also lists supported Jungle Hunt and Elevator Action PCBs for the Frontline Vertical Taito path. The exact PCB and control configuration must therefore be verified before choosing.
What processors are used?
The documented multigame installation uses Z80 main and sound CPU daughter cards.
Where are the documented CPU locations?
Main CPU installation is documented at IC56 and sound CPU installation at IC52 on the supported Taito PCB stack.
Do original ROMs need to be removed?
Yes. The documented installations include removal of specified original program and sound ROMs.
Does installation require soldering?
Not when the required Z80 locations already use compatible sockets. A compatible 40-pin socket must be installed if a required processor is soldered directly to the PCB.
