Frontline High Score Save Kit Compatibility
Before ordering the Frontline high score save kit, verify that your arcade machine contains documented compatible original Taito SJ PCB hardware. The Vertical Taito Multigame kit uses both the main and sound Z80 processor locations and requires PCB-stack access during installation.
Choosing the Correct Frontline Arcade PCB Upgrade
The HighScoreSaves Vertical Taito Multigame kit is designed for documented compatible original Taito SJ arcade hardware. Before ordering, confirm the PCB family, both Z80 processor locations, required ROM-removal locations, PCB-stack condition, and control requirements.
This category is intended to verify whether the Frontline high score save kit is appropriate for the original hardware in your cabinet. Complete multigame features, score-saving options, Standard/Wi-Fi choices, pricing, and ordering information remain on the product page.
Original Taito SJ PCB Compatibility
Two Z80 Processor Locations Are Used
Unlike a simple single-processor daughterboard installation, the Vertical Taito Multigame kit uses two Z80 daughterboards.
Taito SJ PCB Stack Installation
Installation requires partial disassembly of the original multi-board Taito SJ stack. This is more involved than installing a daughterboard on a single exposed processor socket.
Program and Sound ROM Removal
The current installation guide explicitly states that the kit will not operate correctly with the original documented program and sound ROMs left installed.
Rotary-Control Requirements
The PCB used as the donor hardware and the controls installed in the cabinet are separate compatibility considerations.
When using documented Jungle Hunt or Elevator Action PCB compatibility, rotary-dial support is required. Confirm that the cabinet has the appropriate control hardware before ordering based solely on PCB compatibility.
Frontline Pre-Order Compatibility Checklist
After Confirming Frontline PCB Compatibility
Once you have confirmed Taito SJ hardware, both Z80 processor locations, PCB-stack condition, ROM-removal requirements, and any necessary rotary controls, use the product page for the complete seven-game lineup, high-score features, Standard and Wi-Fi choices, current pricing, and ordering options.
Frontline PCB Compatibility FAQ
Which PCB family does the Frontline Multigame kit require?
The current installation guide specifies compatible Taito SJ PCB hardware.
Which original Taito game PCBs are documented?
Current product documentation identifies Frontline, Wild Western, Jungle Hunt, and Elevator Action Taito SJ configurations.
Does this installation use one or two Z80 processors?
Two processor locations are involved. The main Z80 at IC56 installs on the Main Daughter Card, and the sound Z80 at IC52 installs on the Sound Daughter Card.
Which original ROMs must be removed?
The current installation guide documents removal of sound ROMs IC70–IC73 and program ROMs IC1–IC10.
Does the PCB stack need to be disassembled?
Yes. The current guide requires partial disassembly of the Taito SJ stack so the CPU and sound daughterboards can be installed and the documented ROMs and MCU can be removed.
Is rotary-dial support required?
It is required when using the documented Jungle Hunt or Elevator Action PCB compatibility.
Does installation normally require soldering?
No soldering is normally required when the required processor locations are already properly socketed. If a required processor is soldered directly to the PCB, it must be properly removed and socketed by a qualified arcade technician before installation.
