Roc 'n Rope Arcade PCB Upgrades for Original Konami Hardware
Research the HighScoreSaves Roc 'n Rope upgrade for compatible original Konami arcade hardware. This kit is specifically designed for an original Roc 'n Rope PCB and uses a dedicated Konami1 adapter together with a 6809E daughter card.
Installation changes the processor configuration while keeping the original Konami PCB as the operating game hardware. The original Konami1 processor is removed and stored, the supplied Konami1 adapter is installed in its place, and the HighScoreSaves daughter card with a compatible 6809E processor is then installed on the adapter.
This is an original-PCB upgrade rather than a replacement JAMMA board, reproduction PCB, generic multicade, or software-emulation platform.
Roc 'n Rope Free Play and High Score Save Kit Installation Guide
Before ordering, verify that your cabinet contains a compatible original Roc 'n Rope PCB and review the documented Konami1 processor and adapter installation. The existing game board should be fully working before the upgrade is installed.
Roc 'n Rope Konami1 and 6809E Compatibility
The HighScoreSaves kit includes two key hardware components: a Roc 'n Rope 6809E daughter card and a Konami1 adapter. A compatible 6809E processor is also required for the installation.
- Designed specifically for a compatible original Konami Roc 'n Rope PCB
- Original Konami1 processor is removed and stored safely
- Included Konami1 adapter installs at the original processor location
- Requires a compatible 6809E processor installed on the HighScoreSaves daughter card
- 6809E daughter card installs on top of the Konami1 adapter with correct Pin 1 orientation
HighScoreSaves designs and supports Roc 'n Rope upgrades for compatible original Konami arcade PCBs using the Konami1 adapter and 6809E processor configuration.
Understanding the Roc 'n Rope Original PCB Upgrade
The Roc 'n Rope kit adds supported upgrade functionality while continuing to use the compatible original Konami game PCB. Unlike a replacement arcade board or emulation platform, the original Roc 'n Rope hardware remains in the cabinet as the underlying game system.
What makes this installation distinctive is its processor arrangement. Rather than simply placing a daughter card into the original processor socket, the kit replaces the original Konami1 processor in the active configuration with an adapter and 6809E-based daughter card.
Konami1 Processor, Adapter, and 6809E Daughter Card
Installation begins by locating the original Konami1 processor on the Roc 'n Rope PCB. That processor is carefully removed and stored in a safe place; it is no longer used while the HighScoreSaves kit is installed.
The supplied Konami1 adapter is installed at the original processor location. A compatible 6809E is then installed on the HighScoreSaves daughter card, and the completed daughter card is installed on top of the Konami1 adapter.
Correct Pin 1 orientation of the 6809E is important. Always compare the processor, daughter card, adapter, and PCB orientation with the installation guide before applying power.
What Happens to the Original Konami1 Processor?
The original Konami1 processor should be stored safely after removal. Keeping the original component protects the ability to retain the game's original hardware parts and provides a record of the PCB's previous processor configuration.
Roc 'n Rope Program ROMs
The installation documentation identifies removal of the original program ROMs as optional. They do not need to be removed simply to complete the basic daughter-card installation. If original program ROMs are removed, store them safely and record their original PCB locations.
Original Konami PCB vs. Replacement Hardware
The HighScoreSaves upgrade does not replace the Roc 'n Rope PCB with a generic multicade, replacement JAMMA board, or software-emulation system. Compatible original Konami hardware remains the operating arcade platform.
Why Keep the Original Roc 'n Rope PCB?
- Retains compatible original Konami arcade hardware in the cabinet
- Keeps the original Roc 'n Rope PCB as the underlying game platform
- Uses a dedicated Konami1 adapter designed for this processor configuration
- Adds supported functionality through a removable daughter-card upgrade
- Avoids replacing the original game system with a generic multicade or emulation platform
What to Check Before Ordering the Roc 'n Rope Kit
Vintage arcade cabinets may have been converted, repaired, or fitted with replacement components during decades of service. Inspect the actual game PCB before ordering rather than relying only on the cabinet artwork or control panel.
- Confirm that the cabinet contains a compatible original Roc 'n Rope PCB
- Verify that the existing game board is fully working before installation
- Locate and identify the original Konami1 processor
- Confirm that a compatible 6809E processor is available or select one when ordering
- Inspect the processor area, sockets, pins, traces, and nearby components for previous damage or repairs
- Review the Roc 'n Rope Installation Guide before ordering or beginning installation.
After confirming compatible original Roc 'n Rope hardware, visit the Roc 'n Rope Free Play and High Score Save Kit product page for current pricing, Top 5 score saving, 16 score tables, Free Play, attract sounds, Standard and Wi-Fi options, configuration choices, and ordering.
