Burgertime Arcade PCB Upgrade Overview for Original Data East Hardware
Review the available HighScoreSaves upgrade option for compatible original Data East Burgertime arcade PCBs, including Free Play, permanent high score saving, installation requirements, hardware compatibility, serial EEPROM storage, attract sounds, menu-driven DIP settings, attract mode protection, ROM Saver support, Backup and Restore, Reset Button support, separate score tables, Fast Boot, Stealth Mode, upright/cocktail cabinet support, and optional Wi-Fi leaderboard support.
This category is intended for collectors, operators, and restoration projects using original Burgertime arcade hardware. The upgrade keeps the original Data East PCB in service rather than replacing the cabinet with an emulation platform, reproduction board, or generic multicade system.
Burgertime installation uses a ribbon cable daughter card installation method. No soldering, CPU removal, board modifications, or special wiring are required when the original PCB and ribbon cable connectors match the documented installation guide.
Burgertime Hardware Compatibility and Upgrade Features
The Burgertime kit is designed for original Data East arcade hardware and adds modern reliability, score saving, attract sound control, menu settings, service features, and optional leaderboard support while preserving the original Burgertime gameplay, timing, controls, sound, and classic arcade behavior.
- Designed for compatible original Data East Burgertime arcade PCBs
- Ribbon cable daughter-card installation
- No soldering required when the PCB matches the documented installation method
- Free Play with traditional Coin-Up operation support
- Saves the Top 5 scores permanently
- Reliable serial EEPROM storage with no batteries required
- Separate score tables for 2, 3, 4, or 5 lives
- Attract sounds with authentic gameplay sound effects
- Attract mode protection to help reduce static-screen display time
- Menu-driven DIP settings for supported game options
- Backup and Restore support for saved high score data
- Reset Button support for restarting without cycling cabinet power
- Fast Boot support for quicker startup
- Stealth Mode support to boot directly into gameplay
- ROM Saver support for optional original program ROM removal
- Upright and cocktail cabinet support
- Optional Wi-Fi leaderboard support
View Burgertime Free Play and High Score Save Kit
View/Download Burgertime Install Guide (PDF)
Before ordering: confirm that your machine contains a documented compatible original Data East Burgertime arcade PCB. Review the install guide and compare your PCB and ribbon cable connectors to the documented layout before installation. Some ribbon cable notches may require slight filing for proper fitment.
Burgertime PCB Upgrade Details and Benefits
The HighScoreSaves Burgertime Free Play and High Score Save Kit adds Free Play, permanent Top 5 score saving, battery-free serial EEPROM storage, attract sounds, menu-driven DIP settings, attract mode protection, ROM Saver support, Backup and Restore, Reset Button support, separate score tables, Fast Boot, Stealth Mode, upright/cocktail cabinet support, and optional Wi-Fi leaderboard support to documented compatible original Data East Burgertime arcade hardware.
This upgrade is designed for original Data East Burgertime arcade PCBs. It keeps the original board in service rather than replacing the cabinet with an emulation system, reproduction PCB, or generic multicade platform.
Main Burgertime Kit Features
- Permanent score saving: Saves the Top 5 scores.
- Battery-free storage: Uses reliable serial EEPROM storage with no battery required.
- Free Play: Start Burgertime without inserting coins.
- Traditional Coin-Up operation: Normal coin operation remains supported when desired.
- Separate score tables: Supports separate score tables for 2, 3, 4, or 5 lives.
- Attract sounds: Restores authentic gameplay sound effects during attract mode.
- Attract mode protection: Helps reduce static-screen display time during idle periods.
- Menu-driven DIP settings: Change supported game options directly from the on-screen menu.
- Backup and Restore: Back up stored high scores and restore them when needed.
- Reset Button: Restart the game without turning the cabinet power off.
- Fast Boot: Supports quicker startup without lengthy initialization.
- Stealth Mode: Boots directly into gameplay.
- ROM Saver: Designated original program ROMs may be removed when installed as directed.
- Ribbon cable installation: Installs as a daughter card between ribbon cables with no CPU removal required.
- Upright and cocktail support: Supports documented upright and cocktail cabinet configurations.
- Optional Wi-Fi: Add qualifying online leaderboard score submission while keeping local score saving.
Access the HighScoreSaves Burgertime Settings Menu
To access the settings menu, hold Player 1 Start while turning the cabinet on. Release the button when the on-screen prompt tells you to continue.
Free Play, Coin-Up, and Top 5 Score Saving
Free Play allows Burgertime to start without inserting coins while retaining traditional Coin-Up operation when desired.
Supported score data is stored using serial EEPROM, so batteries are not required for saved scores. The kit saves the Top 5 scores.
Separate score tables are supported for 2, 3, 4, or 5 lives, allowing score storage to remain organized across supported lives settings.
Data East Hardware, Attract Sounds, and Stealth Mode
Burgertime uses original Data East arcade hardware, and this kit is intended for documented compatible original Burgertime arcade PCBs.
Attract sounds restore authentic gameplay sound effects, while attract mode protection helps reduce static-screen display time during idle periods.
Stealth Mode boots directly into gameplay, and Fast Boot helps reduce startup time after power-up or service.
ROM Saver, Backup and Restore, and Reset Button
ROM Saver support allows designated original program ROMs to be removed when the kit is installed as directed in the Burgertime installation guide.
Backup and Restore support allows stored high score data to be backed up and restored later for service, events, parties, route use, or tournament preparation.
Reset Button support allows the game to restart without powering the cabinet off.
Ribbon Cable Installation, Cabinet Support, and Local Saving
Burgertime installation uses a ribbon cable daughter-card method. The kit installs between ribbon cables with no CPU removal required when the PCB and connectors match the documented installation guide.
Some ribbon cable notches may require slight filing for proper fitment. Always compare your PCB and ribbon cable connectors to the installation guide before installation.
Upright and cocktail cabinet configurations are supported when used with documented compatible original Data East Burgertime arcade hardware.
Standard kits save supported scores and settings locally to the installed arcade PCB. Wi-Fi is optional and is not required for normal gameplay, local score saving, cabinet settings, menu operation, Reset Button support, Fast Boot, Stealth Mode, or ROM Saver operation.
Installation and PCB Requirements
- Designed for documented compatible original Data East Burgertime arcade PCBs.
- Access to the original arcade PCB is required during installation.
- Installation uses a ribbon cable daughter-card method.
- No CPU removal is required when the PCB and ribbon cable connectors match the documented installation guide.
- No soldering, board modifications, or special wiring are required for documented compatible installations.
- Verify ribbon cable connector orientation and fitment before restoring power.
- Some ribbon cable notches may require slight filing for proper fitment.
- Remove only the designated original program ROMs identified in the Burgertime installation guide when using ROM Saver features.
- Verify board seating, ribbon cable alignment, connector orientation, ROM removal locations, and all cable connections before restoring cabinet power.
- Review the Burgertime installation guide before installation.
Standard and Optional Wi-Fi Versions
The Standard Kit saves supported scores and settings locally to the PCB and does not require an internet connection for gameplay, Free Play, menu settings, ROM Saver operation, Backup and Restore, Reset Button support, Fast Boot, Stealth Mode, or local score saving.
The optional Wi-Fi Enabled Kit includes the same local features and can submit qualifying scores to the HighScoreSaves online leaderboard after a player enters their initials.
Wi-Fi can be disabled without affecting Burgertime gameplay, Free Play, local score saving, cabinet settings, menu-driven options, Reset Button support, Fast Boot, Stealth Mode, or ROM Saver operation.
Burgertime Kit FAQ
Which arcade PCB does the HighScoreSaves Burgertime kit support?
The kit is designed for documented compatible original Data East Burgertime arcade PCBs.
How many high scores does the Burgertime kit save?
The kit saves the Top 5 high scores using reliable serial EEPROM storage.
Does the Burgertime kit support Free Play and Coin-Up?
Yes. The kit supports Free Play and traditional Coin-Up operation.
How is the HighScoreSaves Burgertime settings menu opened?
Hold Player 1 Start while turning the cabinet on. Release the button when the on-screen prompt tells you to continue.
Does the Burgertime kit support separate score tables?
Yes. Separate score tables are supported for 2, 3, 4, or 5 lives.
What is Stealth Mode on the Burgertime kit?
Stealth Mode boots directly into gameplay without showing startup screens.
How does the Burgertime kit install?
It uses a ribbon cable daughter-card installation method and installs between ribbon cables with no CPU removal required on documented compatible PCBs.
Do ribbon cables require modification?
Some ribbon cable notches may require slight filing for proper fitment. Review the install guide and compare your PCB before installation.
Is Wi-Fi required for the HighScoreSaves Burgertime kit?
No. Standard kits save supported scores locally. Wi-Fi is optional for online leaderboard support.
