Chiller Arcade PCB Upgrade Compatibility for Original Exidy 440 Hardware
Confirm whether your Chiller arcade machine uses compatible original Exidy 440 hardware for the HighScoreSaves Exidy 440 Multigame upgrade. Chiller is included with this 10-game kit rather than being offered as a separate Chiller-only product.
Choosing the Correct Chiller Arcade PCB Upgrade
A Chiller cabinet, marquee, gun assembly, or control hardware does not by itself confirm compatibility. Original light-gun cabinets may have been converted, repaired, or fitted with replacement boards, so the actual arcade hardware should be identified before ordering.
Chiller is supported through the HighScoreSaves Exidy 440 Multigame Free Play and High Score Save Kit. There is no separate Chiller-only HighScoreSaves kit. The upgrade requires documented compatible original Exidy 440 arcade hardware and keeps that original platform in service.
Chiller & Exidy 440 PCB Compatibility
How the Chiller Exidy 440 Installation Works
The Exidy 440 installation works with both the original CPU PCB and sound PCB. The board stack is separated during installation so the required processors, daughter cards, and designated original components can be handled in their documented locations.
On the CPU board, designated EPROMs are removed and the 6809E processor is transferred to the kit. The main daughter card is then installed into the documented sockets. On the sound board, the 6809 processor and designated EPROMs are removed before the sound daughter-card assemblies are installed.
Before restoring cabinet power, verify processor orientation, Pin 1 alignment, daughter-card seating, socket condition, ribbon-cable connections, DIP-switch positions, and all other steps shown in the current Exidy 440 installation guide.
Chiller Pre-Order Compatibility Checklist
Keeping the Original Exidy 440 Chiller Hardware
The HighScoreSaves Exidy 440 Multigame Kit keeps compatible original Exidy arcade hardware in service while adding Chiller and the other supported Exidy 440 titles, Free Play, permanent score saving, flexible game selection, diagnostics, and optional online capability.
For the complete 10-game list, exact high-score modes, menu options, Gun Select Mode, Stealth Mode, Standard and Wi-Fi versions, included components, current price, and ordering choices, use the individual Exidy 440 Multigame product page.
Chiller Exidy 440 PCB Compatibility FAQ
Is there a separate Chiller-only HighScoreSaves kit?
No. Chiller is supported through the HighScoreSaves Exidy 440 Multigame Free Play and High Score Save Kit.
Does Chiller require original Exidy 440 hardware?
Yes. The multigame upgrade is designed for documented compatible original Exidy 440 arcade hardware and works with that original platform rather than replacing it.
Which processors are used during Exidy 440 installation?
The current installation guide uses a 6809E processor for the CPU-board portion of the kit and a 6809 processor for the sound-board portion.
Are original ROMs removed during Chiller installation?
Yes. Designated original EPROMs are removed from the Exidy 440 CPU and sound boards as directed by the installation guide. Save the removed components and record their original locations.
Does the multigame kit replace the original Chiller game hardware?
No. The documented compatible original Exidy 440 hardware remains the underlying arcade platform. The daughter-card system adds Chiller, multigame selection, score saving, and other supported functions to that hardware.
