Tron | Satan's Hollow Multigame Free Play and High Score Save Kit for Original Bally Midway Hardware

Tron | Satan's Hollow Multigame Kit Details and Benefits

The Tron | Satan's Hollow Multigame Free Play and High Score Save Kit upgrades documented compatible original Bally Midway arcade hardware with two supported games, Free Play, separate Top 10 high score tables, 8-digit scoring, menu-driven settings, serial EEPROM storage, adjustable attract sounds, ROM Saver support, Backup and Restore, selectable boot behavior, and optional Wi-Fi leaderboard support.

This is an original-hardware upgrade for Tron and Satan's Hollow cabinet owners who want multigame functionality without replacing the original Bally Midway PCB hardware with an emulator, reproduction board, or generic multicade system.

Main Tron | Satan's Hollow Multigame Features

• Two games included: Play Tron and Satan's Hollow from supported original Bally Midway hardware.
• Original hardware support: Designed for documented compatible original Tron or Satan's Hollow arcade hardware.
• Permanent score saving: Saves separate Top 10 score tables for each game.
• 8-digit scoring: Supports scores up to 99,999,999 without rolling over at 999,999.
• Serial EEPROM storage: Saves supported scores and settings without batteries or failure-prone NVRAM.
• Free Play: Start supported games without inserting coins.
• Coin-Up operation: Continue using traditional coin play when desired.
• Attract sounds: Configure supported attract sounds at 25%, 50%, or 100%.
• Attract mode protection: Helps reduce long periods of static display content.
• Menu-driven settings: Adjust supported game and DIP options through the on-screen menu.
• Backup and Restore: Preserve and restore supported high score data when needed.
• Reset Button: Restart the selected game without cycling cabinet power.
• Latest supported ROM revisions: Includes Tron 8/09 and the latest supported Satan's Hollow revisions.
• Stealth Mode: Boot directly into the last played or selected game.
• Satan's Hollow shield controls: Choose Spinner, Up, Down, or Player 2 button for shield activation.
• ROM Saver support: Designated original program ROMs may be removed as documented.
• Cabinet compatibility: Supports documented upright and cabaret cabinet configurations.
• Optional Wi-Fi: Add supported online score submission while retaining local score saving.

Satan's Hollow Shield Control Options

Satan's Hollow uses a shield mechanic that was not part of Tron's original control arrangement. The HighScoreSaves multigame kit provides selectable shield-control options so the game can be configured for the available controls in a supported cabinet.

Shield activation can be assigned to the Spinner, Up, Down, or Player 2 button. The preferred control option is selected through the kit settings.

Included Games and Score Saving

The Tron | Satan's Hollow Multigame kit includes Tron and Satan's Hollow. Each supported game maintains its own separate Top 10 high score table.

The kit expands scoring to eight digits, allowing supported scores to reach 99,999,999 instead of rolling over at 999,999.

Supported scores and settings are stored locally using serial EEPROM rather than batteries or NVRAM. Backup and Restore support allows saved score data to be preserved before service work, events, transport, testing, or other maintenance.

Free Play, Coin-Up, Attract Sounds, and Boot Options

Free Play allows Tron and Satan's Hollow to start without inserting coins. Traditional Coin-Up operation remains available when desired.

Attract sounds can be configured at 25%, 50%, or 100% of the supported attract rotation. Attract mode protection helps reduce prolonged static-screen display during idle operation.

Stealth Mode allows the cabinet to boot directly into the last played or selected game. Reset support also allows the active game to be restarted without cycling cabinet power.

Installation and PCB Requirements

• Designed for documented compatible original Bally Midway Tron or Satan's Hollow arcade hardware.
• A compatible Z80 processor is required.
• The required processor location must have a compatible 40-pin socket.
• No soldering is required when the required CPU locations are already properly socketed.
• If a required Z80 is soldered directly to the PCB, a compatible socket must be installed before using the kit.
• The installation uses multiple daughterboards across the original Bally Midway PCB stack.
• Designated program ROMs are removed from the Graphics, Super CPU, and Sound boards as directed by the installation guide.
• The original PCB stack is folded and reassembled in a different order to provide clearance for the installed daughterboards.
• The original ribbon cables remain connected during the documented installation procedure.
• Verify all daughterboard pins are aligned and fully seated before restoring cabinet power.
• Review the complete installation guide before beginning and power the cabinet off immediately if the game does not start correctly after installation.

Standard and Optional Wi-Fi Versions

Standard kits save supported scores and settings locally. An internet connection is not required for Tron or Satan's Hollow gameplay, Free Play, Coin-Up operation, game selection, or local score saving.

Optional 2.4 GHz Wi-Fi kits include the same local features and add supported online score submission through the HighScoreSaves leaderboard platform.

Wi-Fi can be disabled without affecting local gameplay, Free Play, Coin-Up operation, score saving, game selection, or menu operation.

Tron | Satan's Hollow Multigame Kit FAQ

Which games are included?

The kit includes Tron and Satan's Hollow.

Which arcade hardware is required?

The kit is designed for documented compatible original Bally Midway Tron or Satan's Hollow arcade hardware.

How many scores are saved?

Each game maintains a separate Top 10 high score table.

What is 8-digit scoring?

Supported scores can reach 99,999,999 without rolling over at 999,999.

How does the Satan's Hollow shield work in a Tron cabinet?

Shield activation can be configured to use the Spinner, Up, Down, or Player 2 button.

Does the kit support Free Play and Coin-Up?

Yes. Free Play and traditional Coin-Up operation are both supported.

What processor is required?

A compatible socketed Z80 processor is required.

Is installation more involved than a normal single-board kit?

Yes. The Tron | Satan's Hollow kit uses multiple daughterboards and requires documented ROM removal and rearrangement of the original Bally Midway PCB stack. Review the installation guide completely before beginning.

Can I choose which game the cabinet boots into?

Yes. Stealth Mode supports booting directly into the last played or selected game.

Which cabinet styles are supported?

The current product specifies support for upright and cabaret cabinet configurations.

Is Wi-Fi required?

No. Standard kits save supported scores locally. Wi-Fi is optional for online leaderboard support.
