Discs of Tron Arcade PCB Upgrade Overview for Original Bally Midway Hardware
Review the available HighScoreSaves upgrade option for compatible original Bally Midway Discs of Tron arcade PCBs, including Free Play, permanent high score saving, installation requirements, hardware compatibility, serial EEPROM storage, attract sound options, attract mode protection, on-screen DIP settings, ROM Saver support, Backup and Restore, separate score tables, bonus-life options, initial entry options, Z80 processor requirements, and optional Wi-Fi leaderboard support.
This category is intended for collectors, operators, and restoration projects using original Discs of Tron arcade hardware. The upgrade keeps the original Bally Midway PCB in service rather than replacing the cabinet with an emulation platform, reproduction board, or generic multicade system.
Discs of Tron installation requires a Z80 processor and a compatible socketed CPU location. No soldering is required when the Z80 CPU is already installed in a compatible 40-pin socket. If the Z80 is soldered directly to the PCB, a compatible 40-pin socket must be installed before the kit can be used.
Discs of Tron Hardware Compatibility and Upgrade Features
The Discs of Tron kit is designed for compatible original Bally Midway arcade hardware and adds modern reliability, score saving, attract behavior, menu settings, service features, and optional leaderboard support while preserving the original Discs of Tron gameplay, timing, sound, cabinet controls, and classic arcade experience.
- Designed for compatible original Bally Midway Discs of Tron arcade PCBs
- Free Play with traditional Coin-Up operation support
- Saves the Top 10 scores permanently
- Reliable serial EEPROM storage with no batteries or NVRAM required
- Attract sounds adjustable at 25%, 50%, or 100% rotation
- Copyright message option for original manufacturer or HighScoreSaves branding
- Attract mode protection to help reduce static-screen display time
- On-screen DIP settings for supported game options
- Backup and Restore support for saved high score data
- Separate score tables for 2, 3, 4, or 5 lives
- Bonus life options for 10k, 20k, 40k, or 80k
- Initial entry options for 2 or 3 initials
- Stealth Mode support for menu access during power-up
- ROM Saver support for optional original program ROM removal
- Requires a Z80 processor and compatible 40-pin socketed CPU location
- Upright and cocktail cabinet support where documented
- Optional Wi-Fi leaderboard support
View Discs of Tron Free Play and High Score Save Kit
View/Download Discs of Tron Install Guide (PDF)
Before ordering: confirm that your machine contains a documented compatible original Bally Midway Discs of Tron arcade PCB and the required socketed Z80 CPU location. If the Z80 CPU is soldered directly to the PCB, a qualified arcade technician must install a compatible 40-pin socket before the kit can be used.
Discs of Tron PCB Upgrade Details and Benefits
The HighScoreSaves Discs of Tron Free Play and High Score Save Kit adds permanent Top 10 score saving, Free Play, Coin-Up support, serial EEPROM storage, attract sounds, attract mode protection, on-screen DIP settings, ROM Saver support, Backup and Restore, separate score tables, Stealth Mode, bonus-life options, 2- or 3-initial entry, upright/cocktail support, and optional Wi-Fi leaderboard support to documented compatible original Discs of Tron arcade hardware.
This upgrade is designed for original Bally Midway Discs of Tron arcade PCBs. It keeps the original arcade board in service rather than replacing the cabinet with an emulation system, reproduction PCB, or generic multicade platform.
Main Discs of Tron Kit Features
- Permanent score saving: Stores the Top 10 supported scores.
- Battery-free storage: Uses reliable serial EEPROM storage with no batteries or NVRAM required.
- Free Play: Start Discs of Tron without inserting coins.
- Traditional Coin-Up operation: Continue using quarters or tokens when coin operation is enabled.
- Attract sounds: Adjustable at 25%, 50%, or 100% of the attract cycle.
- Attract mode protection: Helps reduce static-screen display time during idle operation.
- On-screen DIP settings: Configure supported operator settings directly through the menu system.
- Copyright message options: Switch between original manufacturer branding or HighScoreSaves branding.
- ROM Saver: Remove designated original program ROMs when installed as directed.
- Backup and Restore: Save and restore supported high score data.
- Separate score tables: Separate supported score tables for 2, 3, 4, or 5 lives.
- Stealth Mode: Enter the menu by holding Player 1 Start during power-up.
- Bonus-life options: Select supported bonus-life settings at 10k, 20k, 40k, or 80k.
- Initial entry options: Choose 2- or 3-initial entry.
- Upright and cocktail support: Supports documented upright and cocktail cabinet configurations.
- Optional Wi-Fi: Adds qualifying online leaderboard score submission while keeping local score saving.
Access the HighScoreSaves Discs of Tron Settings Menu
To access the settings menu, hold Player 1 Start while turning the cabinet on. This menu-access behavior is documented as Stealth Mode for the Discs of Tron kit.
Free Play, Coin-Up, and Top 10 Score Saving
Free Play allows Discs of Tron to start without inserting coins while retaining traditional Coin-Up operation when desired.
Supported score data is stored using serial EEPROM, so batteries or NVRAM are not required for saved scores. The kit stores the Top 10 supported scores.
Backup and Restore support allows stored score data to be backed up and restored later for service work, events, parties, route use, or tournament preparation.
Attract Sounds, DIP Settings, and Operator Options
Attract sounds can be adjusted to 25%, 50%, or 100% of the attract cycle, allowing the cabinet to be configured for home arcade, route, event, or collection use.
On-screen DIP settings allow supported options to be configured directly from the menu system instead of relying only on physical DIP-switch access.
Supported options include bonus-life settings at 10k, 20k, 40k, or 80k and 2- or 3-initial entry. Separate score tables are available for 2, 3, 4, or 5 lives.
ROM Saver, Stealth Mode, and Cabinet Support
ROM Saver support allows designated original program ROMs to be removed when the kit is installed as directed in the Discs of Tron installation guide.
Stealth Mode allows menu access by holding Player 1 Start during power-up. This helps keep normal cabinet startup behavior cleaner while still allowing operator access to supported settings.
Upright and cocktail cabinet configurations are supported when used with documented compatible original Discs of Tron arcade hardware.
Installation and PCB Requirements
- Designed for documented compatible original Discs of Tron arcade PCBs.
- Access to the original arcade PCB is required during installation.
- This kit requires a socketed Z80 CPU.
- The kit installs at the documented 40-pin Z80 processor location.
- No soldering is required when the required Z80 processor location already has a compatible 40-pin socket.
- If the Z80 processor is soldered directly to the PCB, a qualified arcade technician must install a compatible 40-pin socket before the kit can be used.
- Remove only the designated original program ROMs identified in the Discs of Tron installation guide when using ROM Saver features.
- Verify Pin 1 orientation, processor alignment, socket condition, board seating, ROM removal locations, and every processor pin before restoring cabinet power.
- Review the Discs of Tron installation guide before installation.
Standard and Optional Wi-Fi Versions
The Standard Kit stores supported scores and settings locally to the PCB and does not require an internet connection for gameplay, Free Play, Coin-Up operation, local score saving, on-screen DIP settings, ROM Saver operation, Backup and Restore, Stealth Mode, or bonus-life settings.
The optional Wi-Fi Enabled Kit includes the same local features and can submit qualifying scores to the HighScoreSaves online leaderboard after supported score entry.
Wi-Fi can be disabled without affecting Discs of Tron gameplay, Free Play, local score saving, menu operation, cabinet settings, or ROM Saver operation.
Discs of Tron Kit FAQ
Which arcade PCB does the HighScoreSaves Discs of Tron kit support?
The kit requires an original Discs of Tron PCB and a socketed Z80 CPU.
How many high scores does the Discs of Tron kit save?
The kit stores the Top 10 supported scores using reliable serial EEPROM storage.
Does the Discs of Tron kit support Free Play and Coin-Up?
Yes. The kit supports Free Play and traditional Coin-Up operation.
How is the HighScoreSaves Discs of Tron settings menu opened?
Hold Player 1 Start while turning the cabinet on. This is the documented Stealth Mode menu access for this kit.
Are separate score tables available?
Yes. Separate score tables are available for 2, 3, 4, or 5 lives.
What bonus-life options are supported?
Supported bonus-life settings include 10k, 20k, 40k, or 80k.
Can I choose 2 or 3 initials?
Yes. The kit supports selectable 2- or 3-initial entry.
Does installation require soldering?
No soldering is required when the Z80 CPU location is already socketed. If the Z80 is soldered directly to the PCB, a compatible 40-pin socket must be installed first.
Is Wi-Fi required?
No. Standard kits save supported scores and settings locally. Wi-Fi is optional for online leaderboard support.
