Juno First Free Play and High Score Save Kit for Original Konami Hardware
Upgrade a compatible original Konami Juno First arcade PCB with Free Play, Top 20 high score saving, serial EEPROM storage, attract sounds, menu-driven DIP settings, ROM Saver support, separate lives-based score tables, backup and restore, Stealth Mode, and optional Wi-Fi leaderboard support.
The HighScoreSaves Juno First Kit works with original Konami arcade hardware rather than replacing the game board with an emulation platform, reproduction PCB, or multicade system.
The kit requires a 6809E processor, and the Konami-1 CPU location must be socketed. No soldering is required when the required CPU location is already installed in a compatible 40-pin socket.
HighScoreSaves Juno First Kit
Designed for players, collectors, and operators who want Free Play, permanent score saving, attract sound support, menu-driven settings, ROM Saver support, and optional online leaderboard support while keeping original Juno First arcade hardware in service.
- Free Play with traditional Coin-Up operation retained
- Permanent Top 20 high score saving using serial EEPROM storage
- Attract sounds enabled during every attract rotation
- Screen saver attract mode to help reduce CRT monitor burn-in
- Menu-driven DIP and operator settings
- ROM Saver support for optional original ROM removal
- Separate score tables for 3, 4, 5, or 7 lives settings
- Backup and restore support for saved high scores
- Stealth Mode for a stock-style boot appearance
- Upright and cocktail cabinet support
- Optional Wi-Fi leaderboard support
View Juno First Free Play and High Score Save Kit
View Juno First Installation Guide
Before ordering: confirm that your machine contains a documented compatible original Konami Juno First arcade PCB and the required socketed CPU location. If the required CPU is soldered directly to the PCB, a qualified arcade technician must install a compatible 40-pin socket before the kit can be used.
Juno First Kit Details and Benefits
The HighScoreSaves Juno First Free Play and High Score Save Kit adds Free Play, Top 20 high score saving, serial EEPROM storage, attract sounds, screen saver attract mode, menu-driven DIP settings, ROM Saver support, separate lives-based score tables, backup and restore, Stealth Mode, upright/cocktail support, and optional Wi-Fi leaderboard support to documented compatible original Konami arcade hardware.
This daughterboard works with the original Konami Juno First arcade PCB rather than replacing the game board with an emulation platform, reproduction PCB, or multicade system.
Main Juno First Kit Features
- Top 20 score saving: Stores the Top 20 supported high scores permanently.
- Battery-free storage: Uses reliable serial EEPROM storage instead of NVRAM or batteries.
- Free Play: Start Juno First without inserting coins.
- Traditional Coin-Up operation: Coins remain supported when desired.
- Attract sounds: Sound is enabled during every attract rotation.
- Screen saver attract mode: Rotates content to help reduce CRT monitor burn-in.
- Menu-driven DIP settings: Change supported DIP options directly on screen.
- ROM Saver: Original ROMs may be removed when installed as directed.
- Separate score tables: Independent score tables for 3, 4, 5, and 7 lives settings.
- Backup and restore: Save and reload scores when needed.
- Stealth Mode: Boots to appear stock and original.
- Upright and cocktail support: Supports documented upright and cocktail cabinet configurations.
- Optional Wi-Fi: Add online leaderboard score submission while keeping local score saving.
Access the HighScoreSaves Juno First Settings Menu
To access the settings menu, hold Player 1 Start while turning the cabinet on. Release the button when the on-screen prompt tells you to continue.
Free Play, Attract Sounds, and Permanent High Scores
Free Play allows Juno First to start without inserting coins while retaining traditional Coin-Up operation as an available setting.
Supported score data is stored using serial EEPROM, so NVRAM or batteries are not required for saved scores. The kit stores the Top 20 supported scores.
Attract sounds are enabled during every attract rotation, and screen saver attract mode helps reduce CRT monitor burn-in during idle operation.
Konami Hardware, ROM Saver, and Score Tables
Juno First uses original Konami arcade hardware, and this kit is designed to keep the original gameplay, controls, timing, sound, and cabinet behavior intact.
ROM Saver support allows designated original ROMs to be removed when the kit is installed as directed in the Juno First installation guide.
Separate score tables are supported for 3, 4, 5, and 7 lives settings, helping keep score results organized across different gameplay configurations.
Backup, Restore, and Stealth Mode
Backup and restore support allows saved scores to be preserved and reloaded when needed for service, maintenance, or event preparation.
Stealth Mode provides a stock-style startup appearance for collectors who want the cabinet to look and behave closer to an original configuration during boot.
Installation and PCB Requirements
- Designed for documented compatible original Konami Juno First arcade PCBs.
- Access to the original arcade PCB is required during installation.
- This kit requires a 6809E processor.
- The Konami-1 CPU must be installed in a compatible 40-pin socket.
- No soldering is required when the required CPU location is already socketed.
- If the required CPU is soldered directly to the PCB, a qualified arcade technician must install a compatible 40-pin socket before the kit can be used.
- Remove only the designated original ROMs identified in the Juno First installation guide when using ROM Saver features.
- Verify Pin 1 orientation, processor alignment, socket condition, board seating, and all processor pins before restoring cabinet power.
- Review the Juno First installation guide before installation.
Standard and Optional Wi-Fi Versions
The Standard Kit saves supported scores locally to the PCB and does not require an internet connection for gameplay, Free Play, settings, ROM Saver operation, Stealth Mode, or local score saving.
The optional Wi-Fi Enabled Kit includes the same local features and adds online score syncing through the HighScoreSaves global leaderboard platform.
Wi-Fi can be disabled without affecting Juno First gameplay, Free Play, local score saving, score tables, ROM Saver operation, Stealth Mode, or menu-driven settings.
Juno First Kit FAQ
Which arcade PCB does the HighScoreSaves Juno First kit support?
The Juno First kit is designed for documented compatible original Konami Juno First arcade PCBs.
Which processor is required for the Juno First kit?
The Juno First kit requires a 6809E processor, and the Konami-1 CPU must be socketed.
How many high scores does the Juno First kit save?
The kit stores the Top 20 supported scores using serial EEPROM storage.
Does the Juno First kit support Free Play and Coin-Up operation?
Yes. Free Play and traditional Coin-Up operation are both supported.
How is the HighScoreSaves Juno First settings menu opened?
Hold Player 1 Start while turning the cabinet on. Release the button when the on-screen prompt tells you to continue.
Does Juno First support separate score tables for different lives settings?
Yes. Separate score tables are supported for 3, 4, 5, and 7 lives settings.
What is ROM Saver on the Juno First kit?
ROM Saver allows designated original ROMs to be removed when the kit is installed as directed in the Juno First installation guide.
Does the Juno First kit support upright and cocktail cabinets?
Yes. The Juno First kit supports documented upright and cocktail cabinet configurations.
Is Wi-Fi required for the HighScoreSaves Juno First kit?
No. Standard kits save supported scores locally. Wi-Fi is optional for online leaderboard support.
