Crystal Castles Arcade PCB Upgrade Overview for Original Atari Hardware
Review the available HighScoreSaves upgrade option for compatible original Atari Crystal Castles arcade PCBs, including Free Play, permanent high score saving, installation requirements, hardware compatibility, serial EEPROM storage, attract mode protection, copyright message options, on-screen DIP settings, ROM Saver support, Backup and Restore, Reset Button support, separate score tables, Fast Boot, upright/cocktail cabinet support, and optional Wi-Fi leaderboard support.
This category is intended for collectors, operators, and restoration projects using original Crystal Castles arcade hardware. The upgrade keeps the original Atari PCB in service rather than replacing the cabinet with an emulation platform, reproduction board, or generic multicade system.
Crystal Castles installation requires a 6502 processor and a compatible socketed CPU location. No soldering is required when the 6502 CPU is already installed in a compatible 40-pin socket.
Crystal Castles Hardware Compatibility and Upgrade Features
The Crystal Castles kit is designed for original Atari arcade hardware and adds modern reliability, score saving, attract behavior, menu settings, service features, and optional leaderboard support while preserving the original Crystal Castles gameplay, timing, trackball control, sound, and classic isometric arcade behavior.
- Designed for compatible original Atari Crystal Castles arcade PCBs
- Free Play with traditional Coin-Up operation support
- Saves the Top 32 scores permanently
- Reliable serial EEPROM storage with no batteries or NVRAM required
- Copyright message option for original manufacturer or HighScoreSaves branding
- Attract mode protection with rotating gameplay/demo screens
- On-screen DIP settings for supported game options
- Backup and Restore support for saved high score data
- Reset Button support for soft restart when enabled
- Fast Boot support with minimal initialization time
- Separate score tables for 2, 3, 4, or 5 lives
- ROM Saver support for optional original program ROM removal
- Requires a 6502 processor and compatible 40-pin socketed CPU location
- Upright and cocktail cabinet support
- Optional Wi-Fi leaderboard support
View Crystal Castles Free Play and High Score Save Kit
View/Download Crystal Castles Install Guide (PDF)
Before ordering: confirm that your machine contains a documented compatible original Atari Crystal Castles arcade PCB and the required socketed 6502 CPU location. If the 6502 CPU is soldered directly to the PCB, a qualified arcade technician must install a compatible 40-pin socket before the kit can be used.
Crystal Castles PCB Upgrade Details and Benefits
The HighScoreSaves Crystal Castles Free Play and High Score Save Kit adds Free Play, permanent Top 32 score saving, battery-free serial EEPROM storage, attract mode protection, copyright message options, on-screen DIP settings, ROM Saver support, Backup and Restore, Reset Button support, Fast Boot, separate score tables, upright/cocktail cabinet support, and optional Wi-Fi leaderboard support to documented compatible original Atari Crystal Castles arcade hardware.
This upgrade is designed for original Atari Crystal Castles arcade PCBs. It keeps the original board in service rather than replacing the cabinet with an emulation system, reproduction PCB, or generic multicade platform.
Main Crystal Castles Kit Features
- Permanent score saving: Saves the Top 32 scores.
- Battery-free storage: Uses reliable serial EEPROM storage with no batteries or NVRAM required.
- Free Play: Start Crystal Castles without inserting coins.
- Traditional Coin-Up operation: Normal coin operation remains supported when desired.
- Copyright message options: Select original manufacturer branding or HighScoreSaves branding.
- Attract mode protection: Rotating attract behavior helps reduce static-screen display time.
- On-screen DIP settings: Configure supported game options directly from the on-screen menu.
- Backup and Restore: Back up stored high scores and restore them when needed.
- Reset Button: Supports soft restart when the reset option is enabled.
- Fast Boot: Supports minimal initialization time during startup.
- Separate score tables: Includes separate score tables for 2, 3, 4, or 5 lives.
- ROM Saver: Designated original program ROMs may be removed when installed as directed.
- 6502 processor requirement: Requires a 6502 processor installed in a compatible 40-pin socketed location.
- Upright and cocktail support: Supports documented upright and cocktail cabinet configurations.
- Optional Wi-Fi: Add qualifying online leaderboard score submission while keeping local score saving.
Access the HighScoreSaves Crystal Castles Settings Menu
To access the settings menu, hold Player 1 Start while turning the cabinet on. Release the button when the on-screen prompt tells you to continue.
Free Play, Coin-Up, and Top 32 Score Saving
Free Play allows Crystal Castles to start without inserting coins while retaining traditional Coin-Up operation when desired.
Supported score data is stored using serial EEPROM, so batteries or NVRAM are not required for saved scores. The kit saves the Top 32 scores.
Backup and Restore support allows stored high score data to be backed up and restored later for service, events, parties, route use, or tournament preparation.
Atari Hardware, Attract Protection, and DIP Settings
Crystal Castles uses original Atari arcade hardware, and this kit is intended for documented compatible original Crystal Castles arcade PCBs.
Attract mode protection helps reduce static-screen display time by rotating attract behavior instead of leaving the cabinet on one static display.
On-screen DIP settings allow supported options to be configured directly from the on-screen menu, reducing the need to adjust PCB DIP switches during normal setup.
Copyright Options, ROM Saver, Reset Button, and Fast Boot
Copyright message options allow the cabinet to show either original manufacturer branding or HighScoreSaves branding.
ROM Saver support allows designated original program ROMs to be removed when the kit is installed as directed in the Crystal Castles installation guide.
Reset Button support allows a soft restart when enabled. Fast Boot reduces startup initialization time for quicker cabinet operation.
Separate score tables are supported for 2, 3, 4, or 5 lives, allowing score storage to remain organized across supported lives settings.
Cabinet Support and Local Saving
Upright and cocktail cabinet configurations are supported when used with documented compatible original Atari Crystal Castles arcade hardware.
Standard kits save supported scores and settings locally to the installed arcade PCB. Wi-Fi is optional and is not required for normal gameplay, local score saving, cabinet settings, menu operation, Reset Button support, Fast Boot, or ROM Saver operation.
Installation and PCB Requirements
- Designed for documented compatible original Atari Crystal Castles arcade PCBs.
- Access to the original arcade PCB is required during installation.
- This kit requires a 6502 processor.
- The 6502 processor must be installed in a compatible 40-pin socketed location.
- No soldering is required when the required 6502 processor location is already socketed.
- If the 6502 processor is soldered directly to the PCB, a qualified arcade technician must remove the processor and install a compatible 40-pin socket before the kit can be used.
- Remove only the designated original program ROMs identified in the Crystal Castles installation guide when using ROM Saver features.
- Verify Pin 1 orientation, processor alignment, socket condition, board seating, ROM removal locations, and all processor pins before restoring cabinet power.
- Review the Crystal Castles installation guide before installation.
Standard and Optional Wi-Fi Versions
The Standard Kit saves supported scores and settings locally to the PCB and does not require an internet connection for gameplay, Free Play, menu settings, ROM Saver operation, Backup and Restore, Reset Button support, Fast Boot, or local score saving.
The optional Wi-Fi Enabled Kit includes the same local features and can submit qualifying scores to the HighScoreSaves online leaderboard after a player enters their initials.
Wi-Fi can be disabled without affecting Crystal Castles gameplay, Free Play, local score saving, cabinet settings, menu-driven options, Backup and Restore, Reset Button support, Fast Boot, or ROM Saver operation.
Crystal Castles Kit FAQ
Which arcade PCB does the HighScoreSaves Crystal Castles kit support?
The kit is designed for documented compatible original Atari Crystal Castles arcade PCBs.
How many high scores does the Crystal Castles kit save?
The kit saves the Top 32 scores using reliable serial EEPROM storage.
Does the Crystal Castles kit support Free Play and Coin-Up?
Yes. The kit supports Free Play and traditional Coin-Up operation.
How is the HighScoreSaves Crystal Castles settings menu opened?
Hold Player 1 Start while turning the cabinet on. Release the button when the on-screen prompt tells you to continue.
Are separate score tables available?
Yes. Separate score tables are available for 2, 3, 4, or 5 lives.
What is the Reset Button option?
When enabled, the game can be soft restarted without turning the cabinet power off.
Which processor does this kit require?
A 6502 processor is required and must be installed in a compatible 40-pin socketed location.
What is ROM Saver on the Crystal Castles kit?
ROM Saver allows designated original program ROMs to be removed while the game runs directly from the kit when installed as directed.
Is Wi-Fi required for the HighScoreSaves Crystal Castles kit?
No. Standard kits save supported scores locally. Wi-Fi is optional for online leaderboard support.
