Krull Arcade PCB Upgrade Overview for Original Gottlieb Hardware
Review the available HighScoreSaves upgrade option for compatible original Gottlieb Krull arcade PCBs, including Free Play, high score retention, installation requirements, hardware compatibility, ROM Saver support, attract sound options, menu-driven settings, God Mode practice, and optional Wi-Fi leaderboard support.
This category is intended for collectors, operators, and restoration projects using original Krull arcade hardware. The upgrade keeps the original Gottlieb PCB in service rather than replacing the cabinet with an emulation platform, reproduction board, or multicade system.
Krull installation requires an Intel 8088-compatible processor installed in a compatible 40-pin socket. No soldering is required when the original 8088 processor location is already socketed.
Krull Hardware Compatibility and Upgrade Features
The Krull kit is designed for original Gottlieb arcade hardware and adds modern reliability, score retention, operator settings, and optional leaderboard support while preserving the original gameplay, timing, sound, and cabinet behavior.
- Designed for compatible original Gottlieb Krull arcade PCBs
- Free Play with optional coin operation retained
- Battery-free EEPROM score retention
- Displays the Top 10 Elite scores
- Daily Top 25 scores are not stored after power is removed
- Selectable attract sounds for every intro screen set, 1 of 4, 2 of 4, or all the time
- Menu-driven game settings for supported options
- Bonus lives and lives-per-game settings
- Attract mode protection to help reduce screen burn
- Backup and restore support for saved score data
- Multiple score tables based on selected number of lives
- God Mode practice with score saving disabled
- ROM Saver support for optional original program ROM removal
- Upright and cocktail cabinet support
- Optional Wi-Fi leaderboard support
View Krull Arcade Free Play and High Score Save Kit
Before ordering: confirm that your machine contains a documented compatible original Gottlieb Krull arcade PCB and a socketed 8088 processor location. If the original processor is soldered directly to the PCB, a qualified arcade technician must install a compatible 40-pin socket before the kit can be used.
Krull PCB Upgrade Details and Benefits
The HighScoreSaves Krull Arcade Free Play and High Score Save Kit adds Free Play, battery-free EEPROM score retention, Top 10 Elite score display support, attract sound options, menu-driven game settings, ROM Saver support, backup and restore, multiple score tables, God Mode practice, upright and cocktail cabinet support, and optional Wi-Fi leaderboard support to documented compatible original Gottlieb arcade hardware.
This upgrade is designed for original Gottlieb Krull arcade PCBs. It keeps the original board in service rather than replacing the cabinet with an emulation system, reproduction PCB, or multicade platform.
Main Krull Kit Features
- Free Play: Play Krull without inserting coins.
- Optional coin operation: Coin operation can still be retained.
- Battery-free score retention: Uses EEPROM storage with no batteries required.
- Top 10 Elite score display: Displays the Top 10 Elite scores.
- Daily Top 25 limitation: Daily Top 25 scores are not stored after power is removed.
- Attract sounds: Select attract sounds for every intro screen set, 1 of 4, 2 of 4, or all the time.
- Menu-driven settings: Configure supported game options through the on-screen settings menu.
- Game settings: Select bonus lives, lives per game, and other supported options.
- Attract mode protection: Helps reduce screen burn during attract mode.
- Backup and restore: Save and reload score data from the settings menu.
- Multiple score tables: Maintains separate score tables based on the selected number of lives.
- God Mode: Practice mode with unlimited lives while score saving is disabled.
- ROM Saver: Original program ROMs may be removed because the daughterboard supplies the required game code.
- Upright and cocktail support: Supports documented upright and cocktail cabinet configurations.
- Optional Wi-Fi: Add online leaderboard score submission while keeping local score retention.
Access the HighScoreSaves Krull Settings Menu
To access the settings menu, hold Player 1 Start while turning the cabinet on. Release the button when the on-screen prompt tells you to continue.
Free Play, EEPROM Score Retention, and Top Score Tracking
Free Play allows Krull to start without inserting coins while retaining optional coin operation when desired.
Supported score data is retained using battery-free EEPROM storage, so batteries are not required for local score retention.
The kit displays the Top 10 Elite scores. The Daily Top 25 scores are not retained after power is removed, so this category should be understood as a Krull Free Play and supported high-score-retention upgrade, not a full Daily Top 25 score preservation system.
Gottlieb Hardware, Attract Sounds, and ROM Saver
Krull uses original Gottlieb arcade hardware, and this kit is designed to preserve the original gameplay, timing, sound, and cabinet behavior.
Attract sounds can be configured for every intro screen set, 1 of 4, 2 of 4, or all the time. Attract mode protection helps reduce screen burn during idle operation.
ROM Saver support allows the original program ROMs to be removed because the daughterboard supplies the required game code when installed as directed.
Backup, Restore, Multiple Score Tables, and God Mode
Backup and restore support allows score data to be saved and reloaded from the settings menu for service, event preparation, or maintenance.
Multiple score tables are maintained based on the selected number of lives, helping keep score results organized across supported gameplay settings.
God Mode provides unlimited-lives practice. Scores are not saved while God Mode is active, which keeps practice sessions separate from normal score tracking.
Installation and PCB Requirements
- Designed for documented compatible original Gottlieb Krull arcade PCBs.
- Access to the original arcade PCB is required during installation.
- This kit requires an Intel 8088-compatible processor.
- The original 8088 processor must be installed in a compatible 40-pin socket.
- No soldering is required when the original 8088 processor is already socketed.
- If the original 8088 processor is soldered directly to the PCB, a qualified arcade technician must install a compatible 40-pin socket before the kit can be used.
- Average install time is approximately 10–20 minutes when the original 8088 processor is already socketed.
- Remove only the designated original program ROMs identified in the Krull installation guide when using ROM Saver features.
- Verify Pin 1 orientation, processor alignment, socket condition, board seating, and all processor pins before restoring cabinet power.
- Review the Krull installation guide before installation.
Standard and Optional Wi-Fi Versions
The Standard Kit saves supported score data locally to the PCB and does not require an internet connection for gameplay, Free Play, settings, ROM Saver operation, God Mode practice, or local score retention.
The optional Wi-Fi Enabled Kit includes the same local features and adds online score syncing through the HighScoreSaves global leaderboard platform.
Wi-Fi can be disabled without affecting Krull gameplay, Free Play, local score retention, ROM Saver operation, cabinet settings, or menu-driven options.
Krull Kit FAQ
Which arcade PCB does the HighScoreSaves Krull kit support?
The kit is designed for documented compatible original Gottlieb Krull arcade PCBs.
Which processor is required for the Krull kit?
The Krull kit requires an Intel 8088-compatible processor installed in a compatible socketed 40-pin processor location.
Does the Krull kit save the Daily Top 25 scores?
No. The kit displays the Top 10 Elite scores and does not store the Daily Top 25 scores after power is removed.
Does the Krull kit support Free Play and coin operation?
Yes. Free Play is supported while optional coin operation can still be retained.
How is the HighScoreSaves Krull settings menu opened?
Hold Player 1 Start while turning the cabinet on. Release the button when the on-screen prompt tells you to continue.
What is God Mode on the Krull kit?
God Mode is a practice mode with unlimited lives. Scores are not saved while God Mode is active.
What is ROM Saver on the Krull kit?
ROM Saver allows the original program ROMs to be removed because the daughterboard supplies the required game code.
Does the Krull kit support upright and cocktail cabinets?
Yes. The Krull kit supports documented upright and cocktail cabinet configurations.
Is Wi-Fi required for the HighScoreSaves Krull kit?
No. Standard kits save supported score data locally. Wi-Fi is optional for online leaderboard support.
