Braze Asteroids Free Play High Score Save Kit

Braze Frogger High Score Save Kit — Features & Install 📄 Installation Guide (PDF) Overview Installation is similar to other Braze Technology save kits (replace the CPU with the daughter card). Frogger’s board set may require extra disassembly/reassembly to reach the CPU and spacer rearrangement or replacement to provide additional clearance between boards. See the detailed install guide for step-by-step photos. Installation Summary Power down and discharge the cabinet; remove the board set. Disassemble the stack as needed to access the CPU; adjust or replace spacers for clearance. Carefully remove the CPU from the Frogger CPU board. Insert the CPU into the included daughter card. Plug the daughter card into the vacated CPU socket, reassemble the board set, and restore spacers. Power on and follow the install guide to verify operation. No soldering or special wiring is required. Key Features Installs in minutes: no board modifications, soldering, or special wiring. High Score Save: stores the top 5 scores and 3-letter initials permanently (no batteries). True Free Play: no coins needed; keep the coin door closed. Full attract mode: runs normally while in Free Play. Initials entry: user-friendly on-screen interface. Premium hardware: gold-plated machined header pins; daughter card snaps firmly in place. Power-on diagnostics: automatic self-test every time the game powers up. On-screen settings: adjust options and erase high scores without DIP switches. On-screen test mode: test music, sound effects, sprites, characters, and color maps. FAQ Where can I download the install guide? Frogger Install Guide (PDF) Do I need to solder anything? No. Installation requires no soldering or special wiring. Why do I need extra spacers? The daughter card adds height. Adjusting or replacing spacers ensures proper clearance between stacked boards. How many scores and initials are saved? The kit permanently stores the top 5 scores and 3-letter initials, even after power-off. Can I test audio and video through the kit? Yes. Use the on-screen test mode for sound effects, music, sprites, characters, and color maps. How do I erase the high score table? Open the on-screen settings menu and select the option to clear high scores.

Braze Space Invaders (Taito) 8-in-1 Multigame High Score Save Kit — Features & Install 📄 Installation Guide (PDF) Overview Easy-to-install kit that expands your Space Invaders boardset to play 8 games. No soldering, special wiring, or external switches required. Switch games using P1 Start + P2 Start to access the on-screen selection menu. Includes on-screen configuration options and high score save for all titles. Note: Your 8080 CPU may require a socket. Check your PCB before installation. Installation Summary Power down the cabinet and access the Taito SI two-board L-shaped set or 3-PCB stack. Inspect the 8080 CPU — add a socket if necessary. Carefully remove the 8080 from the PCB. Insert the 8080 into the included daughter card. Plug the daughter card into the vacated 8080 socket. Power on and press P1+P2 Start to select a game. Key Features Installs on a Space Invaders PCB in minutes—no soldering or wiring. Free Play option (Galaxy Wars excluded). High Score Save for all eight titles. Power-on diagnostics at each startup. On-screen configuration menu with advanced options. Interactive test mode for detail-level PCB checks. Game List Space Invaders Space Invaders Deluxe Jatre Specter Lunar Rescue Space Laser Balloon Bomber Galaxy Wars (Free Play not supported) Super Earth Invasion FAQ Where can I download the install guide? Space Invaders Install Guide (PDF) What board types are supported? Supports the Taito black-and-white style PCB in both two-board and 3-board configurations. Will it work in a cocktail cab? Yes — as long as it’s a B&W Taito style (not the color Taito variant). Cocktail/upright mode depends on input-board strapping, and screen flip is done via monitor relays. How do I switch between games? Press P1 Start + P2 Start simultaneously to open the menu. How do these versions differ from originals? Adds Free Play, onboard diagnostics, high score save, extended configuration, and options like laser-base count, bonus award levels, and other enhancements. Do I need to solder anything? Usually no — unless your 8080 CPU is soldered in. In that case, a socket must be added first.

Braze Battlezone High Score Save Kit — Features & Install 📄 Installation Guide (PDF) Overview A high score save kit for Battlezone that permanently remembers the top 10 scores and initials—even after power-off—without any batteries. It also serves as a ROM saver, reducing failures caused by aging ROM sockets. Note: This version does not include attract sounds; the Highscoresaves.com version does. No soldering or special wiring required. Installation Summary Power down the cabinet and access the CPU board. Remove the 6502 CPU from the Battlezone board. Insert the 6502 into the included daughter card. Plug the daughter card into the original 6502 socket. Power on and verify operation using the install guide. To clear saved scores, enter Self Test, then hold Start + Fire until the screen displays “ERASED.” Key Features Installs in minutes — no wiring or soldering. Top 10 High Score Save — scores + initials saved permanently. ROM Saver — reduces issues from aged or loose ROM sockets. Premium hardware — gold-plated machined header pins for a strong, reliable connection. Easy reset — clear via Self Test (Start + Fire) with on-screen confirmation. Attract sounds — not included in this Braze version (available on Highscoresaves.com version). FAQ Where can I download the install guide? Battlezone Install Guide (PDF) Do I need to solder anything? No. Installation is fully plug-and-play. How do I clear the high scores? Enter Self Test, then hold Start + Fire until “ERASED” appears. Does this kit include attract sounds? No. This Braze version has no attract sounds. Highscoresaves.com version includes them. Which CPU does this kit use? The kit uses the 6502 CPU. Remove your 6502, place it in the daughter card, then install the card. What ensures a reliable connection? Gold-plated machined header pins provide a tight, long-lasting connection in the original socket.

Braze Red Baron High Score Save Kit — Features & Install 📄 Installation Guide (PDF) Overview A simple-to-install high score save kit for Red Baron that permanently remembers the top 7 scores and initials—no batteries required. It also functions as a ROM Saver, reducing issues from aging sockets. Premium gold-plated machined header pins provide a strong, reliable connection, and the daughter card snaps firmly into place. No special wiring or soldering is required. Installation Summary Power down the cabinet and access the CPU board. Carefully remove the 6502 CPU from the Red Baron board. Insert the 6502 into the included daughter card. Plug the daughter card into the vacated 6502 CPU socket on the board. Power on and follow the install guide to verify operation. To clear saved scores: enter Self Test, then press and hold Start + Fire until the screen displays “ERASED.” Key Features Installs in minutes: no board modifications or special wiring; no soldering required. Top 7 High Score Save: scores and initials are retained permanently (no batteries). ROM Saver: reduces problems from aging or intermittent ROM sockets. Premium hardware: gold-plated machined header pins; daughter card locks firmly in place. Easy reset: clear the table via Self Test (Start + Fire) with on-screen “ERASED” confirmation. FAQ Where can I download the install guide? Red Baron Install Guide (PDF) Do I need to solder anything? No. Installation requires no soldering or special wiring. How do I clear the high scores? Enter Self Test, then press and hold Start + Fire until “ERASED” appears on screen. Which CPU does this kit use? The kit interfaces with the 6502 CPU—remove the existing 6502, place it in the daughter card, then plug the card into the 6502 socket. What ensures a reliable connection? Gold-plated machined header pins provide a secure, long-lasting connection to the Red Baron CPU socket.

Braze Popeye High Score Save Kit — Features & Install 📄 Installation Guide (PDF) Overview A simple-to-install high score save kit for Popeye that permanently remembers the top 5 scores and initials—no batteries required. Includes enhanced Free Play with full attract-mode screens. Installs in minutes with no special wiring or soldering. Installation Summary Power down the cabinet and access the CPU board. Carefully remove the Z80 CPU from the Popeye CPU board. Insert the Z80 into the included daughter card. Plug the daughter card into the vacated Z80 socket on the CPU board. Power on and follow the install guide to verify operation. Key Features Installs in minutes: no board modifications or special wiring; no soldering. Top 5 High Score Save: scores and initials are retained permanently (no batteries). Enhanced Free Play: real Free Play with full, standard attract mode. Easy reset: in Popeye test mode, follow on-screen instructions to restore the default table. Improved test mode: clearer DIP verification plus a mini power-on self-test (POST) on each boot. FAQ Where can I download the install guide? Popeye Install Guide (PDF) Do I need to solder anything? No. Installation requires no soldering or special wiring. How do I reset the high scores? Enter Popeye test mode and follow the on-screen prompts to clear the table and restore factory defaults. Does Free Play keep attract mode? Yes. Enhanced Free Play includes full, standard attract-mode screens. Which CPU does this kit use? The kit interfaces with the Z80 CPU—remove the Z80, place it in the daughter card, then insert the card into the Z80 socket.
