Gyruss Multigame Free Play and High Score Save Kit for Original Arcade Hardware
Upgrade a compatible original Gyruss arcade PCB with the Gyruss Multigame Free Play and High Score Save Kit, adding Gyruss, Time Pilot, and Pooyan support along with Free Play, Top 5 score saving with initials, serial EEPROM storage, extended scoring, on-screen DIP settings, ROM Saver support, and optional Wi-Fi leaderboard support.
This multigame upgrade is designed for compatible original Gyruss arcade hardware rather than replacing the cabinet with an emulation platform, reproduction PCB, or multicade system.
The kit requires a socketed Z80 processor. Most Gyruss PCBs also require sockets for 3× 16-pin PROMs and 1–2× 16-pin LS377s before installation.
Gyruss Multigame Kit Features
Choose this kit when you want Gyruss, Time Pilot, and Pooyan selectable from compatible original Gyruss hardware with permanent score saving and modern operator features.
- Includes Gyruss, Time Pilot, and Pooyan
- Free Play with traditional Coin-Up operation retained
- Permanent Top 5 high score saving with initials for each game
- Reliable serial EEPROM storage with no batteries or NVRAM required
- Extended scoring support up to 9,999,990 points
- Adjustable attract sounds at 25%, 50%, or 100% sound cycles
- On-screen DIP and gameplay settings
- ROM Saver support for optional original program ROM removal
- High Scores button and All Global High Scores button support
- Backup and restore support for saved high scores
- Separate score tables for 3, 5, or 6 lives settings
- Reset button support
- Self-test access through the menu or DIP switch setup
- God Mode practice with score saving disabled
- Stealth Mode Multigame boot selection
- Upright and cocktail cabinet support
- Optional Wi-Fi leaderboard support
View Gyruss Multigame Free Play and High Score Save Kit
View Gyruss Multigame Installation Guide
Before ordering: confirm that your machine contains a documented compatible original Gyruss arcade PCB. A socketed Z80 processor is required, and most Gyruss PCBs need additional socket work for PROMs and LS377s before this multigame kit can be installed.
Gyruss Multigame Kit Details and Benefits
The Gyruss Multigame Free Play and High Score Save Kit adds Gyruss, Time Pilot, and Pooyan support to compatible original Gyruss arcade hardware. It also adds Free Play, Top 5 high score saving with initials, serial EEPROM storage, attract sounds, menu-driven settings, ROM Saver support, extended scoring, backup and restore, self-test features, God Mode practice, Stealth Mode Multigame boot selection, and optional Wi-Fi leaderboard support.
This kit is designed for original arcade hardware behavior and does not replace the cabinet with an emulation system, reproduction PCB, or multicade board.
Games Included
Gyruss
Konami’s rotating space shooter with circular movement, fast enemy waves, and classic arcade sound.
Time Pilot
Multidirectional time-travel shooting gameplay with era-based aerial combat.
Pooyan
Classic Konami arcade action with balloon combat, precision shooting, and cartoon-inspired gameplay.
Main Gyruss Multigame Features
- Three games included: Select Gyruss, Time Pilot, or Pooyan on compatible original Gyruss hardware.
- Permanent score saving: Saves the Top 5 scores with initials for each game.
- Battery-free storage: Uses serial EEPROM instead of batteries or NVRAM.
- Free Play: Start games without coins while retaining traditional Coin-Up operation.
- Attract sounds: Adjustable at 25%, 50%, or 100% sound cycles.
- Extended scoring: Supports scoring up to 9,999,990 points.
- On-screen DIP settings: Adjust supported gameplay and configuration settings through the menu.
- ROM Saver: Original program ROMs may be removed when installed as directed.
- High Scores button: Quickly view saved score tables for the selected game.
- All Global High Scores button: Useful for Wi-Fi enabled leaderboard support.
- Backup and restore: Save and restore supported high scores when needed.
- Separate score tables: Individual tables for 3, 5, or 6 lives settings.
- Reset button: Restart gameplay without powering down the cabinet.
- Self-test: Accessible through the menu or by turning all DIP switches OFF.
- God Mode: Unlimited-lives practice mode with score saving disabled.
- Stealth Mode Multigame: Choose Gyruss, Time Pilot, or Pooyan during boot.
- Upright and cocktail support: Supports documented upright and cocktail cabinet configurations.
- Optional Wi-Fi: Add online leaderboard score submission while keeping local score saving.
Stealth Mode Multigame Boot Selection
The Gyruss Multigame kit uses Stealth Mode Multigame boot behavior to choose between Gyruss, Time Pilot, and Pooyan. Review the installation guide for the exact setup and startup procedure before installation.
Installation and PCB Requirements
- Designed for documented compatible original Gyruss arcade PCBs.
- Access to the original arcade PCB is required during installation.
- A socketed Z80 processor is required.
- If the Z80 processor is soldered directly to the PCB, a qualified arcade technician must install a compatible 40-pin socket.
- Most Gyruss PCBs require sockets for 3× 16-pin PROMs and 1–2× 16-pin LS377s.
- No trace cutting or special wiring is required beyond socket installation.
- Remove only the designated original program ROMs identified in the Gyruss Multigame installation guide when using ROM Saver features.
- Verify Pin 1 orientation, processor alignment, socket condition, added socket work, board seating, and all pins before restoring cabinet power.
- Review the Gyruss Multigame installation guide before setup.
Standard and Optional Wi-Fi Versions
The Standard Kit saves supported scores locally to the PCB and does not require an internet connection for gameplay, Free Play, local score saving, ROM Saver operation, Stealth Mode Multigame boot selection, or menu-driven settings.
The optional Wi-Fi Enabled Kit includes the same local features and adds online score syncing through the HighScoreSaves global leaderboard platform.
Wi-Fi can be disabled without affecting local gameplay, Free Play, score saving, settings, ROM Saver operation, game selection, or supported boot/menu features.
Gyruss Multigame Kit FAQ
Which games are included with the Gyruss Multigame kit?
The Gyruss Multigame kit includes Gyruss, Time Pilot, and Pooyan.
Which arcade PCB does the Gyruss Multigame kit support?
The kit is designed for documented compatible original Gyruss arcade PCBs.
Does the Gyruss Multigame kit require extra socketing?
Yes. Most Gyruss PCBs require sockets for 3× 16-pin PROMs, 1–2× 16-pin LS377s, and the Z80 CPU location.
How many high scores does the Gyruss Multigame kit save?
The kit saves the Top 5 scores with initials for each included game using serial EEPROM storage.
Does the Gyruss Multigame kit support Free Play and Coin-Up operation?
Yes. The kit supports Free Play while retaining traditional Coin-Up operation.
What is extended scoring on the Gyruss Multigame kit?
Extended scoring supports score display up to 9,999,990 points.
What is God Mode on the Gyruss Multigame kit?
God Mode provides unlimited-lives practice with score saving disabled.
Does the Gyruss Multigame kit support upright and cocktail cabinets?
Yes. The Gyruss Multigame kit supports documented upright and cocktail cabinet configurations.
Is Wi-Fi required for the Gyruss Multigame kit?
No. Standard kits save supported scores locally. Wi-Fi is optional for online leaderboard support.
