Arabian Free Play and High Score Save Kit for Original Arcade PCB Upgrade your original Arabian arcade PCB with Free Play, permanent high score saving, adjustable attract sounds, Flip Screen, configurable settings, and optional Wi-Fi leaderboard support while preserving the original gameplay, timing, controls, and sound. This plug-and-play arcade PCB upgrade uses the original Z80 processor and authentic Arabian arcade hardware. Installation requires a socketed Z80 CPU. No soldering is required when the original processor is already installed in a socket. Original Arcade Hardware • No Emulation • No Gameplay Changes • Battery-Free Score Storage View Arabian Install Guide Free Play Start games without coins while retaining normal coin operation when desired. Top 10 Scores Battery-free EEPROM storage permanently retains the ten highest scores. Optional Wi-Fi Submit qualifying scores to the HighScoreSaves online leaderboard. Original Hardware Designed specifically for a compatible original Arabian arcade PCB. Add Permanent Score Saving to Your Original Arabian Arcade PCB Original Arabian arcade hardware does not retain high scores after the machine is powered off. This kit adds battery-free score storage while continuing to use the original arcade PCB, Z80 processor, controls, sound hardware, and game program. The kit permanently stores the Top 10 scores in one dedicated score table. It also adds Free Play, adjustable attract sounds, menu-driven settings, score backup and restore, Flip Screen, attract-mode options, and an optional ROM Saver configuration. This is not an emulator, replacement game board, or multigame system. The original Arabian gameplay remains unchanged. Included Features Free Play Mode: Play without coins while retaining optional coin operation. Permanent High Score Saving: Battery-free EEPROM storage retains scores after power is turned off. Top 10 Score Tracking: Permanently stores the ten highest scores in one dedicated score table. On-Screen Settings Menu: Adjust supported game options through the arcade controls after installation. Adjustable Attract Sounds: Select supported attract-audio frequency settings. Attract-Mode Protection: Additional options help reduce prolonged static-image display time. Score Backup and Restore: Back up stored high scores and restore them when needed. Flip Screen: Correct the displayed screen orientation through the kit settings. ROM Saver: Supports removal of designated original program ROMs as explained in the installation guide. Cabinet Compatibility: Supports upright and cocktail cabinets using compatible original Arabian hardware. Installation Requirements Compatible Hardware: Compatible original Arabian arcade PCB Installation Difficulty: Easy when the original Z80 CPU is already socketed Soldering Required: No, when the original Z80 CPU is already socketed CPU Socket Requirement: The original Z80 processor must be installed in a 40-pin socket If the Z80 Is Soldered: A qualified arcade technician must remove the processor and install a 40-pin socket before the kit can be used Cabinet Access: Access to the arcade PCB is required during installation Cabinet Compatibility: Upright and cocktail cabinets using compatible original hardware Installation Guide: Download the Arabian Installation Guide PDF Standard and Optional Wi-Fi Kits Compare Standard and Wi-Fi Enabled Kits The Standard Kit permanently saves scores and settings locally on the installed arcade PCB. It does not require an internet connection. The optional Wi-Fi Enabled Kit includes the same local score-saving features and can also submit qualifying scores to the HighScoreSaves online leaderboard after a player enters their initials. Wi-Fi-enabled kits connect to compatible 2.4 GHz Wi-Fi networks. Wi-Fi can be disabled without affecting local score saving or normal gameplay. View Global Arcade High Scores Arabian Free Play and High Score Save Kit FAQ Is the Arabian Free Play and High Score Save Kit plug and play? Yes, when the original Z80 CPU is already installed in a socket. The original processor is removed from the PCB, installed on the kit, and the assembled kit is placed into the original CPU socket. Does installation require soldering? No soldering is required when the original Z80 CPU is already socketed. If the processor is soldered directly to the PCB, a qualified technician must install a 40-pin socket first. How many high scores does the Arabian kit save? The kit permanently stores the Top 10 scores in one dedicated score table. Does the kit support screen flipping? Yes. The Flip Screen setting can be used to correct the displayed screen orientation for a compatible cabinet setup. Does the kit change the original Arabian gameplay? No. The kit continues to use the original arcade PCB, processor, controls, sound hardware, and game program. It does not emulate or replace the original gameplay. What is the difference between Standard and Wi-Fi kits? Both versions save scores locally. The Wi-Fi version can also submit qualifying scores to the HighScoreSaves online leaderboard through a compatible 2.4 GHz Wi-Fi connection. Where can I download the installation guide? Download the Arabian Installation Guide PDF Designed, tested, and supported by HighScoreSaves for arcade collectors, operators, restorers, and original-hardware enthusiasts. Arabian Kit Resources 1. Arabian Installation Guide PDF 2. HighScoreSaves Tips and Tricks 3. Standard and Wi-Fi Kit Comparison 4. Global Arcade High Score Leaderboards 5. HighScoreSaves YouTube Channel
