Exidy 440 Multigame Instruction Magnet

The HighScoreSaves Exidy 440 Multigame Free Play and High Score Save Kit upgrades genuine Exidy 440 arcade hardware with 10 supported games, Free Play, permanent per-game high score saving, flexible game-selection menus, diagnostics, operator settings, and optional Wi-Fi leaderboard support while retaining the original Exidy 440 PCB platform, controls, sound, and gameplay. Exidy 440 Compatibility & Requirements Compatible Hardware: Genuine Exidy 440 arcade PCB hardware Processors: 6809E and 6809 Processor Requirement: Transfer the existing compatible 6809E and 6809 processors from the original Exidy 440 hardware to the HighScoreSaves kit Installation Method: Main 6809E daughterboard, sound daughterboard, 6809 CPU daughterboard, and ribbon cable installation Soldering: Not required during the documented installation Program ROM Requirement: Designated original program EPROMs must be removed as shown in the installation guide PCB DIP Switches: Follow the installation guide for required CPU-board and sound-board DIP switch positions Game Hardware: Uses the original Exidy 440 cabinet, PCB stack, controls, sound hardware, and supported gun system Installation: The original 6809E and 6809 processors are transferred to the appropriate HighScoreSaves daughterboards. Designated original program EPROMs are removed, the three kit PCBs are installed at the documented locations, and the supplied ribbon cable connects the 6809 CPU daughterboard to the sound daughterboard. Follow the installation guide closely for processor orientation, PROM placement, DIP switch positions, and daughterboard alignment. Exidy 440 Multigame Compatibility & Kit Details View Exidy 440 Installation Guide PDF What This Kit Adds 10-Game Multigame System Play ten supported Exidy 440 titles from one original Exidy 440 hardware platform without installing a separate multicade or emulation system. Free Play & Coin Operation Use Free Play for home or event operation while retaining traditional Coin-Up operation when desired. Flexible High Score Saving Choose Save All, Top 3, First Score Only, or disable high score saving entirely. Per-Game Score Tables Each of the ten included games maintains its own supported high score table using battery-free serial EEPROM storage. Flexible Game Menus Choose between a compact text-list game menu and a marquee-style image menu. Gun Select Mode Shoot once to select a supported game and shoot again to begin gameplay. Attract Sounds & Rotation Configure supported attract sounds at 25%, 50%, or 100% rotation intervals while rotating attract displays help reduce prolonged static-screen display. Menu-Driven Settings & Difficulty Configure supported operator and gameplay settings from the kit menu, including Normal, Hard, Harder, and Hardest difficulty options. Backup & Restore Back up supported high score tables and restore saved score data when needed. Stealth Mode Boot directly into a selected game for a stock-style dedicated cabinet appearance. Admin Lockout Restrict access to supported menu and configuration functions when the cabinet is used in public, route, or event environments. Startup Sound Options Select from 32 supported startup sound samples. God Mode Use supported practice gameplay without saving scores. Built-In Diagnostics Access supported troubleshooting and hardware diagnostic functions directly through the kit. ROM Saver The kit supplies supported program code after the designated original program EPROMs are removed as directed in the installation guide. What's Included 1 × HighScoreSaves 6809E main daughter PCB 1 × HighScoreSaves sound daughter PCB 1 × HighScoreSaves 6809 CPU daughter PCB 1 × ribbon cable Processors required: transfer the existing compatible 6809E and 6809 processors from your original Exidy 440 hardware to the kit during installation. Games Included Crossbow Classic Exidy 440 light-gun shooting gameplay on the original hardware platform. Cheyenne Western-themed Exidy shooting gameplay with fast-moving targets and gun-based action. Chiller Horror-themed Exidy 440 shooting gameplay with dark environments and target-based action. Catch 22 Military-themed target-shooting gameplay running on supported original Exidy 440 hardware. Clay Pigeon Clay-target shooting gameplay focused on timing, accuracy, and quick reactions. Combat Fast-paced shooting gameplay from the Exidy 440 hardware family. Crackshot Precision target-shooting gameplay using the supported original Exidy gun controls. Hit n Miss Target-shooting gameplay emphasizing reaction speed and accuracy. WhoDunnit Crime-themed Exidy shooting gameplay with detective-style presentation. Showdown Western quick-draw shooting gameplay on the supported Exidy 440 platform. Standard vs. Wi-Fi Kit Standard Kit Saves supported per-game high score data, settings, and configuration information locally on the Exidy 440 kit. No internet connection is required. Wi-Fi Enabled Kit Includes the same local features and can also submit qualifying completed scores to the HighScoreSaves online leaderboard. Wi-Fi can be disabled without affecting local score saving, Free Play, game selection, menu settings, diagnostics, or normal gameplay. Wi-Fi-enabled kits use compatible 2.4 GHz Wi-Fi networks. Exidy 440 Multigame Kit FAQ How do I enter the Exidy 440 kit settings menu? Hold Player 1 Start for approximately 4 seconds while turning on the cabinet. Release the button when the on-screen prompt tells you to continue. Which high score saving modes are available? The kit supports Save All, Top 3, First Score Only, or disabled high score saving. Each included game has its own supported score table. Do I need my original 6809E and 6809 processors? Yes. The existing compatible 6809E and 6809 processors are removed from the original Exidy 440 hardware and transferred to the appropriate HighScoreSaves daughterboards during installation. How does Gun Select Mode work? Shoot once to select a supported game from the menu and shoot again to start gameplay. Will the Wi-Fi kit still save scores if Wi-Fi is disabled? Yes. Local score saving, Free Play, game selection, settings, diagnostics, and normal gameplay continue to work when Wi-Fi is disabled or unavailable. Helpful Exidy 440 Resources Cheyenne Operator's and Service Manual Cheyenne Arcade Schematics and Wiring Diagrams Learn How HighScoreSaves Kits Work What's a Wi-Fi Kit? View Global Arcade High Scores Get HighScoreSaves Arcade Updates Get new kit releases, restocks, technical tips, and occasional subscriber-only offers. Join the Newsletter
