Darksoft Namco System 2 Multigame Kit

Darksoft CPS3 Multigame Kit Overview The Darksoft CPS3 Multigame Kit is designed for original Capcom CPS3 arcade hardware, allowing multiple CPS3 game titles to be run from a single multigame solution. This kit is intended for arcade collectors and technicians who want expanded game access without compromising original hardware behavior. Compatibility and Hardware Requirements Compatible with original Capcom CPS3 systems Requires a compatible CPS3 security cartridge Stable power delivery is required for reliable operation CD-ROM drive condition should be verified prior to installation Not compatible with CPS1, CPS2, or non-CPS systems Installation Notes CPS3 multigame installation requires familiarity with CPS3 hardware, cartridge handling, and CD-ROM based systems. Improper setup or power issues may result in loading or stability problems. This product is recommended for experienced arcade technicians. View all available Darksoft CPS3 Multigame Kits . No more long loading times. The UltraSIMM has 8× the capacity of a regular SIMM so you can load up to eight CPS-III games and switch without painful waits. Install Guide Helpful Tips & Tricks Two adapter boards compatible with TL86_PLUS (PROMAN) are included. You’ll need a TL86_PLUS / PROMAN programmer (typically around $85; not included). Each SIMM has a different pinout—match the SIMM type to the correct adapter. Programming the SIMMs 64 Mb SIMMs (two flash chips): program using the adapter labeled “Adapter SIMM 512 (TL86)” with a switch. 128 Mb SIMMs (one flash chip): program using the adapter labeled “Adapter SIMM 1G (TL86)” (no switch). Programming is straightforward and takes ~3 minutes per SIMM. Note: The kit requires a new BIOS that will be published on the forum. Works only with carts that have standard SH-2 processors. After installation you can switch between games with a 3-position DIP switch (power cycle required). Dip-Switch Game Config Example 111 — Street Fighter III: New Generation (SF3NG) 110 — Warzard / Red Earth 101 — Street Fighter III: 2nd Impact 100 — JoJo 011 — JoJo’s Bizarre Adventure 010 — SFIII: 3rd Strike (slot 1) 001 — SFIII: 3rd Strike (slot 2) 000 — SFIII: 3rd/“4th Strike” variant Attention A microSD card (not included) is required to store games. See the Arcade Projects forum for information on available games. Remove any content you’re not legally entitled to use. As with any arcade PCB, discharge static by touching ground before handling the board or motherboard. Shipping Information Please note: Ships with signature required and insurance. Typical dispatch: 48–96 hours. Contact us with any concerns. USA Ships via USPS or UPS at the sole discretion of Highscoresaves.com based on size/weight. International Expedited International (2–5 business days) via UPS for any order containing a Darksoft product. Customs/taxes/import fees may apply and are the customer’s responsibility. A phone number is required for all international shipments. We cannot under-declare values. Suggested tariff code: 95049080. Tech Support via Forum Tech questions can be searched and asked on the forum: ArcadeProjects.com — Capcom CPS-III If there’s any issue with the kit, please post on the forums or email us before assuming “it doesn’t work.” These carts are tested extensively. Other Darksoft Multigame Systems Darksoft multigame kits are available for multiple classic arcade platforms. Explore other systems designed for original hardware. CPS1 Multigame Kits CPS2 Multigame Kits Neo Geo MVS Multigame Kits ST-V Multigame Kits Namco System 2 Multigame Kits Taito F3 Multigame Kits FAQs How many games can UltraSIMM hold? Up to eight CPS-III games (8× the capacity of a standard SIMM). Do I need a programmer? Yes. Use a TL86_PLUS (PROMAN) programmer. Two compatible adapters are included; the programmer is not. Which adapter do I use? 64 Mb SIMMs use the “Adapter SIMM 512 (TL86)” with switch; 128 Mb SIMMs use the “Adapter SIMM 1G (TL86)” without switch. How long does programming take? About 3 minutes per SIMM. What BIOS/cart compatibility is required? A new BIOS (released on the forum) is required. Works only with carts that have standard SH-2 processors. How do I switch between games? Use the 3-position DIP switch; power cycle to apply the selection. Can I remove the microSD while powered? Yes—except during programming/game load or firmware updates. Where can I get support? Visit the Arcade Projects CPS-III forum.

Darksoft ST-V Multigame Kit Overview The Darksoft ST-V Multigame Kit is designed for original Sega ST-V (Titan) arcade hardware, allowing multiple ST-V game titles to be run from a single multigame solution. This kit is intended for arcade collectors and technicians who want expanded game access without compromising original hardware behavior. Compatibility and Hardware Requirements Compatible with original Sega ST-V (Titan) systems Motherboard and cartridge compatibility must be verified Stable power delivery is required for reliable operation Cartridge condition and connector integrity should be checked Not compatible with CPS, Neo Geo, or non-ST-V systems Installation Notes ST-V multigame installation requires familiarity with cartridge-based arcade hardware, proper power adjustment, and careful handling of connectors. This product is recommended for users experienced with arcade hardware installation and troubleshooting. View all available Darksoft ST-V Multigame Kits . The Dark Knight Edition ST-V Multigame kit updates the classic design: the cart plugs into the four motherboard connectors (not the standard game cart slot) for extra stability and room for new features. Install Guide Key Features New form factor: Fits into the four ST-V motherboard connectors for improved rigidity and feature space. Selectors: Choose games via the included LCD, or the optional OLED selector that lets you browse by images. Both can operate in parallel. Integrated sound: Sound kit is built-in. You’ll hear audio prompts for start/end of flashing directly from the cab speakers. Flash memory: The selected game remains stored until you change it. Status feedback: Two LEDs illuminate during programming; one LED remains when finished. Optional WAV files (SoundsStart.wav, SoundsEnd.wav) can play at those moments. Sound PCB support: Plug in a compatible Sound PCB to enjoy enhanced audio on titles like Batman and others. Audio outputs: The cart can emit sounds and supports connection of a speaker to SP+/SP-. microSD workflow: Insert/remove the microSD card anytime—except during updates. Attention A microSD card (not included) is required to run games. Check the Arcade Projects forum for available games. If you are not legally entitled to play any game or sound, you must delete it. As with any arcade PCB handling, discharge static by touching ground before handling the cart or motherboard. Shipping Information Please note: This product ships with signature required and insurance. Typical dispatch is within 48–96 hours. USA Ships via USPS or UPS, at the sole discretion of Highscoresaves.com depending on size/weight. International Expedited International Shipping (2–5 business days) via UPS is used for any order containing a Darksoft product. Customs/taxes/import fees may apply and are the customer’s responsibility. A phone number is required for all international shipments. We cannot under-declare values. Suggested tariff code: 95049080. Tech Support via Forum Tech questions can be searched and asked on the forum: ArcadeProjects.com — SEGA ST-V (Titan) If there is any issue with the kit or something isn’t working, please post on the forums or email us before concluding “it doesn’t work.” This cartridge has been tested extensively. Other Darksoft Multigame Systems Darksoft multigame kits are available for multiple classic arcade platforms. Explore other systems designed for original hardware. CPS1 Multigame Kits CPS2 Multigame Kits CPS3 Multigame Kits Neo Geo MVS Multigame Kits Namco System 2 Multigame Kits Taito F3 Multigame Kits FAQs

Darksoft CPS1 Multigame Kit Overview The Darksoft CPS1 Multigame Kit is designed for original Capcom CPS1 arcade hardware, allowing multiple CPS1 game titles to be run from a single multigame solution. This kit is intended for arcade collectors and technicians who want flexibility without compromising original hardware accuracy. Compatibility and Hardware Requirements Compatible with original Capcom CPS1 boards Correct voltage adjustment is required for stable operation Board revision compatibility must be verified prior to installation Not compatible with CPS2, CPS3, or non-CPS systems Installation Notes CPS1 multigame installation requires attention to power delivery, board condition, and cabinet wiring. Improper voltage levels or poor connections may result in instability. This product is recommended for users familiar with arcade hardware installation practices. Install Guide Key Features Full compatibility: Every CPS-1.5 QSound game works just like original hardware. Flexible for devs & modders: Ideal for trainers, hacks, new game development, or just having fun. Flash memory based: The loaded game persists until you write a new one—no reloading each boot. LCD selector included: Connects to the Multi PCB to browse microSD and load games. B-Board replacement: The Multi PCB replaces your existing B-Board. See the guide for installation details. Handle with care: Grip by the sides only—large PCB with many parts; avoid flexing or stressing components. microSD workflow: Store games on microSD; insert/remove anytime except during game loading or firmware update. Adjustments: Trim pot near microSD sets LCD contrast. Another trim pot near the RCA output sets QSound volume over JAMMA. Use the A-Board pot for CPS-1 title volume. Attention A microSD card (not included) is required to run games. Use Arcade Projects to locate legal game content. Discharge static by touching ground before handling this or any arcade PCB. Shipping Information Please note: Ships with signature required and insurance. Typical dispatch: 48–96 hours. USA Ships via USPS or UPS at our discretion. International Expedited UPS Worldwide (2–5 business days) for any Darksoft order. Customs fees may apply (customer responsibility). A phone number is required for all international shipments. We cannot under-declare. Suggested tariff code: 95049080 Tech Support via Forum Tech questions can be searched and asked on the forum: ArcadeProjects.com — Capcom CPS-1 If something isn’t working, please post on the forums or email us before assuming “it doesn’t work.” These kits are tested extensively. Other Darksoft Multigame Systems Darksoft multigame kits are available for multiple classic arcade platforms. Explore other systems designed for original hardware. CPS2 Multigame Kits CPS3 Multigame Kits Neo Geo MVS Multigame Kits ST-V Multigame Kits Namco System 2 Multigame Kits Taito F3 Multigame Kits FAQ Which mainboards are supported? Every Short Version CPS-1 mainboard is supported. Does it run CPS-1.5 QSound games? Yes—full CPS-1.5 QSound support just like original hardware. How do I load/select games? Use the included LCD selector to browse the microSD and flash a game. Does the selected game persist? Yes, flash memory retains the game until you write a new one. Can I remove the microSD while powered? Yes — except during game loading or firmware updates. How do I adjust audio and LCD? LCD contrast: trim pot near microSD. QSound volume: trim pot near RCA. CPS-1 volume: adjust A-Board pot. Any handling tips? Handle by the PCB edges; avoid flexing. Ask if uncertain. How is it shipped? Signature and insurance included. Dispatch 48–96 hours. USA via USPS/UPS; International via UPS.

Darksoft Taito F3 Multigame Kit Overview The Darksoft Taito F3 Multigame Kit is designed for original Taito F3 arcade hardware, allowing multiple F3 game titles to be run from a single multigame solution. This kit is intended for arcade collectors and technicians who want flexibility without compromising original hardware accuracy. Compatibility and Hardware Requirements Compatible with original Taito F3 hardware Cartridge and motherboard compatibility must be verified Correct voltage adjustment is required for stable operation Not compatible with CPS1, CPS2, or non-F3 systems Installation Notes Installation requires careful handling of F3 cartridges and attention to power delivery and connector condition. This product is recommended for users experienced with arcade hardware installation and troubleshooting. View all available Darksoft Taito F3 Multigame Kits . Install Guide Key Features Flash memory: Works like CPS2 multi—the selected game stays in flash until you write a new one. Two selectors: Use the included LCD or the optional OLED selector (browse by images). Both can be connected in parallel. Perfect fit: Cartridge fits the Taito F3 cart slot; some regions may require a connector mod. Handle with care: Grip the PCB by the sides—avoid pushing/pulling from the center. It’s a large board and should be handled gently. microSD workflow: Store games on a microSD card and insert into the cart. You may insert/remove the card anytime, except during a game load or firmware update. LCD contrast: Trim pot near the microSD slot adjusts the LCD contrast. Attention A microSD card (not included) is required to run games. Check the Arcade Projects forum for information about available games. Remove any content you are not legally entitled to use. Discharge static by touching ground before handling the cartridge or motherboard (standard arcade PCB practice). Shipping Information Please note: Ships with signature required and insurance. Typical dispatch is within 48–96 hours. Contact us if you have concerns. USA Ships via USPS or UPS at the discretion of Highscoresaves.com based on size/weight. International Expedited International (2–5 business days) via UPS on any order containing a Darksoft product. Customs/taxes/import fees may apply and are the customer’s responsibility. A phone number is required on all international shipments. We cannot under-declare values. Suggested tariff code: 95049080. Tech Support via Forum Tech questions can be searched and asked on the forum: ArcadeProjects.com — Taito F3 If there’s any issue with the kit, please post on the forums or email us before assuming “it doesn’t work.” These carts are tested extensively. Other Darksoft Multigame Systems Darksoft multigame kits are available for multiple classic arcade platforms. Explore other systems designed for original hardware. CPS1 Multigame Kits CPS2 Multigame Kits CPS3 Multigame Kits Neo Geo MVS Multigame Kits ST-V Multigame Kits Namco System 2 Multigame Kits FAQs How do I change games? Use the LCD menu or the optional OLED selector (image browsing). Select a game from microSD and flash it to the cart. Does the game persist after power off? Yes. The selected game remains in flash until you write a different one. Can I remove the microSD card while powered? Yes, except during a game load or firmware update. The LCD looks washed out—how do I fix it? Adjust the contrast using the trim pot near the microSD slot. Do I need to modify anything for my region? Some regions may require a connector modification for the cartridge to fit correctly. Where can I find compatible games and support? Visit the Arcade Projects Taito F3 forum. Remove any content you’re not legally entitled to use. How is the item shipped? Signature and insurance included. Usually ships 48–96 hours after order. USA via USPS/UPS; international via UPS.
