Space Duel Free Play and High Score Save Kit
Product information "Space Duel Free Play and High Score Save Kit"
Space Duel Free Play and High Score Save Kit for Atari Arcade PCB
Upgrade your original Space Duel arcade PCB with reliable free play, high score saving, attract sounds, and optional Wi-Fi leaderboard functionality while preserving authentic gameplay and original arcade hardware.
Designed specifically for original Atari vector hardware, this plug and play upgrade improves long-term reliability without changing gameplay timing, controls, sound, or the classic arcade experience collectors expect.
Play without coins while retaining optional coin operation.
Saves the Top 10 scores permanently with initials support.
Adjustable attract-mode sounds at 25%, 50%, or 100%.
Upload scores online to global arcade leaderboards.
Upgrade Your Space Duel Arcade Experience
Restore and enhance your original Space Duel arcade machine with a professionally designed Free Play and High Score Save Kit built specifically for authentic Atari vector arcade hardware.
Original boards often lose high scores, rely on aging components, or suffer from unstable resets. This upgrade modernizes your PCB while preserving the original gameplay, controls, timing, and vector arcade feel that made Space Duel one of Atari’s most recognizable color vector shooters.
Unlike multigame systems or reproduction boards, this kit keeps your original arcade PCB intact while improving long-term reliability for collectors, operators, and restoration projects.
Available Kit Options
Build your kit exactly how you want it. Choose between a Wi-Fi Enabled Kit or a Standard Save Kit.
Optional processor and socket upgrades are also available to simplify installation on original hardware.
Important Installation Notes
- Socketed 6502 required: Install a 40-pin socket if your processor is soldered directly to the PCB
- Review the Space Duel Installation Guide before installing
Included Features
- Easy Installation: No soldering, board modifications, or special wiring required
- Permanent Score Saving: Uses serial EEPROM instead of batteries or NVRAM
- High Score Save: Saves the Top 10 scores with initials
- Attract Sounds: Adjustable at 25%, 50%, or 100% of attract rotation
- Freeplay Mode: No more coins or opening the coin door
- Coin-Up Support: Continue using quarters or tokens if desired
- Attract Mode Protection: Helps reduce vector monitor burn-in by minimizing static screens
- Copyright Selection: Choose original manufacturer or HighScoreSaves branding
- On-Screen DIP Settings: Menu-driven configuration with no cabinet access needed
- ROM Saver: Remove original program ROMs while the program runs directly from the kit
- Cabinet Compatibility: Works in Upright and Cocktail cabinets
- Backup and Restore: Save and restore high scores anytime
- Reset Button: Restart the game without powering off when enabled through the menu
- Separate Score Tables: Independent high-score tables for 2, 3, 4, and 5 lives
- Fast Boot: Skip lengthy initialization sequences
- Stealth Mode: Boots directly into gameplay mode
Installation Information
- Installation Difficulty: Easy
- Soldering Required: No, if CPU is socketed
- Processor Requirement: Requires a 6502 processor
- Socketed CPU Required: Install a 40-pin socket if needed
- Cabinet Compatibility: Upright and Cocktail supported
- Installation Guide: Download PDF Installation Guide
Optional Wi-Fi Features and Online Leaderboards
Upgrade to a Wi-Fi Enabled Kit to upload scores online and compete against players around the world, locally within your arcade, or across your own connected cabinet network.
Standard kits save scores locally to the PCB, while Wi-Fi kits add automatic online score syncing through the HighScoreSaves global leaderboard platform.
Space Duel Free Play and High Score Save Kit FAQ
Do I need to solder anything?
No. This kit is fully plug-and-play with no board modifications required.
Does it save high scores permanently?
Yes. Scores are stored in EEPROM and remain saved when powered off.
How many high scores are saved?
The Top 10 scores with initials are saved permanently.
Does it support attract sounds?
Yes. Enable attract sounds at 25%, 50%, or 100% rotation frequency.
Can I use Freeplay mode?
Yes. Freeplay mode is fully supported.
Does Coin-Up still work?
Yes. Coin-Up continues working normally if desired.
Does it support Upright and Cocktail cabinets?
Yes. Compatible with both cabinet styles.
What is Stealth Mode?
Stealth Mode boots directly into gameplay while skipping menu screens.
What CPU is required?
A socketed 6502 processor is required.
Where can I download the installation guide?
