Donkey Kong Free Play and High Score Save Kits
Upgrade your original Donkey Kong cabinet with a plug-and-play Free Play and High Score Save Kit. Choose a Wi-Fi Enabled kit to upload scores to your personal online page (that we provide), or a Standard kit for local score saving—both preserve authentic gameplay while adding modern features.
Learn about Wi-Fi vs Standard kits, browse install guides and explore online scoreboards at ArcadeHighScores.com.
Braze Donkey Kong Free Play and High Score Save Kit
Braze Donkey Kong High Score Save Kit — Features & Install Overview A simple-to-install high score save kit for Donkey Kong that permanently remembers the top 5 scores and initials. Includes deluxe Free Play with full attract mode, selectable attract-mode sound, power-on self-test, and an on-screen settings menu for easy configuration. Installs in minutes—no special wiring or soldering is typically required. Installation Summary Power down the cabinet and access the CPU board. Carefully remove the Z80 CPU from the DK CPU board. Insert the Z80 into the included daughter card. Plug the daughter card into the vacated Z80 socket on the CPU board. Power on and follow the install guide to verify operation. Key Features Installs in minutes: no board modifications or special wiring. Top 5 High Score Save: remembers scores and initials permanently (no batteries). True Free Play: full attract mode while in Free Play. Selectable attract-mode sound: enable or disable via settings. Power-on diagnostics: automatic self-test each time the game powers up. On-screen settings menu: adjust options and erase high scores without opening the coin door. Just the FAQ's Where can I download the install guide? Do I need to solder anything? Typically no. Most installations require no soldering or special wiring. How do I reset the high scores? Use the on-screen settings menu to erase the high score table and restore defaults. Which CPU does this kit use? The kit interfaces with the Z80 CPU—remove the Z80, place it in the daughter card, then insert the card into the Z80 socket.
Donkey Kong | D2K | Pauline Edition Free Play and High Score Save Kit
Customize Your Donkey Kong | D2K | Pauline Edition DK Free Play and High Score Save Kit Build your kit exactly how you want it. Choose a Wi-Fi Enabled Kit or a Standard Save Kit. You can also add a processor and/or a 40-pin socket—optional but recommended for easy installation. Learn More About This Kit Click a button to view details, tips, or the installation guide. Features Easy install – No soldering, board modifications, or special wiring. Plug in and go! Save your scores forever – Uses a reliable serial EPROM, not failure-prone NVRAM or batteries. High Score Save – Saves the Top 5 scores. Initial entry – Choose 3 or 12 characters for high-score initials. Logo options – Switch between manufacturer logo or HighScoreSaves logo on the attract screen. Extended scoring – Save scores over 1,000,000 points. Freeplay – No more coins or opening the coin door. Coin Up – Still supports coins if desired. Attract sounds – Set at 25%, 50%, or 100% of the attract rotation. Attract mode – Minimizes screen burn; no more static screens. Change DIP settings – Menu-driven; no need to open the cabinet to flip DIP switches. ROM saver – Optionally remove original program ROMs to save power. Cabinet support – Works in Upright or Cocktail cabinets. Additional Features Backup & Restore – Back up high scores and restore later; ideal for before/after game-room parties. Separate score tables – Different high-score tables for 2, 3, 4, or 5 lives. Game menu – Easy-select in-game menu. ROM revision choice – Select US or Japan revisions. Practice Mode – Start at Level 4 (Girder, Elevator, Rivet, Pie Factory stages). Slow Down (Practice Mode) – Press a Start button to slow gameplay to half speed (Practice Mode only). Wild Barrel hack – All barrels thrown are Type 2. Color Barrel hack – Learn how to control barrel behavior. No Kill-Screen hack – Keep playing indefinitely. Important Socketed Z80 required: If your Z80 isn’t socketed, install a 40-pin socket. Read the Donkey Kong | D2K | Pauline Edition DK Installation Guide (PDF) before installing. Not compatible with DK Remix: You cannot “stack” the DK Remix kit with this HSS/Free Play kit. 2- or 4-board PCB stack only: Installs on a 2- or 4-PCB stack. Pauline graphics requirement: This kit requires 5 EPROMs to be changed on the video PCB for Pauline to work properly (this is also why DK Remix cannot be stacked). You must download and burn these ROMs yourself: available here (add to cart; $5). Note: Requires a socketed Z80 and a 2- or 4-board PCB stack. DK Remix is not compatible. Pauline graphics require 5 EPROM changes on the video PCB (download link below). Games List Donkey Kong D2K Pauline Edition Donkey Kong Wild Barrel Edition Donkey Kong Color Barrel Donkey Kong FAQ How many scores are saved? The kit saves the Top 5 high scores (supports extended scoring over 1,000,000). Does it support Freeplay and coin operation? Yes. You can enable Freeplay or keep Coin Up enabled for tokens/quarters. Is this compatible with the DK Remix kit? No. The DK Remix kit cannot be stacked with this High Score Save/Free Play kit. Which PCB stacks are supported? This kit installs on 2- or 4-board PCB stacks only. What do I need for the Pauline graphics? The Pauline edition requires 5 EPROMs on the video PCB to be changed. Download the ROMs here (add to cart; $5) and burn them yourself. Where can I download the Installation Guide? Download it here: Donkey Kong | D2K | Pauline Edition DK Installation Guide (PDF).
Donkey Kong | Pauline Edition Free Play and High Score Save Kit
Customize Your Donkey Kong | Pauline Free Play and High Score Save Kit Build your kit exactly how you want it. Choose a Wi-Fi Enabled Kit or a Standard Save Kit. You can also add a processor and/or a 40-pin socket—optional but recommended for easy installation. Learn More About This Kit Click a button to view details, tips, or the installation guide. Features Easy install – No soldering, board modifications, or special wiring. Plug in and go! Save your scores forever – Uses a reliable serial EPROM, not failure-prone NVRAM or batteries. High Score Save – Saves the Top 5 scores. Initial entry – Choose 3 or 12 characters for high-score initials. Logo options – Switch between manufacturer logo or HighScoreSaves logo on the attract screen. Extended scoring – Save scores over 1,000,000 points. Freeplay – No more coins or opening the coin door. Coin Up – Still supports coins if desired. Attract sounds – Set at 25%, 50%, or 100% of the attract rotation. Attract mode – Minimizes screen burn; no more static screens. Change DIP settings – Menu-driven; no need to open the cabinet to flip DIP switches. ROM saver – Optionally remove original program ROMs to save power. Cabinet support – Works in Upright or Cocktail cabinets. Additional Features Backup & Restore – Back up high scores and restore later; ideal for before/after game-room parties. Separate score tables – Different high-score tables for 2, 3, 4, or 5 lives. Game menu – Easy-select in-game menu. ROM revision choice – Select US or Japan revisions. Practice Mode – Start at Level 4 (Girder, Elevator, Rivet, Pie Factory stages). Slow Down (Practice Mode) – Press a Start button to slow the level to half speed (Practice Mode only). Wild Barrel hack – All barrels thrown are Type 2. Color Barrel hack – Learn how to control barrel behavior. No Kill-Screen hack – Keep playing indefinitely. Important Socketed Z80 required: If your Z80 isn’t socketed, install a 40-pin socket. Read the Donkey Kong | Pauline Installation Guide (PDF) before installing. Not compatible with DK Remix: You cannot “stack” the DK Remix kit with this HSS/Free Play kit. 2- or 4-board PCB stack only: Installs on a 2- or 4-PCB stack. Pauline graphics requirement: This kit requires 5 EPROMs to be changed on the video PCB for Pauline to work properly (this is also why DK Remix cannot be stacked). You must download and burn these ROMs yourself: available here (add to cart; $5). Note: Requires a socketed Z80 and a 2- or 4-board PCB stack. DK Remix is not compatible. Pauline graphics require 5 EPROM changes on the video PCB (download link below). Games List Donkey Kong Pauline Edition Donkey Kong Wild Barrel Edition Donkey Kong Color Barrel Donkey Kong FAQ How many scores are saved? The kit saves the Top 5 scores (with extended scoring over 1,000,000 supported). Does it support Freeplay and coin operation? Yes. You can enable Freeplay or keep Coin Up enabled for tokens/quarters. Is this compatible with the DK Remix kit? No. The DK Remix kit cannot be stacked with this HSS/Free Play kit. Which PCB stacks are supported? This kit installs on 2- or 4-board PCB stacks only. What do I need for the Pauline graphics? The Pauline edition requires 5 EPROMs on the video PCB to be changed. Download the ROMs here (add to cart; $5) and burn them yourself. Where can I download the Installation Guide? Download it here: Donkey Kong | Pauline Installation Guide (PDF).
Donkey Kong Free Play and High Score Save Kit
Customize Your Donkey Kong Free Play and High Score Save Kit Build your kit exactly how you want it. Choose a Wi-Fi Enabled Kit or a Standard Save Kit. You can also add a processor and/or a 40-pin socket—optional but recommended for easy installation. Learn More About This Kit Click a button to view details, tips, or the installation guide. Features Easy install – No soldering, board modifications, or special wiring. Plug in and go! Save your scores forever – Uses a serial EPROM, not failure-prone NVRAM or batteries. High Score Save – Saves the Top 5 scores. Initial entry – Choose 3 or 12 characters for high-score initials. Logo options – Switch between manufacturer logo or HighScoreSaves logo on the attract screen. Extended scoring – Save scores over 1,000,000 points. Freeplay – No more coins or opening the coin door. Coin Up – Still supports coins if desired. Attract sounds – Hear what you’ve been missing! Set at 25%, 50%, or 100% of the attract rotation. Attract mode – Minimizes screen burn with dynamic rotation. Change DIP settings – Menu-driven; no need to open the cabinet to flip DIP switches. ROM saver – Optionally remove original program ROMs to save power. Cabinet support – Works in Upright or Cocktail cabinets. Additional Features Backup & Restore – Back up high scores and restore later; great for before/after parties. Separate score tables – Different high-score tables for 2, 3, 4, or 5 lives. Game menu – Easy-select in-game menu. ROM revision choice – Select US or Japan revisions. Practice Mode – Start at Level 4 (Girder, Elevator, Rivet, Pie Factory). Slow Down (Practice Mode) – Press a Start button to slow the level to half speed (e.g., helpful on Elevator level). Wild Barrel hack – All barrels thrown are Type 2. Color Barrel hack – Learn to control barrel behavior. No Kill-Screen hack – Keep playing indefinitely. Important Ensure your Z80 is socketed; otherwise install a 40-pin socket for the kit to work. Read the Donkey Kong Installation Guide (PDF) before installing. You cannot “stack” the DK Remix kit with this HSS/Free Play kit. Installs on a 2- or 4-PCB stack. Just the FAQ's How many scores are saved? The kit saves the Top 5 high scores. Does this kit support Freeplay and coin operation? Yes. You can enable Freeplay or keep Coin Up enabled. What is Practice Mode? Practice Mode lets you start at Level 4 and even slow gameplay for training. Can I use the DK Remix kit with this? No. The DK Remix kit cannot be stacked with this High Score Save/Free Play kit. Where can I download the Installation Guide? You can download it here: Donkey Kong Installation Guide (PDF).
Donkey Kong Pauline GFX ROMs
These are the 5 Graphics ROMS that need to be installed on your PCB for the Pauline Graphics to work on your DK | Pauline or DK | D2K | Pauline high score save kit.This is an instant download once it is processed through your shopping cart for the following HSS kits -Donkey Kong | Pauline Edition Free Play and High Score Save KitDonkey Kong | D2K | Pauline Edition Free Play and High Score Save Kit There is a chart inside the zip folder, along with the 5 eproms that need to be burned and replaced on your PCB. These roms are 2716 proms. There is a total of 5 needed.
Donkey Kong Rearranged Multigame Free Play and High Score Save Kit
Customize Your Donkey Kong Rearranged Multigame Free Play and High Score Save Kit Build your kit exactly how you want it. Choose a Wi-Fi Enabled Kit or a Standard Save Kit. You can also add a processor and/or a 40-pin socket—optional but recommended for easy installation. Learn More About This Kit Click a button to view details, tips, or the installation guide. In the drop-down selections above, choose which PCB to install the kit on (kits differ by selection), add the 4-game Remix Collection, and enable Wi-Fi to upload your scores to your personal webpage. 3DK Install Guide (Donkey Kong) — PDF 3DKJr Install Guide (Donkey Kong Jr.) — PDF This is the newest Donkey Kong kit on the scene: high-score saves, Free Play, and attract sounds—designed for the 21st century. This is NOT Double Donkey Kong. Install on a Donkey Kong or Donkey Kong Jr. board set (selected in the drop-downs) and play Donkey Kong, Donkey Kong Jr., Donkey Kong 3, D2K: Jumpman Returns plus the Rearranged Edition and unlockable editions on your PCB. Adding the Remix Collection gives you four more game versions. No special wiring or switches required. Enter the Modern Menu by holding P1 for 4 seconds to access the Game Select Menu instantly. Game List Donkey Kong Pauline Donkey Kong Donkey Kong Junior Donkey Kong 3 D2K: Jumpman Returns Pauline D2K: Jumpman Returns Donkey Kong (Japan ROMs) Donkey Kong Jr. (Japan ROMs) Practice Levels Rearranged Edition – an intertwined game-level lineup Optional Remix Collection Donkey Kong Remix Donkey Kong Jr. Remix Donkey Kong Christmas Remix Donkey Kong Spooky Remix Unlockable Levels Drunken Master Edition – Grab the bottle for 2× points during a 30-second timer; controls are reversed. Black Hammer Edition – When the lights go out… Wild Barrel Edition – More Wild Barrels than ever. Miner 2049er Edition – A tough, nostalgic challenge. Builders Edition FHMC Edition – Faster, Harder, More Challenging Rearranged lineup starting at L04+. Personal Edition – Create your own Rearranged version. Features No soldering required – No board mods or special harness wiring. Plug in and go. Modern Menu – Sleek interactive game menu (or choose a standard list). Save your scores forever – Uses a reliable serial EPROM (not failure-prone NVRAM or batteries). High Score Save – Saves the Top 5 scores and initials for each game. Separate score tables – Per game/mode (DK/DKJr/DK3/Pauline, etc.). HighScoreSaves splash logo – Optional on game change/startup. Extended scoring – Saves scores over 1,000,000 points for all games. Attract sounds – Set at 25%, 50%, or 100% of the attract rotation. Free Play – No coins or opening the coin door. Coin Up – Still supports coins if desired. Cabinet type – Upright or Cocktail (with a 2-board stack). Screen saver – Reduces burn-in; if left on Game Select, it auto-cycles attracts. DIP settings – Menu-driven coinage, Free Play, bonus lives, etc.—no cabinet opening. ROM Saver – Optionally remove original program ROMs to save power. Practice Mode – Most start at Level 4; some start earlier. Sound Expansion Module – Truist sounds across all games. Kill-screen switchable – Toggle on/off in DIPs (standard DK/Pauline). Important Socketed Z80 required: If your Z80 isn’t socketed, install a 40-pin socket. Board compatibility: Choose the correct kit for DK or DKJr in the drop-down. DK3 PCBs are not supported. Stack type: Works on a 2-board stack only (not 4-board). Read the install guide for your board set: 3DK Install Guide (Donkey Kong) or 3DKJr Install Guide (Donkey Kong Jr.). Just the FAQ's Do I need to send in my PCB to get the kit installed? No. Install it yourself in ~15 minutes. No soldering required. Refer to the installation guides and the video overview. Does the 3DK Multigame kit sound correct? Yes. Choose preferred audio in the Game Settings menu. Options include DK analog sounds for DKJr, NES-style DKJr sounds, and a 100% accurate external Sound Expansion Module (default). Can this run on DK and DKJr PCBs? Yes—DK and DKJr are supported (select the correct option in the drop-down). DK3 PCBs are not supported for this kit. Will it work on a 4-board DK stack? No. The daughter cards fit a 2-board stack only. Cocktail use is possible with a DKJr cocktail that has a DK 2-board stack installed. Where can I download the Installation Guide? Download the PDF for your board set here: 3DK Install Guide (Donkey Kong) — PDF 3DKJr Install Guide (Donkey Kong Jr.) — PDF
Donkey Kong Remix Tournament Edition Multigame Free Play and High Score Save Kit
Donkey Kong Remix Tournament Edition Multigame Free Play & High Score Save Kit This plug-and-play Donkey Kong Multigame Remix Tournament Edition kit adds multiple Donkey Kong versions to your original cabinet, while preserving high scores and enabling Free Play. Game List Donkey Kong Donkey Kong Remix Donkey Kong Deranged Donkey Kong Trainer Donkey Kong with in-game pace calculator Donkey Kong Tournament Edition Donkey Kong Remix Tournament Edition Main Features Switch between games via the Game Select screen. Scores are saved permanently—even after powering off. Free-Play option available. Each game has its own service menu settings. Any game can be set as default boot game. Game switching, score saving, and Free-Play can be enabled or disabled. Compatible with both U.S. and Japanese board sets and ROMs. Runs original Donkey Kong ROMs directly from your PCB when selected. Extra Features Six new stages + three new bonus stages, alongside the originals. Stages include progressive variations to keep gameplay fresh. Blue hammer jumping mechanic. New Rivets stages with collapsing girders to crush Firefoxes. Reversible elevators on the 3rd Rivets stage. New challenging kill screen for an exciting finish. Extra Jumpmen available at 150k, 250k, or 350k points. Donkey Kong Remix Tournament Edition Thousands of game variations via a tournament code system. Codes are inter-compatible across different machines and players. Play as three unique characters, each with special abilities. Options: warp pipes to skip stages, adjust hammer number/duration, set stage order, alter randomizer, enable timer or timed play, and more. Donkey Kong Tournament Edition Includes the same extensive tournament system with inter-compatible codes. Play as three different characters. Warp pipes, hammer settings, optional jump hammers. Set start/end levels, change stage order, modify randomizer. Enable timers or timed play modes. Includes context-sensitive control enhancements. Donkey Kong Trainer Features Start directly at level 5. Restart or skip stages with one button press. Adjust game speed (0–150% in 10% increments). Built-in pace calculator and pace chart. Per-stage jump and smash point displays. On-screen indicators: DK logic, spring types, fireball AI, etc. Timers for hammer duration, difficulty changes, firefox spawns. Donkey Kong Deranged Features Difficulty continues scaling past level 5. New varieties of Wild Barrels. Up to 8 fireballs/firefoxes simultaneously at high levels. Increased fireball, conveyor, and elevator speeds. Accelerated spawn and barrel release rates. Custom kill screen designed for maximum challenge. Just the FAQ's Which PCBs are supported? Compatible with both U.S. and Japanese Donkey Kong boards and ROM sets. Does this kit save high scores? Yes, scores are stored permanently—even after power off. Each game has its own high score table. Is Free-Play supported? Yes. Enable Free-Play from the kit’s menu. Coin play remains available. How do tournament codes work? Codes generate unique game variations and can be shared across machines, ensuring all players play the same settings. Can I use this kit to practice specific levels? Yes, the Trainer mode lets you restart or skip levels, start at level 5, and adjust speed. Does it run my original Donkey Kong ROMs? Yes, when Donkey Kong is selected, the kit runs the ROMs directly from your PCB. Are there new gameplay mechanics? Yes. Blue hammer jumps, collapsing Rivets floors, reversible elevators, new Wild Barrels, and advanced kill screens are all included. Do I need a socketed CPU? Yes. Ensure your Z80 is socketed. If not, you must install a 40-pin socket before using the kit.
