Vanguard Free Play and High Score Save Kit

Customize Your Xevious Free Play and High Score Save Kit Build your kit exactly how you want it. Choose a Wi-Fi Enabled Kit or a Standard Save Kit. You can also add a processor and/or a 40-pin socket—optional but recommended for easy installation. Learn More About This Kit Click a button to view details, tips, or the installation guide. Main Features Easy install: No soldering, board modifications, or special wiring. Plug in and go. Save your scores forever: Uses reliable serial EEPROM (not failure-prone NVRAM or batteries). High Score Save: Stores the Top 5 scores with initials. Initials entry: 3 characters using Highscoresaves copyright or 10 using NAMCO copyright. Copyright: Switch between manufacturer logo or Highscoresaves logo. Freeplay: No more coins or opening the coin door. Coin Up: Still supports tokens/coins if desired. Attract Mode: Minimizes screen burn. On-screen DIP settings: Menu-driven DIP control. ROM Saver: Remove original program ROMs if desired. Cabinet support: Works in Upright and Cocktail cabinets. Additional Features Backup & Restore: Save and restore high scores for events or parties. Separate score tables: Different HSS tables for 2, 3, or 4 lives. Fast Boot: Self-test available via menu or DIP switches. Cross Hatch: Pattern for monitor adjustment. RAM / Input Test: Enable RAM and input diagnostics. Important Installation Notes Z80 CPU must be socketed: Install a 40-pin socket if your CPU is soldered. Read the Xevious Installation Guide (PDF) before beginning installation. P1 and P2 start buttons will not light while on Free Play FAQ Is installation truly plug-and-play?Yes. No soldering required. Just ensure your Z80 CPU is socketed. How many scores are saved and can I enter initials? Top 5 scores saved. Enter 3 or 10 initials depending on copyright option selected. What’s the difference between Wi-Fi and Standard kits? The Wi-Fi kit uploads scores online; the Standard kit saves locally only. Does it support coins as well as Freeplay? Yes. You can use Freeplay or coin-up. What diagnostics and setup tools are included? Includes Fast Boot, Cross Hatch, and RAM/Input Test features. Where can I download the Installation Guide? Xevious Installation Guide (PDF) Do P1/P2 start buttons light up in Free Play? No. P1 and P2 start buttons will not illuminate while in Free Play. Resources Xevious — Installation Guide (PDF) HighScoreSaves YouTube Channel — Installation Tips HighScoreSaves Facebook Page HighScoreSaves eBay Store

Customize Your Pengo Free Play and High Score Save Kit Build your kit exactly how you want it. Choose a Wi-Fi Enabled Kit or a Standard Save Kit. You can also add a processor and/or a 40-pin socket—optional but recommended for easy installation. Learn More About This Kit Click a button to view details, tips, or the installation guide. Main Features Easy install: No soldering, board modifications, or special wiring—plug in and go. Save your scores forever: Uses a serial EEPROM (not failure-prone NVRAM or batteries). High Score Save: Stores the Top 5 scores with initials. Attract sounds: Enable at 25%, 50%, or 100% of attract-screen rotations. Free Play: Start games without coins or opening the coin door. Coin Up: Coins/tokens still supported if desired. Attract mode: Reduce screen burn—no more static screens. Menu-driven DIP settings: Change settings on-screen—no cabinet pull-out. ROM Saver: Optionally remove original program ROMs to save power. Cabinet support: Works in upright or cocktail cabinets. Additional Features Backup & restore: Back up high scores and restore later—ideal before/after parties. Separate score tables: Different tables for chosen lives (2, 3, or 4). Reset button: Restart a game without powering off (enable in menu). Important Installation Notes Ensure your Z80 is socketed. If not, install a 40-pin socket for the kit to work. Use a standard Z80: Some PCBs use an encrypted Z80 that is not compatible with this save kit. Read the installation guide (PDF) before installing. Game List Pengo FAQ Do I need to solder anything?No, the kit is plug-and-play. No soldering or board modifications required. Does it save my high scores permanently?Yes, scores are stored on EEPROM and don’t need batteries. How many high scores does it save?The kit saves the Top 5 scores with initials. Does it support attract sounds?Yes, you can enable attract sounds at 25%, 50%, or 100% frequency. Can I use Free Play and coins?Yes, the kit supports both Free Play and Coin Up modes. Does it work in all cabinet types?Yes, it works in upright and cocktail cabinets. Can I back up and restore scores?Yes, you can back up scores and restore them later, perfect for before/after parties. Does it provide separate score tables?Yes, you can save distinct tables for different life settings (2, 3, or 4 lives). What CPUs are compatible?You must use a standard Z80. Encrypted Z80 CPUs are not supported. Where can I download the installation guide? You can download it here: Pengo Installation Guide (PDF) Resources Pengo Free Play and High Score Save Kit — Installation Guide (PDF) HighScoreSaves YouTube Channel — Installation Tips HighScoreSaves Facebook Page HighScoreSaves eBay Store

Customize Your Mappy Free Play and High Score Save Kit Build your kit exactly how you want it. Choose a Wi-Fi Enabled Kit or a Standard Save Kit. You can also add a processor and/or a 40-pin socket—optional but recommended for easy installation. Learn More About This Kit Click a button to view details, tips, or the installation guide. Main Features Easy install: No soldering, board modifications, or special wiring—just plug in and play. Save your scores forever: Uses reliable serial EPROM, not failure-prone NVRAM or batteries. High Score Save: Stores the Top 5 scores. Attract sounds: Plays on every attract cycle. Full attract sounds: Includes the dot munching sound from the attract gameplay screen. Freeplay: No more coins needed. Coin up: Keep coin operation enabled if desired. Attract mode: Minimizes static screens to reduce burn-in. Menu-driven DIP settings: Full on-screen DIP adjustment menu. ROM Saver: Optionally remove original program ROMs to reduce power usage. Cabinet compatibility: Works in Upright or Cocktail cabinets. Additional Features Separate score tables: Distinct tables for 2, 3, 4, or 5 lives. Backup & Restore: Save and reload high scores anytime. Selectable character names: Choose between Goro or Meowky. Important Installation Notes Processor required: Must have a 6809E installed. Socketed CPU required: If your CPU is not socketed, install a 40-pin socket. Read the Mappy Free Play and High Score Save Kit Installation Guide / Manual (PDF) before setup. FAQ Does this kit permanently save scores?Yes—your Top 5 scores are permanently saved using serial EPROM. Freeplay and coin operation?Yes, choose between Freeplay or Coin-Up. Attract sounds?Includes the full attract sound set including dot munching. Soldering required?No—just plug into a socketed 6809E processor. Backup & Restore?Yes—save and load scores anytime. Download the Installation Guide Download the Mappy Free Play and High Score Save Kit Setup Instructions / Installation Manual (PDF) Socketed CPU required?Yes—a socketed 6809E. Resources Mappy Free Play and High Score Save Kit — Installation Guide (PDF) HighScoreSaves YouTube Channel — Installation Tips HighScoreSaves Facebook Page HighScoreSaves eBay Store

Customize Your Super Multipede Multigame Free Play and High Score Save Kit Build your kit exactly how you want it. Choose a Wi-Fi Enabled Kit or a Standard Save Kit. You can also add a processor and/or a 40-pin socket — optional but recommended for easy installation. Learn More About This Kit Click a button to view details, tips, or the installation guide. Compatibility: This Super Multipede multigame kit installs on a Millipede PCB only. Main Features Easy install: No soldering, board modifications, or special wiring. Plug in and go. Save your scores forever: Uses reliable serial EEPROM (not failure-prone NVRAM or batteries). High Score Save: Centipede/Millipede save Top 8; Super Breakout & Warlords save Top 5. Separate score tables: Distinct tables for Centipede, Millipede, and Super Breakout. ROM revisions: Uses the most current ROM revisions. Attract sounds: Set to 25%, 50%, or 100% per game. Freeplay & Coin-Up: Play without coins or keep quarters enabled (Warlords is Freeplay only). Attract mode: Minimizes screen burn; no static screens. Menu-driven DIP settings: Change DIP switches without opening your cabinet. Cabinet support: Works in Upright or Cocktail; flips screen in cocktail mode for Centipede/Millipede. Super Breakout & Warlords use P1 side. Additional Features Backup & Restore: Save and restore high scores (great before/after parties). Reset button: Restart a game without powering off (enable in menu). Menu for game select: Hold P1 for 4 seconds, then release. Stealth Mode: Choose boot game (last played or from list). ROM Saver: All original program ROMs (1H–1M) can be removed. Copyright options: Choose original Atari or HighScoreSaves branding. Games List Centipede Millipede Super Breakout Warlords Important Installation Notes Compatibility: This Super Multipede multigame kit installs on a Millipede PCB only. Socketed 6502 required: If your 6502 isn’t socketed, install a 40-pin socket for this kit to work. Read the Super Multipede Installation Guide (PDF) before setup. Just the FAQ's Which PCB is required?This kit installs on a Millipede PCB only. Which games are included?The kit includes Centipede, Millipede, Super Breakout, and Warlords. Warlords 4-player support?Only 1 player is supported due to hardware limitations. How many scores are saved?Centipede & Millipede: Top 8Super Breakout & Warlords: Top 5 Does it support Freeplay and coin-up?Yes. Note: Warlords is Freeplay only. How to select a game?Hold P1 for 4 seconds, then release. What is Stealth Mode?Choose what game the kit boots into—either last played or fixed selection. What is ROM Saver?You may remove all original program ROMs (1H–1M); program runs from the kit. Where to download the Installation Guide?Super Multipede Installation Guide (PDF) Do I need a socketed CPU?Yes — a socketed 6502 is required. Resources Super Multipede — Installation Guide (PDF) HighScoreSaves YouTube Channel HighScoreSaves Facebook Page HighScoreSaves eBay Store

Customize Your Pacman | Ms Pacman Multi Game Free Play and High Score Save Kit Build your kit exactly how you want it. Choose a Wi-Fi Enabled Kit or a Standard Save Kit. You can also add a processor and/or a 40-pin socket — optional but recommended for easy installation. Learn More About This Kit Click a button to view details, tips, or the installation guide. Main Features Easy install — No soldering, board modifications, or special wiring. Plug in and go. Save your scores forever — Uses reliable serial EPROM (not NVRAM or batteries). High Score Save — Saves the Top 10 scores with initials. Attract Sounds — Adjustable to 25%, 50%, or every attract screen. Freeplay — No more coins or opening the coin door. Coin Up — Still supports coins if desired. Attract Mode — Prevents static burn-in on screens. Copyright options — Show original Midway logos or the HighScoreSaves logo. Menu-driven DIP settings — Change DIP switches without opening the cabinet. ROM Saver — Original program ROMs must be removed with this kit installed. Cabinet support — Works in Upright, Cabaret, or Cocktail cabinets. Ships with latest v1.09e version — The best Pac Multi yet! Additional Features Backup & Restore — Back up and reload your scores, great for parties. Fast or Original versions — Play either mode. Extended scoring — Supports up to 9,999,990 points (7-digit saves, no rollover). Separate high score tables — Maintains separate tables for Fast and Original play. Stealth Mode — Choose what game the kit boots to. Enable/disable submenus to restrict guest access. Game select menu included. Option to play Inky and Pinky with original Pac bug behavior or fixed AI. Turn off the “kill screen” to continue past level 255. Switch ghost names from original to alternates. Start at Level 1, Apple level, Key level, or directly at 255 to see the kill screen. Pengo! — Playable using P1 button, no control panel mods required. Important Installation Notes Ensure your Z80 is socketed. If not, install a 40-pin socket for compatibility. Read the installation guide before starting — Pac-Man | Ms. Pac-Man Multigame Installation Guide (PDF) . Compatible PCBs — Works with Pac-Man, Ms. Pac-Man, and Pac-Man Plus boards. Changes color PROMs: Pac-Man Plus, Ms. Pac-Man Plus, and Pengo will have original colors and sounds. New RAM Test (v1.09+) — DIP 1 and 2 OFF triggers an automatic RAM diagnostic at startup; DIP 1/2 ON disables the loop test. Game List Fast Versions Pac-Man Ms. Pac-Man Pac-Man Plus Ms. Pac-Man Plus Original Versions Pac-Man Ms. Pac-Man Pac-Man Plus Ms. Pac-Man Plus Pengo V3 Pengo V2 Just the FAQ's Which PCBs are compatible?Original Pac-Man, Ms. Pac-Man, and Pac-Man Plus boards. Do I need to remove the original program ROMs?Yes. With ROM Saver enabled, original program ROMs must be removed. How many scores are saved?The kit saves the Top 10 scores with initials and maintains separate tables for Fast and Original modes. Does it support Freeplay and coins?Yes. Enable Freeplay or keep Coin Up active—your choice. Can I bypass the kill screen?Yes. You can disable the kill screen and continue past level 255. What’s included in v1.09e?v1.09e includes the latest RAM test, extended scoring, and refinements to the multigame menu and options. Is Pengo included and how is it controlled?Yes, Pengo is included and is playable using the P1 button—no control panel mods required. Can I change ghost AI and names?Yes. Toggle original Pac bug behavior vs fixed AI, and switch between original and alternate ghost names. Will colors/sounds be correct on Plus and Pengo?Yes. Color PROMs are handled so Pac-Man Plus, Ms. Pac-Man Plus, and Pengo use original colors and sounds. Where is the installation guide?Right here: Pac-Man | Ms. Pac-Man Multigame Installation Guide (PDF) . Resources Pac-Man | Ms. Pac-Man Multigame — Installation Guide (PDF) HighScoreSaves YouTube Channel — Installation Tips HighScoreSaves Facebook Page HighScoreSaves eBay Store
